- Page 1 Twin Cavity Cooker/ User Manual BFSG51TCWHLPG BFSG51TCBKLPG BFSG51TCBKNG...
- Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ....................4 1.2 Installation Warnings ......................7 1.3 During Use ........................8 1.4 During Cleaning and Maintenance ................10 2.INSTALLATION AND PREPARATION FOR USE ............12 2.1 Instructions for the Installer ..................12 2.2 Installation of the Cooker ....................13 2.3 Gas Connection ......................13 2.4 Gas Conversion (If available) ..................14 2.5 Electrical Connection and Safety (If available) .............16... -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within. - Page 5 WARNING: Danger of fire: Do not store items on the cooking surfaces. WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. • For models which incorporate a hob lid, clean any spillages off the lid before use and allow the cooker to cool before closing the lid.
- Page 6 applicable local and international standards and regulations. • Maintenance and repair work should only be carried out by authorised service technicians. Installation and repair work that is carried out by unauthorised technicians may be dangerous. Do not alter or modify the specifications of the appliance in any way.
-
Page 7: Installation Warnings
the technical instructions which describe how to modify the appliance to match the conditions of use of the country. • All possible measures have been taken to ensure your safety. Since the glass may break, care should be taken while cleaning to avoid scratching. Avoid hitting or knocking the glass with accessories. -
Page 8: During Use
In the case of a defect do not use the appliance and contact a qualified service agent immediately. The materials used for packaging (nylon, staplers, styrofoam, etc.) may be harmful to children and they should be collected and removed immediately. •... - Page 9 very hot and damage may be caused to the product. Do not leave the cooker unattended when cooking with solid or liquid oils. They may catch fire under extreme heating conditions. Never pour water on to flames that are caused by oil, instead switch the cooker off and cover the pan with its lid or a fire blanket.
-
Page 10: During Cleaning And Maintenance
with the oven door closed. CAUTION: Glass lids may shatter when heated. Turn off all the burners and allow the hob surface to cool before closing the lid. • Do not place anything on the oven door when it is open. This could unbalance the oven or damage the door. - Page 11 CE Declaration of conformity We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced. This appliance has been designed to be used only for home cooking. Any other use (such as heating a room) is improper and dangerous.
-
Page 12: Installation And Preparation For Use
2. INSTALLATION AND Gas appliances expel burned gas waste to the outside air, either directly or via a PREPARATION FOR USE cooker hood with a chimney. If it is not WARNING : This appliance must be possible to install a cooker hood, install a installed by an authorised service fan on the window or wall that has access to fresh air. -
Page 13: Installation Of The Cooker
vicinity, such as curtains, oil, cloth etc. appliance for air circulation. which may catch fire. • There should be a minimum 2cm blank • The worktop and furniture surrounding space around the appliance for air the appliance must be made of circulation. -
Page 14: Gas Conversion (If Available)
collar. If you need to use it in another country, any of the connections in the figure below • Connect your appliance with a short may be required. In such a case, contact and durable hose that is as close as local authorities to learn the correct gas possible to the gas source. - Page 15 lowing steps should be performed: the type of gas that is going to be used, Changing injectors according to the information chart (which is also supplied in the gas conversion kit). Hob burners Oven Injector • Cut off the main gas supply and unplug the appliance from the mains electrical The oven burner is held in its cradle by supply.
