- Page 1 MANUAL ENGLISH Spectral M3000 Q4 IP Ordercode: 43546 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Spectral M3000 Q4 IP Table of contents Warning ....................................3 Safety Instructions ................................. 3 Operating Determinations ............................5 Rigging .................................... 5 Connection with the mains............................6 Return Procedure ................................7 Claims ....................................7 Description of the device ..............................8 Frontside..................................8 Backside .................................. - Page 3 Spectral M3000 Q4 IP Maintenance ..................................29 Troubleshooting ................................29 No Light ..................................29 No Response to DMX..............................29 Product Specifications ..............................31 Dimensions ..................................32 Notes ....................................33 Ordercode: 43546...
-
Page 4: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: Showtec Spectral M3000 Q4 IP Special Schuko power cable (1,5 m) ... - Page 5 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 6: Operating Determinations
Spectral M3000 Q4 IP • Repairs, servicing and electric connection must be carried out by a qualified technician. • WARRANTY: Till one year after date of purchase. Operating Determinations • This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. -
Page 7: Connection With The Mains
Spectral M3000 Q4 IP The Spectral can be placed on a flat stage floor or mounted to any kind of truss with a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. Always check if the right color cable is connected to the right place. -
Page 8: Return Procedure
Spectral M3000 Q4 IP Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 9: Description Of The Device
Spectral M3000 Q4 IP Description of the device Features The Spectral M3000 Q4 IP is a LED fixture with high output and great effects. • Input Voltage: 100-240V AC, 60/50Hz • Power consumption: 200W • Light source: 14 x 4-in-1 12W RGBW LED •... -
Page 10: Backside
Spectral M3000 Q4 IP Backside Fig. 02 04) Special 3-pin DMX signal cable IN 05) Special 3-pin power connector 100-240V IN 06) Safety eye 07) Special 3-pin power connector 100-240V OUT 08) Special 3-pin DMX signal cable OUT 09) 4-digit LED display + menu buttons Installation Remove all packing materials from the Spectral M3000 Q4 IP. -
Page 11: Control Modes
Spectral M3000 Q4 IP Control Modes There are 4 modes: • Static Colors (Manual) • Built-in programs (Auto) • Master/Slave • DMX-512 (3CH, 3CH, 4CH, 4CH, 5CH, 6CH, 7CH, 12CH, 17CH) One Spectral (Static Colors) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Plug the end of the electric mains power cord into a proper electric power supply socket. -
Page 12: Multiple Spectrals (Dmx Control)
Spectral M3000 Q4 IP Multiple Spectrals (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the Spectrals and other devices. 04) Link the units as shown in fig. -
Page 13: Fixture Linking
Spectral M3000 Q4 IP Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 14: Control Panel
Spectral M3000 Q4 IP The Spectral M3000 Q4 IP can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) LED display MENU button C) ENTER button D) UP button DOWN button Fig. -
Page 15: Menu Overview
Spectral M3000 Q4 IP Menu Overview Ordercode: 43546... - Page 16 Spectral M3000 Q4 IP Ordercode: 43546...
