PRODUCT ASSEMBLY

E
Fix the fender.
Clip the fender into the front bracket and fix it with M4 * 10mm round
head screw.
C
Fix the wheel trim(L/R).
Clip the wheel trim into the front bracket and fix it with M4
* 10mm flat head screw.(Note: Install as shown in the figure, the
wheel trim is divided into left and right sides)
G
Fix the steering wheel.
Clip the steering wheel into the front bracket and fix it with M8 *
55mm screws and M8 nuts with M8 wrench.
D
Fix the steering wheel pressure block.
Clip the steering wheel pressure block into the front bracket and fix it
with M4 * 10mm round head screw.
