Page 1 6E128-26, 6E138-25, 6E129-26 and 6E139-25 SmartSwitch 6000 Interface Modules Ethernet 6E128-26 6E128-26 9032311-03 User’s Guide Ethernet Ethernet 6E138-25 6E129-26 6E138-25 6E129-26 Ethernet 6E139-25 6E139-25...
Page 2 9032311-03...
Page 3: Fcc Notice
NOTICE Cabletron Systems reserves the right to make changes in speciﬁcations and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, ﬁrmware, or software described in this manual is subject to change without notice. IN NO EVENT SHALL CABLETRON SYSTEMS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS MANUAL OR...
Page 4: Industry Canada Notice
Notice INDUSTRY CANADA NOTICE This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté...
Page 5 CABLETRON SOFTWARE PROGRAM LICENSE LICENSE. You have the right to use only the one (1) copy of the Program provided in this package subject to the terms and conditions of this License Agreement. You may not copy, reproduce or transmit any part of the Program except as permitted by the Copyright Act of the United States or as authorized in writing by Cabletron.
Page 6: Declaration Of Conformity
Notice DECLARATION OF CONFORMITY Application of Council Directive(s): Manufacturer’s Name: Manufacturer’s Address: European Representative Name: European Representative Address: Conformance to Directive(s)/Product Standards: Equipment Type/Environment: We the undersigned, hereby declare, under our sole responsibility, that the equipment packaged with this notice conforms to the above directives. Manufacturer Mr.
Page 7: Table Of Contents
CHAPTER 1 INTRODUCTION Using This Guide ... 1-1 Structure of This Guide... 1-1 6E12X-26 and 6E13X-25 Overview... 1-2 1.3.1 Connectivity ... 1-4 1.3.2 Full Duplex Switched Ethernet... 1-4 1.3.3 Management ... 1-4 1.3.4 Switching Options ... 1-5 1.3.5 Standards Compatibility ... 1-5 1.3.6 LANVIEW Diagnostic LEDs ...
Page 8 Contents Connecting to the Network...3-5 3.6.1 Connecting Fiber Optic Cables to Ports 1 Through 24 of the Modules ...3-6 3.6.2 Connecting a UTP Segment to the FE-100TX ...3-8 3.6.3 Connecting a Fiber Optic Segment to the FE-100FX and FE-100F3 ...3-9 Completing the Installation...3-11 CHAPTER 4 TROUBLESHOOTING...
Page 9 5.16.1 Establishing Community Names ... 5-59 5.17 SNMP Traps Screen... 5-60 5.17.1 Configuring the Trap Table ... 5-61 5.18 Switch Configuration Screen ... 5-62 5.18.1 Setting the STA... 5-65 5.18.2 Setting the Age Time ... 5-65 5.18.3 Setting (Enabling or Disabling) the Port Status ... 5-65 5.19 Ethernet Full Duplex Configuration Screen ...
Page 10 5.24.2 Changing Source and Destination Ports ...5-87 5.25 Broadcast Suppression Screen ...5-89 5.25.1 Setting the Threshold ...5-90 5.25.2 Setting the Reset Peak Switch ...5-91 5.26 Module Statistics Menu Screen ...5-91 5.27 Switch Statistics Screen...5-93 5.27.1 Using the Clear Counters Command ...5-94 5.28 The Interface Statistics Screen ...5-95...
Page 11 APPENDIX C MODE SWITCH BANK SETTINGS AND OPTIONAL INSTALLATIONS Required Tools ...C-1 Setting the Mode Switch...C-1 Installing Optional Fast Ethernet Interface Modules...C-4 INDEX 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide Contents...
Page 12 Contents 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide...
Page 13: Chapter 1 Introduction
Welcome to the Cabletron Systems 6E128-26, 6E138-25, 6E129-26 and 6E139-25 SmartSwitch 6000 Interface Modules User’s Guide. This guide describes the 6E128-26, 6E138-25, 6E129-26 and 6E139-25 Interface Modules and provides information concerning network requirements, installation, troubleshooting, and the use of Local Management.
Page 14: 6E12X-26 And 6E13X-25 Overview
The 6E12X-26 and 6E13X-25, shown in modules for Cabletron Systems 6C105 SmartSwitch 6000 chassis. The 6E12X-26 and 6E13X-25 are high-speed network switch devices that support 802.1D switching (bridging), 802.1Q switching, and Cabletron Systems SecureFast Switching Virtual Network technology. Ports 25 and...
Page 15 Ethernet 6E128-26 Network Ports 1-24 Fast Ethernet Interface Module Ports 25 and 26 Figure 1-1 The 6E128-26 and 6E138-25 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide 6E12X-26 and 6E13X-25 Overview Ethernet 6E138-25 COM Ports System LEDs Port Status LEDs Network Ports 1-24 HSIM Slot 231101...
Page 16: Connectivity
Chapter 1: Introduction 1.3.1 Connectivity The 6E128-26 and 6E138-25 connect to Ethernet networks or workstations through 24 ST ﬁber optic ports on the front panel. These ports support multimode ﬁber optic cables at lengths up to 2 kilometers. The ports are IEEE 802.3 10BASE-F compliant. The 6E129-26 and 6E139-25 connect to Ethernet networks or workstations through 24 ST ﬁber optic ports on the front panel.
