The MS100 bar code wand is targeted toward low reading volume / cost
effective solutions. The advanced optics and electronic design converts bar
code labels into a high quality digital signal. Able to read color, faded, and
low contrast barcodes quickly and accurately, the MS100 is a proven solution.
Its shape gives the MS100 the comfort and handling of a conventional ink
pen. Just sweep the tip of the wand across the bar code in either direction
and listen for the "good read" beep that lets you know the data has been
successfully captured. It doesn't get easier than that.
Available with TTL, keyboard wedge, RS232, and USB interfaces
Unitech America
Los Angeles Miami Mexico
http://www.ute.com http://latin.unitech-adc.com
e-mail: inquiry@ute.com e-mail: info@latin.uniteeh-adc.com
Unitech APAC
Taipei http://www.unitech-adc.com e-mail: aidcsales@adc.unitech.com.tw
Unitech Japan
Tokyo http://www.unitech-japan.co.jp e-mail: sales@unitech-japan.co.jp
Specifications subject to change without notice. Copyright 2005 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
All products and company names are trademarks, service marks or registered trademarks of their respective owners.
MS100 Wand Scanner
Features
Rugged, lightweight design
Easy to use and configure
Low power consumption
Wide read angle
High scan speed
User configurable via PC programming
Advanced Data Editing
MS100
Wand
Optical
Light Source
650 ~ 660nm Red LED
Receiving Device
Photo Sensor
0.04" (1.0mm)
Depth of Field
Resolution
5 mils (0.127mm)
Print Contrast
0.6 minimum
Scan Rate
4 ~ 24 inches/second (10 ~ 60 cm/second)
Reading Angle
45˚ to 90˚
Ambient Light
5000 Lux/Max
Functionality
Symbologies
Codabar, Code 11, Code 32, Code 39 (standard and full ASCII),
Code 93, Code 128, EAN-8, EAN-13, Label Code IV and V,
MSI Code, Plessey Code, Standard 2 of 5, UPC-A, and UPC-E
Interface
USB, Keyboard wedge, RS232, or TTL (undecoded)
Mechanical and Electrical
Dimensions:
Length 5.5" (140mm)
Diameter 1.2" x .9" (30mm x 23mm)
Weight:
76g
Cable
71" (180 cm)
ABS plastic
Case Material
5V DC ±10%
Supply Voltage
Surge Power
<800mA
Working Current
60mA ±10mA
Environmental:
Operating Temperature
Storage Temperature
Humidity
Mechanical Shock
Unitech Europe
Tilburg / NL Wiltshire / UK
http://www.unitech-europe.nl http://www.unitech.co.uk
e-mail: sales@unitech-europe.nl
Unitech Greater China
Beijeng Suzhou Shanghai Guang Zhou Xiamen Taipei http://www.ute.com.cn
unitech@ute.com.cn http://adc-utt.unitech.com.tw barcode@unitech.com.tw
Head Office
http://www.unitech.-adc.com e-mail: marketing@adc.unitech.com.tw
Scanner
32˚F to 122˚F (0˚C to 50˚C)
-4˚F to 140˚F (-20˚C to 60˚C)
20% to 85% RH non-condensing
5' (1.5m) drop to concrete
