LOW RAIL POSITION
SKU #
34826872
34926874
35026877
FULL CUBBY HEADBOARD PARTS LIST
A
Headboard
Headboard Leg
B
( L / R )
C
Stretcher
TWIN / FULL RAILS PARTS LIST
H
Twin / Full Rails
This product is manufactured by HOUS for
DO NOT USE SUBSTITUTE PARTS. PLEASE CONTACT YOUR RETAIL STORE OR WWW.ROOMSTOGO.COM
Version #1 - JUN 1 . 2024
VIVIEN
FULL CUBBY BED
3412687P - FULL CUBBY BED - WIREBRUSH GRAY
ITEM#
2687-18H
2687-18F
2687-17R
1PC
2PCS
1PC
2PCS
WITH SERVICE OR PARTS REPLACEMENT REQUEST
ITEM DESCRIPTION
FULL CUBBY HEADBOARD
FULL PANEL FOOTBOARD
TWIN / FULL RAILS
FULL PANEL FOOTBOARD PARTS LIST
D
Footboard
E
Slat
Long
F
Support Leg
Short
G
Support Leg
HIGH RAIL POSITION
Q'TY
1
1
1
1PC
5PCS
5PCS
5PCS
Page 1 of 5
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ROOMS TO GO HOUS VIVIEN 3412687P
Summary of Contents for ROOMS TO GO HOUS VIVIEN 3412687P
- Page 1 VIVIEN FULL CUBBY BED LOW RAIL POSITION HIGH RAIL POSITION 3412687P - FULL CUBBY BED - WIREBRUSH GRAY SKU # ITEM# ITEM DESCRIPTION Q'TY 34826872 2687-18H FULL CUBBY HEADBOARD 34926874 2687-18F FULL PANEL FOOTBOARD 35026877 2687-17R TWIN / FULL RAILS FULL CUBBY HEADBOARD PARTS LIST FULL PANEL FOOTBOARD PARTS LIST Headboard...
- Page 2 VIVIEN FULL CUBBY BED Q'TY FULL CUBBY HEADBOARD HARDWARE LIST Allen key 4*74*29mm Q'TY FULL PANEL FOOTBOARD HARDWARE LIST Screw #8*1-3/16" 10PCS Screwdriver (not provided) Hardware Pack Location(s): SKU # ITEM# COLOR ITEM DESCRIPTION 34826872 2687-18H WIREBRUSH GRAY FULL CUBBY HEADBOARD 34926874 2687-18F WIREBRUSH GRAY...
- Page 3 ASSEMBLY INSTRUCTION ***Caution:Please read all instructions carefully before starting the assembly process.These parts are cumbersome and heavy.Therefore,two people are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly. Remark: The bolts were pre-installed on the stretcher. Remark: The bolts were pre-installed on headboard leg.
- Page 4 ASSEMBLY INSTRUCTION ***Caution:Please read all instructions carefully before starting the assembly process.These parts are cumbersome and heavy.Therefore,two people are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly. Step 5: Use the high rail position, connect long support leg (F) to short support leg (G), and attach them to slat (E) by turning clockwise. *Use with trundle *Use without trundle Adjustable leveler...
- Page 5 ASSEMBLY INSTRUCTION ***Caution:Please read all instructions carefully before starting the assembly process.These parts are cumbersome and heavy.Therefore,two people are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly. Mattress Foundation sold separately. Remark: MATTRESS FOUNDATION REQUIRED FOR PROPER...
-
Page 6: English Version
Remark: Electrical warning label ENGLISH VERSION SPANISH VERSION IMPORTANT SAFETY INSTRUCTIONS INSTRUCCIONES DE SEGURIDAD IMPORTANTES El mal uso puede INCENDIO o MUERTE por DESCARGA Misuse can result in FIRE or DEATH by ELECTRICAL SHOCK ELECTRICAL RATING(12VDC/4.0AMPERES) CLASIFICACION ELECTTRICA(12VDC/4.0AMPERES) Dongguan Shijie Hua Xu Electronics Factory Dongguan Shijie Hua Xu Electronics Factory PART NUMBER (HX65C-1204000-AU) PART NUMBER (HX65C-1204000-AU)