Page 17: Switching Options
1.3.4 Switching Options The 6E12X-26 and 6E13X-25 provide 802.1D switching (bridging), 802.1Q switching or SecureFast Switching Virtual Network Services between all of the front panel interfaces including Fast Ethernet Interface Modules and High Speed Interface Modules (HSIMs). SecureFast switching and 802.1Q switching allow for future migration to Virtual Network technologies without requiring the replacement of existing equipment.
Page 18: Runtime Ip Address Discovery
Chapter 1: Introduction 1.3.8 Runtime IP Address Discovery This feature enables the modules to automatically accept an IP address from a BootP server on the network into NVRAM without requiring a user to enter an IP address through Local Management. When the modules are connected to the network and powered up, Runtime IP Address Discovery (RAD) checks the modules for an IP address.
Page 19: Remote Monitoring (Rmon)
1.4.2 Remote Monitoring (RMON) The 6E12X-26 and 6E13X-25 supports all Ethernet RMON groups, which include Statistics, Alarms, Events and History. These groups are enabled on all ports by default. Cabletron Systems RMON Actions is a vendor speciﬁc extension of RMON and provides the ability to set an “Action” on any SNMP MIB variable.
Page 20: Smarttrunk
Chapter 1: Introduction 1.4.5 SmartTrunk SmartTrunk, also referred to as SmartTrunking, is Cabletron Systems’ terminology for load balancing or load sharing. SmartTrunk technology provides an easy-to-implement mechanism to group, or aggregate, multiple links of any technology together to scale the backbone bandwidth beyond the limitations of a single link.
Page 21: Optional Features
OPTIONAL FEATURES Options for the 6E12X-26 and 6E13X-25 are Fast Ethernet Interface Modules and High Speed Interface Modules, which add remote uplink capability. Cabletron Systems provides Fast Ethernet Interface Modules for the 6E12X-26 to support uplinks to 100 Mbps Ethernet backbones or high speed connections to local servers.
Page 22: Document Conventions
Chapter 1: Introduction DOCUMENT CONVENTIONS The following conventions are used throughout this document: Note symbol. Calls the reader’s attention to any item of NOTE information that may be of special importance. Tip symbol. Conveys helpful hints concerning procedures or actions. Caution symbol.
Page 23: Getting Help
GETTING HELP For additional support related to this device or document, contact the Cabletron Systems Global Call Center: World Wide Web Phone Internet mail Login Password To send comments or suggestions concerning this document, contact the Cabletron Systems Technical Writing Department via the following email address: TechWriting@ctron.com Make sure to include the document Part Number in the email message.
Page 24: Related Manuals
Chapter 1: Introduction RELATED MANUALS The following manuals may help to set up, control, and manage the 6E12X-26 and 6E13X-25: Cabletron Systems HSIM-A6DP User’s Guide Cabletron Systems HSIM-F6 User’s Guide Cabletron Systems HSIM-FE6 User’s Guide Cabletron Systems HSIM-W6 User’s Guide Cabletron Systems HSIM-W84 User’s Guide Cabletron Systems HSIM-W87 User’s Guide Cabletron Systems HSIM-G01/G09 User’s Guide...
Page 25: Chapter 2 Network Requirements
NETWORK REQUIREMENTS Before installing the 6E12X-26 and 6E13X-25 or Fast Ethernet Interface Modules (FE-100TX, FE-100FX, or FE-100F3), review the requirements and speciﬁcations referred to in this chapter concerning the following: • SmartTrunk (Section • 10BASE-F Fiber Optic Network • FOIRL Single Mode Fiber Optic Network •...
Page 26: 10Base-F Network
Chapter 2: Network Requirements 10BASE-F NETWORK When connecting a 10BASE-F segment to any of the 6E128-26 and 6E138-25 ports (Interfaces 1 through 24), ensure that the network meets the Ethernet network requirements of the IEEE 802.3 standard for 10BASE-F. Refer to the Cabletron Systems Cabling Guide for details. FOIRL NETWORK When connecting a FOIRL single mode segment to any of the 6E129-26 and 6E139-25 ports (Interfaces 1 through 24), ensure that the network...
Page 27: Installation
Only qualiﬁed personnel should install the 6E12X-26 and 6E13X-25. This chapter covers the following items: • Required tools • Unpacking the 6E12X-26 and 6E13X-25 • Power Supply requirements speciﬁc to the 6E12X-26 and 6E13X-25 • Installing the 6E12X-26 and 6E13X-25 into the 6C105 chassis •...
Page 28: 6E12X-26 And 6E13X-25 Options
Chapter 3: Installation 6E12X-26 AND 6E13X-25 OPTIONS Install any optional equipment before proceeding to NOTE Section 3.5. If the 6E12X-26 is to be installed with an optional Fast Ethernet Interface Module, refer to Appendix C instructions for the HSIMs available for the 6E13X-25 are located in the associated user’s guide.
