FMA202 First Start
Main Page
>
EOL Products
FMA202 Small and professional waterproof tracker with high gain internal
GNSS/GSM antennas and high capacity internal Ni-MH battery
Quick Start Guide
How to insert micro SIM card into FMA202
1.
Open FMA202 case using screwdriver.
2.
Remove FMA202 case.
3.
Insert SIM card as shown.
4.
Connect battery connector as shown.
5.
Attach case, and screw in the screws.
6.
Device is ready.
Cable colors
Wire color
Pin name
Red
VCC (6-30)V DC (+)
Black
GND (-)
Yellow
DIN 1
White/Green DIN 2
White
DIN 3
Grey
AIN 1
White/Orange DOUT 1
Violet
DOUT 2
Green
1WIRE DATA
Blue
1WIRE POWER
>
FMA202
> FMA202 First Start
Description
Power supply (+6...30 V DC).
Ground.
Digital input, channel 1.
Digital input, channel 2.
Digital input, channel 3.
Analog input, channel 1. Input range: 0-30 V DC.
Digital output, channel 1. Open collector output. Max. 3,3
A DC.
Digital output, channel 2. Open collector output. Max. 3,3
A DC.
Data channel for 1–Wire devices.
+3,8 V output for 1–Wire devices.
Advertisement
Table of Contents
Related Manuals for Teltonika FMA202
Summary of Contents for Teltonika FMA202
- Page 1 EOL Products > FMA202 > FMA202 First Start FMA202 Small and professional waterproof tracker with high gain internal GNSS/GSM antennas and high capacity internal Ni-MH battery Quick Start Guide How to insert micro SIM card into FMA202 Open FMA202 case using screwdriver.
- Page 2 GSM operator's information. If device GSM is unavailable, the device will not be able to send the data and FMA202 will start storing records to flash memory. It is possible to store up to 3500 data records. It will send data over GPRS when it is available.
- Page 3 FMA202 has 2 configuration modes: Recommended Configuration. And Advanced Configuration . FMA202 Configurator is divided into main areas: 1 – main button area, 2 – information area, 3 –settings menu, 4 – parameters and values menu, 5 – recommended configuration values. Button 6 is used to change between configuration modes.
- Page 4 (metal free) with not less than ¾ of metal free area as shown in figure below. FMA202 FMA202 has IP67 protection class. Top performance is reached if mounted outside of the vehicle. The device has 4 mounting holes on the edges, and can be tightened with screws, adhesive tape or plastic straps.
- Page 5 FMA202 and even its failure. Safety information This message contains information on how to operate FMA202 safely. By following these requirements and recommendations, you will avoid dangerous situations. You must read these instructions carefully and follow them strictly before operating the device! The device uses SELV limited power source.