-
Page 16: Electrical Connection And Safety (If Available)
from LPG to natural gas. For conversion and/or international authorities. In all gas from natural gas to LPG, the bypass screw connections, refer to the “Assembly of must be tightened. gas supply and leakage check” clause explained above. Valve without flame Valve with flame failure failure device device... -
Page 17: Anti-Tilting Kit
• Fix the supply cable in the cable clamp Product Dimensions and then close the cover. A (mm) B (mm) (Width X Depth X Height) (Cm) • The terminal box connection is placed 60x60x90 (Double Oven) 297.5 on the terminal box. 50x60x90 (Double Oven) 247.5 90x60x85... -
Page 18: Product Features
3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Cooktop 2. Control Panel 3. Top Oven Door Handle 4. Top Oven Door 5. -
Page 19: Use Of Product
4. USE OF PRODUCT Oven / Grill (If available) Burners Regardless of the model of your appliance, all oven burners are equipped with a gas 4.1 uSe of GaS burnerS safety device. For this reason, during Ignition of the Burners ignition, keep the oven knob pressed until The position symbol above each control you see stable flames. -
Page 20: Main Oven Controls
could cause serious burns. • Do not allow pan handles or any other cooking utensils to project over the edge of the cooker top. Crown Spark plug Burner To switch the hob burners off, turn the hob burner knob clockwise to the ‘0’ position or so that the marker on the hob burner knob points upwards. -
Page 21: Top Oven Controls
4.4 top oven ControlS Position Temperature(°C) Top Oven Grill Burner Controls Function Description Turn the grill burner control ..knob counter-clockwise to set to the required flame setting. CAUTION: Accessible parts may become hot while the grill is in use. Young children should be kept away. -
Page 22: Accessories
minutes before sealing steaks or toasting. rack in the oven cavity correctly and push it Food should be turned during cooking, as to the end. required. Food should be thoroughly dried before grilling to minimize splashing. Brush lean meats and fish lightly with a little oil or melted butter to keep them moist during cooking. - Page 23 Cleaning the Stainless Steel Parts (if available) • Clean the stainless steel parts of your appliance on a regular basis. • Wipe the stainless steel parts with a soft cloth soaked in only water. Then, dry them thoroughly with a dry cloth. Do not clean the stainless steel parts while they are still hot from cooking.
-
Page 24: Maintenance
Replaceable light source by a professional 3. Close the door until it almost reaches the fully closed position and remove the door The lamp is designed specifically for by pulling it towards you. use in household cooking appliances. It is not suitable for household room illumination. -
Page 25: Troubleshooting&Transport
6. TROUBLESHOOTING&TRANSPORT 6.1 troubleShootinG If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution The oven and/or grill may be in the ´off` position. -
Page 26: Transport
6.2 tranSport If you need to transport the product, use the original product packaging and carry it using its original case. Follow the transport signs on the packaging. Tape all independent parts to the product to prevent damaging the product during transport. If you do not have the original packaging, prepare a carriage box so that the appliance, especially the external surfaces of the product, is protected against external threats. -
Page 27: Technical Specifications
7. TECHNICAL SPECIFICATIONS 7.1 injeCtor table G30 28-30 mbar 11,9 kW 865,3 g/h II2H3+ IE Class:1 G20/20 mbar G30/28 mbar LARGE BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (KW) CONSUMPTION 276,2 l/h 218,1 g/h MEDIUM BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (KW) 1,75 1,75... -
Page 28: Energy Fiche
7.2 enerGy fiChe Brand Model BFSG51TCWHLPG BFSG51TCBKLPG BFSG51TCBKNG Type of Oven Mass 40,7 Energy Efficiency Index - conventional Energy Efficiency Index - fan forced Energy Class Energy consumption (gas) - conventional MJ/cycle - kWh/cycle Energy consumption (gas) - fan forced... - Page 29 Brand Model BFSG51TCWHLPG BFSG51TCBKLPG BFSG51TCBKNG Type of Hob Number of Cooking Zones Heating Technology-1 Size-1 Auxiliary Energy Efficiency-1 Heating Technology-2 Size-2 Semi-Rapid Energy Efficiency-2 59,0 Heating Technology-3 Size-3 Semi-Rapid Energy Efficiency-3 59,0 Heating Technology-4 Size-4 Rapid Energy Efficiency-4 57,0 Energy Efficiency of Hob...
- Page 30 General Warranty Terms 1. That it is used for domestic purposes and in a residential address only. 2. That it has been installed and used in accordance with the instruction manual and any separate installation instructions provided. That it has been properly connected to mains supplied electricity, gas and water and drainage as appropriate.
- Page 31 11. Deal with any noise, vibration or steam resulting from the normal operation of the appliance. These include periodic start and running of fans, flow and drain pump, steam from a washer, dryer, dishwasher and oven. 12. Reverse door hinges on cooling appliances. 13.
- Page 32 Your Belling Appliance is guaranteed against breakdown for an initial period of 12 months from date of purchase (for guarantee conditions please refer to your instruction booklet) Your standard one year guarantee is extended for an additional 12 months when you register the product within 28 days of purchase with Glen Dimplex Ireland.