Page 29: Installing The 6E12X-26 And 6E13X-25 Into The 6C105 Chassis
Installing the 6E12X-26 and 6E13X-25 Into the 6C105 Chassis INSTALLING THE 6E12X-26 AND 6E13X-25 INTO THE 6C105 CHASSIS Failure to observe static safety precautions could cause damage to the 6E12X-26 and 6E13X-25. Follow static safety CAUTION handling rules and properly wear the antistatic wrist strap provided with the 6C105 chassis.
Page 30 Chapter 3: Installation Locate the slot guides that line up with the number of the slot in which the module will be installed. Install the module in the chassis by aligning the module circuit card between the upper and lower metal rail guides of the desired slot, sliding it into the chassis, and locking down the top and bottom plastic locking tabs, as shown in Take care that the module slides in straight and properly engages the...
Page 31: Connecting To The Network
CONNECTING TO THE NETWORK This section provides the procedures for connecting ﬁber optic or Unshielded Twisted Pair (UTP) segments from the network or other devices to the modules. Ports 1 through 24 on the 6E128-26 and 6E138-25 have ST connectors for multimode ﬁber optic connections.
Page 32: Connecting Fiber Optic Cables To Ports
Chapter 3: Installation 3.6.1 Connecting Fiber Optic Cables to Ports 1 Through 24 of the Modules Each ﬁber optic link consists of two strands of ﬁber optic cabling: the transmit (TX) and the receive (RX). The transmit strand from a module port connects to the receive port of a ﬁber optic Ethernet device at the other end of the segment.
Page 33 At the other end of the fiber optic cable, attach the fiber pair to the transmit and receive ports of the device. Figure 3-2 Fiber Optic Connection Verify that a Link exists by checking that the port RX LED is on (flashing amber, blinking green, or solid green).
Page 34: Connecting A Utp Segment To The Fe-100Tx
Fast Ethernet Interface Module crossover switch shown in marked with =. A schematic of a crossover cable is shown in not cross over, use the switch on the FE-100TX to internally cross over the RJ45 port. Figure 3-3 crossover switch.
Page 35: Connecting A Fiber Optic Segment To The Fe-100Fx And Fe-100F3
Make sure that the twisted pair connection meets dB loss and cable specifications outlined in Confirm that the crossover switch is in the correct position. If a Link is not established, contact the Cabletron Systems Global Call Center. Refer to Section 3.6.3...
Page 36 Chapter 3: Installation Do not touch the ends of the ﬁber optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of the ends causes problems in data CAUTION transmissions. If the ends become contaminated, blow the surfaces with a canned duster.
Page 37: Completing The Installation
The port RX LED ﬂashes green and amber during bootup. NOTE Check that the power is turned on for the device at the other end of the link. Verify proper crossing over of fiber strands between the applicable port on the 6E12X-26 and the fiber optic device at the other end of the fiber optic link segment.
Page 38 Chapter 3: Installation 3-12 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide...
Page 39: Chapter 4 Troubleshooting
TROUBLESHOOTING This chapter provides information concerning the following: • Using the LANVIEW diagnostic and status monitoring system • Using the FE-100TX LED • Troubleshooting network and module operational problems • Using the RESET button The four interface modules covered in this manual all share the NOTE same LANVIEW LEDs.
Page 40 Chapter 4: Troubleshooting CPU LED 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide Ethernet 6E128-26 231104 Figure 4-1 LANVIEW LEDs Receive (RX) Transmit (TX)
Page 41 Color Amber Green Amber Green Green Amber 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide Table 4-1 LANVIEW LEDs State Power off. Blinking. Hardware failure has occurred. Solid. Resetting, normal power up reset. Blinking. Crippled. Solid. Testing. Solid. Functional. Booting. Blinks amber and green while booting.
Page 42: Fe-100Tx Led
Chapter 4: Troubleshooting Table 4-1 LANVIEW LEDs (Continued) Color Green Amber FE-100TX LED The optional FE-100TX has one LED labeled 10/100. The 10/100 LED together with the receive LED allows the user to determine the link status and the operating speed of the Fast Ethernet Interface Module. The 10/100 LED and the Receive (RX) LED are shown in Table 4-2 Table 4-3...
Page 43 100 LED A link exists if the associated port (port 25 or 26) Receive (RX) NOTE LED is on. Table 4-2 FE-100TX LED Indications When the RX LED Is On Color 10/100 Green No link exists if the associated port (port 25 or 26) Receive NOTE (RX) LED is off.
Page 44: Troubleshooting Checklist
Port(s) goes into 6E12X-26 or 6E13X-25 standby for no detects a looped apparent reason. condition. User parameters (IP Mode switch (7), NVRAM address, Device and Reset, was changed Module name, etc.) sometime before either were lost when the cycling power or...
Page 45: Using The Reset Button
USING THE RESET BUTTON The RESET button located near the upper plastic locking tab of the module (refer to Figure processor without affecting the NVRAM. Pressing the RESET button resets the device, and all current switching being performed by the device is halted. A module CAUTION downtime of up to two minutes will result from this action.
Page 46 Chapter 4: Troubleshooting 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide...
