Spectral M3000 Q4 IP

DMX Channels

12 channels (TOUR)

Channel 1 – Dimmer intensity
0-255 Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Red Dimmer must be open
0-255 Gradual adjustment Red, from 0-100%
Channel 3 – Green
0-255 Gradual adjustment Green, from 0-100%
Channel 4 – Blue Dimmer must be open
0-255 Gradual adjustment Blue, from 0-100%
Channel 5 – White
0-255 Gradual adjustment White, from 0-100%
Channel 6 – Macros
0-10 Not functional
11-30 Red 100% / Green Up / Blue 0%
31-50 Red Down / Green 100% / Blue 0%
51-70 Red 0% / Green 100% / Blue Up
71-90 Red 0% / Green Down / Blue 100%
91-110 Red Up / Green 0% / Blue 100%
111-130 Red 100% / Green 0% / Blue Down
131-150 Red 100% / Green Up / Blue Up
151-170 Red Down / Green Down / Blue 100%
171-200 Red 100% / Green 100% / Blue 100% / White 100%
201-205 White 1: 3200K
206-210 White 2: 3400K
211-215 White 3: 4200K
216-220 White 4: 4900K
221-225 White 5: 5600K
226-230 White 6: 5900K
231-235 White 7: 6500K
236-240 White 8: 7200K
241-245 White 9: 8000K
246-250 White 10: 8500K
251-255 White 11: 10000K
Channel 7 – Strobe
0-9 Not functional
10-255 Strobe flash frequency, from slow to fast
Ordercode: 43546
Dimmer must be open
Dimmer must be open
Dimmer must be open
Dimmer must be open
23