-
Page 17: Main Menu Options
Spectral M3000 Q4 IP Main Menu Options Static Colors Built-in programs Master/Slave Mode DMX-512 Mode DMX channel modes (personalities) Edit Mode Settings Display lock Calibration menu White color settings (Calibration menu) RGBW calibration settings (Calibration menu) Zoom settings (Calibration menu) 1. -
Page 18: Built-In Programs
Spectral M3000 Q4 IP 2. Built-in programs With this menu, you can set the built-in programs. 01) Press the UP/DOWN buttons until the display shows and press the ENTER button to open the menu. 02) Press the UP/DOWN buttons to choose one of the 10 uneditable built-in programs (AT01-AT10) and 10 editable presets (PR.C1-PR.10) which can be edited in Edit mode (see page 19). -
Page 19: Dmx Channel Modes
Spectral M3000 Q4 IP 5. DMX channel modes With this menu, you can set the desired DMX channel mode (personality). 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle between the following DMX channel modes: TOUR: 12 channels AR2.S:... -
Page 20: Edit Mode
Spectral M3000 Q4 IP 6. Edit Mode With this menu, you can create your own custom shows. 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to choose the desired custom program: PR.C1 – PR.10. 04) Each custom program has 30 scenes, which can be edited. -
Page 21: Settings
Spectral M3000 Q4 IP 7. Settings With this menu you can set the device’s settings. 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle between the following menus: Color, Dimmer, DMX Error, Zoom, Dimming curve, Upload, Restore settings. -
Page 22: Zoom Settings
Spectral M3000 Q4 IP 7.4. Zoom settings 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle between the following 3 options: Zoom, basic position Zoom, 1 position Zoom, 2... -
Page 23: Password
Spectral M3000 Q4 IP 8. Password 01) When the display shows , press the ENTER button to open the menu. 02) Press the UP/DOWN buttons to choose between ON and OFF. 03) If you have selected ON, press the ENTER button to confirm. 04) It will now take 30 seconds for the device to become locked. -
Page 24: Dmx Channels
Spectral M3000 Q4 IP DMX Channels 12 channels (TOUR) Channel 1 – Dimmer intensity 0-255 Gradual adjustment, from dark to brightest 0-100% Channel 2 – Red Dimmer must be open 0-255 Gradual adjustment Red, from 0-100% Channel 3 – Green Dimmer must be open 0-255 Gradual adjustment Green, from 0-100%... -
Page 25: Channels (Arc1)
Spectral M3000 Q4 IP Channel 8 – Built-in programs/Custom programs Dimmer must be open 0-40 Not functional 41-50 Auto 1 51-60 Auto 2 61-70 Auto 3 71-80 Auto 4 81-90 Auto 5 91-100 Auto 6 101-110 Auto 7 111-120 Auto 8 121-130 Auto 9 131-140... -
Page 26: Channels (Ar1.D)
Spectral M3000 Q4 IP 4 channels (AR1.D) Channel 1 – Dimmer intensity 0-255 Gradual adjustment, from dark to brightest 0-100% Channel 2 – Red Dimmer must be open 0-255 Gradual adjustment Red, from 0-100% Channel 3 – Green Dimmer must be open 0-255 Gradual adjustment Green, from 0-100% Channel 4 –... -
Page 27: Channels (Ar2.S)
Spectral M3000 Q4 IP 6 channels (AR2.S) Channel 1 – Dimmer intensity 0-255 Gradual adjustment, from dark to brightest 0-100% Channel 2 – Red Dimmer must be open 0-255 Gradual adjustment Red, from 0-100% Channel 3 – Green Dimmer must be open 0-255 Gradual adjustment Green, from 0-100% Channel 4 –... - Page 28 Spectral M3000 Q4 IP Channel 7 – Blue Dimmer must be open 0-255 Gradual adjustment Blue, from 0-100% Channel 8 – Fine Blue Dimmer must be open 0-255 Fine adjustment Blue, from 0-100% Channel 9 – White Dimmer must be open 0-255 Gradual adjustment White, from 0-100% Channel 10 –...
-
Page 29: Channels (Ar2.Z)
Spectral M3000 Q4 IP 161-170 PR.03 171-180 PR.04 181-190 PR.05 191-200 PR.06 201-210 PR.07 211-220 PR.08 221-230 PR.09 231-255 PR.10 Channel 14 – Auto speed CH13 must be set between 41-140 0-255 Speed adjustment, from slow to fast Channel 15 – Dimmer speed Preset dimmer speed from the device’s menu 10-29 Linear dimmer... -
Page 30: Maintenance
Suspect two potential problem areas as: the power supply or the LEDs. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the Spectral to your Showtec dealer. 03) If both of the above appear to be O.K., plug the unit in again. - Page 31 Internal fuse blown • Return the device to your local Showtec dealer. Fixtures reset The controller is not connected. • Connect controller. correctly, but all 3-pin XLR Out of the controller •...
-
Page 32: Product Specifications
Spectral M3000 Q4 IP Product Specifications Model: Showtec Spectral M3000 Q4 IP Input Voltage: 100-240 VAC, 60/50Hz Power consumption: 200W (full output) DMX linking: 30pcs Dimensions: 250 x 275 x 375 mm (LxWxH) Weight: 8,9 kg Operating and Programming: Signal pin OUT:... -
Page 33: Dimensions
Spectral M3000 Q4 IP Dimensions Ordercode: 43546... -
Page 34: Notes
Spectral M3000 Q4 IP Notes Ordercode: 43546... - Page 35 Spectral M3000 Q4 IP Ordercode: 43546...
- Page 36 ©2015 Showtec...