Page 47: Chapter 5 Local Management
6E12X-26, 6E13X-25 and the 6C105 chassis. • Monitor the environmental status of the 6C105 chassis. • View switch, interface, and RMON statistics. • Assign ports to operate in standard or full duplex mode. • Enable trunking of ports to perform load sharing.
Page 48: Local Management Keyboard Conventions
Chapter 5: Local Management There are three ways to access Local Management: • Locally using a VT type terminal connected to the COM port of the 6E13X-25 or 6E12X-26. • Remotely using a VT type terminal connected through a modem. •...
Page 49: Management Terminal Setup
MANAGEMENT TERMINAL SETUP Use one of the following systems to access Local Management: • An IBM or compatible PC running a VT series emulation software package • A Digital Equipment Corporation VT100 type terminal • A VT type terminal running emulation programs for the Digital Equipment Corporation VT100 series •...
Page 50: Connecting An Uninterruptible Power Supply
Chapter 5: Local Management 5.3.2 Connecting an Uninterruptible Power Supply If the 6C105 chassis is connected to an American Power Conversion (APC) Uninterruptible Power Supply (UPS) for protection from a loss of power, a connection from the COM port of a module to the UPS can be made to monitor the power status of the UPS.
Page 51: Management Terminal Setup Parameters
5.3.3 Management Terminal Setup Parameters Table 5-2 lists the setup parameters for the local management terminal. Display Setup Menu Columns -> Controls -> Auto Wrap -> Scroll -> Text Cursor -> Cursor Style -> General Setup Menu Mode -> ID number -> Cursor Keys ->...
Page 52: Telnet Connections
Chapter 5: Local Management 5.3.4 Telnet Connections Once the module or chassis has a valid IP address, the user can establish a Telnet session with Local Management from any TCP/IP based node on the network. Telnet connections to the 6E12X-26 and 6E13X-25 require the community name passwords assigned at the SNMP Community Names screen of either the 6C105 chassis, or the module.
Page 53: Accessing Local Management
ACCESSING LOCAL MANAGEMENT Access to Local Management is controlled through the Password screen, Figure 5-3. Whenever a connection is made to the 6E12X-26 and 6E13X-25 the Password screen displays. Before continuing, the user must enter a password which is compared to the previously stored passwords. The level of access allowed the user depends on the password.
Page 54: Navigating Local Management Screens
Refer to the Release Notes shipped with the product to verify NOTE which screens are supported in each of the three available switching modes. The switch operational mode may be set in either the Chassis Conﬁguration screen (Section of the module...
Page 55 General Configuration SNMP Community Names SNMP Traps Chassis Environmental Port Redirect Function Module General Configuration Configuration SNMP Community Names Menu SNMP Traps Switch Configuration Ethernet Full Duplex Configuration SmartTrunk Configuration Module Specific Configuration Switch Statistics Module Interface Statistics Statistics RMON Statistics...
Page 56: Selecting Local Management Menu Screen Items
Chapter 5: Local Management Chassis Menu Password Main Menu Module Menu Figure 5-6 SecureFast VLAN Mode, LM Screen Hierarchy 5.4.2 Selecting Local Management Menu Screen Items Select items on a menu screen by performing the following steps: Use the arrow keys to highlight a menu item. Press ENTER.
Page 57 Using the RETURN Command To exit an LM screen using the RETURN command, proceed as follows: Use the arrow keys to highlight the RETURN command at the bottom of the Local Management screen. Press ENTER. The previous screen in the Local Management hierarchy displays.
Page 58: The Main Menu Screen
Chapter 5: Local Management THE MAIN MENU SCREEN The Main Menu screen is the access point for all Local Management screens for the module and the 6C105 chassis. Menu screen. If the terminal is idle for several minutes, the Local NOTE Management Password screen displays and the session ends.
Page 59 The Main Menu Screen The following explains each Main Menu screen item as shown in Figure 5-7: CHASSIS The Chassis menu item provides access to the Chassis Menu screen, shown in Figure 5-8, that is used to conﬁgure the 6C105 chassis, access current chassis power supply and environmental status, and to conﬁgure IEEE 802.1Q VLANs.
Page 60: Chassis Menu Screen
Chapter 5: Local Management CHASSIS MENU SCREEN The Chassis Menu screen, Management screens that allow you to conﬁgure and monitor operating parameters, modify SNMP community names, set SNMP traps, monitor the 6C105 environmental status, perform port redirect functions, and to conﬁgure the 6C105 for IEEE 802.1Q operation.
Page 61: Snmp Traps
Chassis Menu Screen SNMP TRAPS The SNMP Traps screen provides display and conﬁguration access to the table of IP addresses used for trap destinations and associated community names. For details, refer to Section 5.9. CHASSIS ENVIRONMENTAL The Chassis Environmental screen provides access to chassis power supply status, power supply redundancy status and chassis fan tray status.
Page 62: Chassis Configuration Screen
Chapter 5: Local Management CHASSIS CONFIGURATION SCREEN The Chassis Conﬁguration screen, chassis date and time, IP address and Subnet Mask, the operational mode of all modules installed in the chassis, the screen refresh and lockout times, and to view the chassis uptime. Access the Chassis Conﬁguration screen from the Chassis Menu screen by using the arrow keys to highlight the CHASSIS CONFIGURATION menu item and pressing ENTER.
Page 63 IP Address (Modiﬁable) This ﬁeld allows the IP address to be set for the 6C105 chassis. If an IP address is assigned to the 6C105 chassis all the interface modules installed in the chassis can be managed via this IP address, eliminating the need to assign an IP address to each interface module.
Page 64: Setting The Ip Address
Chapter 5: Local Management Screen Lockout Time (Modiﬁable) Contains the maximum number of minutes that the Local Management application displays a module’s screen while awaiting input or action from a user. For example, if the number 5 is entered in this ﬁeld, the user has up to ﬁve minutes to respond to each of the speciﬁed module’s Local Management screens.
Page 65: Setting The Subnet Mask
Press ENTER. If the IP address is a valid format, the cursor returns to the beginning of the IP address field. If the entry is not valid, the Event Message Line displays “INVALID IP ADDRESS OR FORMAT ENTERED”. Local Management does not alter the current value and refreshes the IP address field with the previous value.
Page 66: Setting The Chassis Date
Chapter 5: Local Management 5.7.3 Setting the Chassis Date The 6C105 is year 2000 compliant, so the Chassis Date may be set beyond the year 1999. To set the chassis date, perform the following steps: Use the arrow keys to highlight the Chassis Date field. Enter the date in this format: MM/DD/YYYY It is not necessary to add separators between month, day, and NOTE...
Page 67: Entering A New Screen Refresh Time
Use the arrow keys to highlight the SAVE command at the bottom of the screen and press ENTER. If the time entered is a valid format, the Event Message Line at the top of the screen displays “SAVED OK”. If the entry is not valid, Local Management does not alter the current value and refreshes the Chassis Time ﬁeld with the previous value.
Page 68: Setting The Operational Mode
Chapter 5: Local Management If the time entered is within the 1 to 30 minutes range, the Event Message Line at the top of the screen displays “SAVED OK”. If the entry is not valid, Local Management does not alter the current setting, but it does refresh the Screen Lockout Time ﬁeld with the previous value.
Page 69 Chassis Conﬁguration Screen If the 6E12X-26 and 6E13X-25 have been set to 802.1Q NOTE SWITCHING, refer to your Port Based VLAN User’s Guide to conﬁgure the devices for this type of operation. The Operational Mode ﬁeld in the Chassis Conﬁguration screen does not support the SECURE FAST VLAN operational mode.
Page 70: Snmp Community Names Screen
Chapter 5: Local Management SNMP COMMUNITY NAMES SCREEN The SNMP Community Names menu item allows the user to set Local Management community names. Community names act as passwords to Local/Remote Management and provide security access to the 6C105. Access to the 6C105 is controlled by enacting any of three different levels of security authorization (read-only, read-write, and super-user).
Page 71: Establishing Community Names
The following explains each SNMP Community Names screen ﬁeld: Community Name (Modiﬁable) Displays the user-deﬁned name through which a user accesses 6C105 management. Any community name assigned here acts as a password to Local/Remote Management. Access Policy (Read-Only) Indicates the access accorded each community name. Possible selections are as follows: read-only read-write...
Page 72 Chapter 5: Local Management All passwords assigned in the 6C105 SNMP Community NOTE Names screen allow access to both 6C105 Local Management screens, and the Local Management screens of the interface modules that are installed in the chassis. To conﬁgure the interface module to not allow access to 6C105 Local Management screens refer to To establish community names, proceed as follows:...
Page 73: Snmp Traps Screen
SNMP TRAPS SCREEN Since the 6C105 is an SNMP compliant device, it can send messages to multiple Network Management Stations to alert users of status changes. The SNMP Traps screen is shown in Access the SNMP Traps screen from the Chassis Menu screen by using the arrow keys to highlight the SNMP TRAPS menu item and pressing ENTER.
Page 74: Configuring The Trap Table
Chapter 5: Local Management Enable Traps (Toggle) Enables transmission of the traps to the network management station with the associated IP address. This ﬁeld toggles between YES and NO. 5.9.1 Conﬁguring the Trap Table To conﬁgure the Trap table, proceed as follows: Using the arrow keys, highlight the appropriate Trap Destination field.
Page 75: Chassis Environmental Screen
5.10 CHASSIS ENVIRONMENTAL SCREEN The Chassis Environmental menu item allows the user to view chassis environmental information. To access the Chassis Environmental Information screen from the Chassis Menu screen, use the arrow keys to highlight the CHASSIS ENVIRONMENTAL menu item and press ENTER. The Chassis Environmental Information screen, Figure 5-13 Chassis Environmental Information Screen The following describes each of the Chassis Environmental Information...
Page 76: Port Redirect Function Screen
Chapter 5: Local Management 5.11 PORT REDIRECT FUNCTION SCREEN The Port Redirect Function screen may not be available NOTE depending on the operational mode that has been set for the chassis. Refer to your Release Notes to see what operational modes support the Port Redirect Function.
Page 77 Event Message Line Source ============ Module Source Port Source Module [1] SAVE EXIT Figure 5-14 Port Redirect Function Screen The following deﬁnitions brieﬂy explain each ﬁeld of the Port Redirect Function screen. Source Module (Read-Only) Displays which modules are currently set as source modules. Source Port (Read-Only) Displays which ports are currently set as source ports.
Page 78: Displaying The Source And Destination Entries
Chapter 5: Local Management Source Port [ n ] (Selectable) Allows a selected port [n] to be conﬁgured as a source port. Destination Module [ n ] (Selectable) Allows a selected module [n] to be conﬁgured as a destination module. Destination Port [ n ] (Selectable) Allows a selected port [n] to be conﬁgured as a destination port.
Page 79: Changing Source And Destination Ports
5.11.2 Changing Source and Destination Ports Add or delete source/destination module and port entries as follows: Use the arrow keys to highlight the Source Module field. Press the SPACE bar or BACKSPACE one or more times to increment or decrement the module number displayed in the brackets [n] until the appropriate module number is displayed.
Page 80: Module Selection Screen
Chapter 5: Local Management 5.12 MODULE SELECTION SCREEN The Module Selection screen is the access point to Local Management for all modules installed in the SmartSwitch 6000 chassis. By selecting a module, the Module Menu for the selected device displays. shows the Module Selection screen.
Page 81: Selecting A Module
Serial # Indicates the serial number of the module. The serial number of the device is necessary when calling the Cabletron Systems Global Call Center. Hardware Revision Reﬂects the hardware version of the module. 5.12.1 Selecting a Module To select an individual module to perform Local Management functions, proceed as follows: Use the arrow keys to highlight the desired module number in the Module # field.
Page 82: Module Menu Screen
Chapter 5: Local Management 5.13 MODULE MENU SCREEN The Local Management screens shown in this chapter are for NOTE the 6E128-26. The 6E138-25, 6E139-25 and 6E129-26 share most of the following Local Management screens. All Local Management functions speciﬁc to any interface module are preceded by a note to alert the reader.
Page 83: Module Configuration
The following explains each Module Menu screen ﬁeld as shown in Figure 5-16: MODULE CONFIGURATION The Module Conﬁguration screen provides access to the Local Management screens that are used to conﬁgure the 6E12X-26 and 6E13X-25. The Module Speciﬁc Conﬁguration Menu screen provides access to the screens that allow the user to check 6E12X-26 and 6E13X-25 resources and set operating parameters speciﬁc to each port.
Page 84: Module Configuration Menu Screen
The Module Conﬁguration Menu screen, Local Management screens that allow you to conﬁgure and monitor operating parameters, modify SNMP community names, set SNMP traps, conﬁgure switch parameters and conﬁgure 6E12X-26 and 6E13X-25 ports. The following menu items on the Module Conﬁguration Menu...
Page 85: General Configuration
6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide Module Conﬁguration Menu Screen 6E128-26 LOCAL MANAGEMENT Module Configuration Menu Firmware Revision: BOOTPROM Revision: XX.XX.XX GENERAL CONFIGURATION SNMP COMMUNITY NAMES SNMP TRAPS SWITCH CONFIGURATION ETHERNET FULL DUPLEX CONFIGURATION SMARTTRUNK CONFIGURATION MODULE SPECIFIC CONFIGURATION EXIT 5.15. Section 5.17. XX.XX.XX...
Page 86: Switch Configuration
Chapter 5: Local Management SWITCH CONFIGURATION The Switch Conﬁguration screen provides basic setup options for modifying the switching functions of the modules. For details, refer to Section 5.18. ETHERNET FULL DUPLEX CONFIGURATION The Ethernet Full Duplex Conﬁguration screen allows each 10 Mbps port (1 to 24) to be set for either Standard Ethernet or Full Duplex operation.
Page 87: General Configuration Screen
5.15 GENERAL CONFIGURATION SCREEN The General Conﬁguration screen, system date and time, IP address and subnet mask, the default gateway, the TFTP gateway IP address, the operational mode, the management mode, set the screen refresh and lockout times, and the COM port conﬁguration.
Page 88 Chapter 5: Local Management The IP Address can also be set through Runtime IP Address NOTE Discovery as previously described in IP Address (Modiﬁable) This display allows the user to set the IP address for the 6E12X-26 and 6E13X-25. To set the IP address, refer to Subnet Mask (Modiﬁable) Displays the subnet mask for the module.
Page 89 Operational Mode (Selectable) This ﬁeld allows the user to set the 6E12X-26 and 6E13X-25 to operate as an IEEE 802.1D switch (802.1D SWITCHING option), an IEEE 802.1Q switch (802.1Q SWITCHING option), or as a Cabletron Systems SecureFast switch (SECURE FAST VLAN option).
Page 90 Chapter 5: Local Management Management Mode (Toggle) This ﬁeld toggles between DISTRIBUTED and STAND ALONE. In DISTRIBUTED mode, Local Management is entered via the 6C105 password screen, and all chassis conﬁguration screens are available to the user. All other modules installed in the chassis that are set for distributed management may also be accessed via a connection to a single COM port on one of the modules.
Page 91: Setting The Ip Address
Clear NVRAM (Toggle) This allows the user to reset NVRAM to the factory default settings. All user-entered parameters, such as IP address and Community Names are then replaced with 6E12X-26 and 6E13X-25 default conﬁguration settings. For details, refer to IP Fragmentation (Toggle) This ﬁeld allows the user to enable or disable IP Fragmentation.
Page 92: Setting The Subnet Mask
Chapter 5: Local Management YOU HAVE ELECTED TO SAVE ONE OR MORE CONFIGURATION ITEMS THAT REQUIRE RESETTING THIS MODULE. ARE YOU SURE YOU WANT TO CONTINUE? Figure 5-19 Conﬁguration Warning Screen Use the arrow keys to highlight the YES command and Press ENTER. The changes are saved and the module reboots.
Page 93: Setting The Default Gateway
Press ENTER. If the subnet mask is valid, the cursor returns to the beginning of the Subnet Mask field. If the entry is not valid, the Event Message Line displays “INVALID SUBNET MASK OR FORMAT ENTERED”. Local Management does not alter the current value, but it does refresh the Subnet Mask field with the previous value.
Page 94: Setting The Tftp Gateway Ip Address
Chapter 5: Local Management 5.15.4 Setting the TFTP Gateway IP Address If the network TFTP server is located on a different IP subnet than the 6E12X-26 and 6E13X-25, a Gateway IP address should be speciﬁed. To set the TFTP Gateway IP address, perform the following steps: Use the arrow keys to highlight the TFTP Gateway IP Addr field.
Page 95: Setting The Module Time
Press ENTER to set the system calendar to the date in the input field. Use the arrow keys to highlight the SAVE command at the bottom of the screen and press ENTER. If the date entered is a valid format, the Event Message Line at the top of the screen displays “SAVED OK”.
Page 96: Entering A New Screen Refresh Time
Chapter 5: Local Management 5.15.7 Entering a New Screen Refresh Time The screen refresh time is set from 3 to 99 seconds with a default of 3 seconds. To set a new screen refresh time, perform the following steps: Use the arrow keys to highlight the Screen Refresh Time field. Enter a number from 3 to 99.
Page 97: Setting The Operational Mode
General Conﬁguration screen, and the module will no longer support Chassis conﬁguration and Module selection screens. If the module will be a SecureFast switch, distributed management is not allowed. The module has been assigned SNMP community names from...
Page 98: Setting The Management Mode
Chapter 5: Local Management 5.15.10 Setting the Management Mode To set the management mode, perform the following steps: Upon saving the new Management Mode, the module will NOTE reboot. If the module will be set to STAND ALONE, ensure the following procedures have been completed: The module has been assigned a unique IP address.
Page 99: Configuring The Com Port
5.15.11 Conﬁguring the COM Port Before altering the COM port settings, ensure that a valid IP address is set for the module or chassis. (Refer to CAUTION Section 5.15.1, COM port conﬁguration section before changing the settings of the COM port. The 6E12X-26 and 6E13X-25 COM ports support the following applications: •...
Page 100 Chapter 5: Local Management THE COM PORT HAS BEEN RECONFIGURED AND THERE IS NO IP ADDRESS SET FOR THIS DEVICE. YOU WILL NO LONGER BE ABLE TO MANAGE THIS BOARD. DO YOU STILL WISH TO RECONFIGURE THIS COM PORT? Figure 5-20 COM Port Warning Screen If the 6C105 chassis has been conﬁgured with a valid IP NOTE address this screen will not appear.
Page 101: Changing The Com Port Application
5.15.12 Changing the Com Port Application After enabling the COM port as described in select one of the applications supported by the COM port: LM or UPS can be selected. The default application is LM. To change the COM port application: Use the arrows keys to highlight the Application field.
Page 102: Clearing Nvram
Chapter 5: Local Management 5.15.13 Clearing NVRAM Clearing NVRAM will result in the loss of all user-entered parameters. Do not proceed unless this procedure is completely understood. CAUTION Clearing NVRAM allows the user to clear all user-entered parameters, such as IP address and Community Names from NVRAM. Clear NVRAM as follows: Use the arrow keys to highlight the Clear NVRAM field.
Page 103: Enabling/Disabling Ip Fragmentation
5.15.14 Enabling/Disabling IP Fragmentation To enable or disable IP fragmentation, proceed as follows: If the 6E12X-26 and 6E13X-25 are being bridged to an FDDI ring (for example, via an HSIM-F6 installed in the 6E13X-25) IP CAUTION Fragmentation should be enabled. If IP Fragmentation is disabled, all FDDI frames that exceed the maximum Ethernet frame size will be discarded.
Page 104 Chapter 5: Local Management To access the SNMP Community Names screen from the Module Conﬁguration Menu screen, use the arrow keys to highlight the SNMP COMMUNITY NAMES menu item and press ENTER. The SNMP Community Names screen, Event Message Line Module Type: 6E128-26 Slot Number: X SAVE...
Page 105: Establishing Community Names
read-write super-user 5.16.1 Establishing Community Names The password used to access Local Management at the Password Screen must have Super-User access in order to view and edit the SNMP Community Names screen. Using a password with read-only or read-write access does not allow the user to view or edit the SNMP Community Names screen.
Page 106: Snmp Traps Screen
Chapter 5: Local Management 5.17 SNMP TRAPS SCREEN Since the 6E12X-26 and 6E13X-25 are SNMP compliant devices, they can send messages to multiple Network Management Stations to alert users of status changes. The SNMP Traps screen is shown in It is only necessary to assign SNMP traps if the user desires NOTE the traps to be sent to different addresses than those assigned Section...
Page 107: Configuring The Trap Table
Trap Community Name (Modiﬁable) Displays the Community Name included in the trap message sent to the Network Management Station with the associated IP address. Enable Traps (Toggle) Enables transmission of the traps to the network management station with the associated IP address. This ﬁeld toggles between YES and NO. 5.17.1 Conﬁguring the Trap Table To conﬁgure the Trap Table, proceed as follows: Using the arrow keys, highlight the appropriate Trap Destination...
Page 108: Switch Configuration Screen
FAST VLAN. This screen may only be used by modules conﬁgured to operate as 802.1D or 802.1Q switches. To access the Switch Conﬁguration screen from the Module Conﬁguration Menu screen, use the arrow keys to highlight the SWITCH CONFIGURATION menu item and press ENTER. The Switch Conﬁguration screen, edit the ﬁelds for ports 9 to 16, highlight [9-16] at the bottom of the screen...
Page 109 Type of STA (Toggle) Allows the user to set the method that switches use to decide which switch is the controlling (Root) switch when two or more switches exist in parallel (Spanning Tree Algorithm). Valid entries include IEEE, DEC, and NONE.
Page 110 Section 5.18.2. Port # (Read-Only) Lists each switch port on the module. If the number of ports is greater than eight, then the additional ports are listed on subsequent screens. MAC Address (Read-Only) Displays the hardware address assigned to each listed port.
Page 111: Setting The Sta
The Spanning Tree Algorithm (STA) setting allows the user to set the method that the switches use to decide which is the controller (Root) switch when two or more switches are in parallel. The available selections are IEEE, DEC, and NONE.
Page 112: Ethernet Full Duplex Configuration Screen
Chapter 5: Local Management Use the SPACE bar to toggle to either ENABLED or DISABLED. Use the arrow keys to highlight the SAVE command at the bottom of the screen. Press ENTER. The message “SAVED OK” displays. 5.19 ETHERNET FULL DUPLEX CONFIGURATION SCREEN The Ethernet Full Duplex Conﬁguration screen, user to set ports 1 through 24, individually or all at once, to either...
Page 113 • ENABLED – The port is turned on administratively. • DISABLED – The port is turned off administratively. Enabling or disabling ports from the Switch Conﬁguration NOTE screen is described in SET ALL PORTS (Toggle) Ports 1 through 24 can be set all at once to either STANDARD or FULL from this ﬁeld.
Page 114: Setting The Operation Mode
Chapter 5: Local Management [1-12], or [13-24] (Navigation Key) When the Full Duplex Conﬁguration screen displays, the current operation mode and status information are displayed for the ﬁrst 12 ports. This ﬁeld allows the user to step to a second screen for the same type of information for ports 13 through 24.
Page 115: Module Specific Configuration Menu Screen
5.20 MODULE SPECIFIC CONFIGURATION MENU SCREEN The Module Speciﬁc Conﬁguration Menu screen, user to select one of ﬁve screens to conﬁgure ports or check system resources speciﬁc to the 6E12X-26 and 6E13X-25. The following menu items on the Module Speciﬁc Conﬁguration NOTE Menu screen may not display if the operational mode of the module has been set to SECURE FAST VLAN or 802.1Q...
Page 116: System Resources
Chapter 5: Local Management Module Type: 6E128-26 Slot Number: X Figure 5-26 Module Speciﬁc Conﬁguration Menu Screen The following explains each ﬁeld of the Module Speciﬁc Conﬁguration Menu screen: SYSTEM RESOURCES The System Resources screen displays the amount of FLASH memory, DRAM, and NVRAM installed, details how much memory is available and provides information on 6E12X-26 and 6E13X-25 operation.
Page 117: Flash Download
802.1Q VLAN Conﬁguration This menu item will only display if the module has been conﬁgured to operate as an IEEE 802.1Q switch. When selected, this menu item opens the VLAN Main Menu screen. For details, refer to the Cabletron Systems Port Based VLAN User’s Guide.
Page 118 Firmware Revision: BOOTPROM Revision: XX.XX.XX CPU Type: i960 HT 25Mhz Available: 16 MB Available: Available: XX KB Current Switch Utilization: 66% Peak Switch Utilization: 75% Reset Peak Switch Utilization: [NO] EXIT XX.XX.XX XXXXX Bytes XXXXX Bytes XXXXX Bytes RETURN RETURN 2311_23...
Page 119: Setting The Reset Peak Utilization
Shows the peak percentage of maximum switching capacity, since last reset. Reset Peak Switch Utilization (Toggle) Allows the user to reset the Peak Switch Utilization ﬁeld. The switch may be set to either YES or NO as described in Peak Switch Utilization ﬁeld to the current system trafﬁc.
Page 120: High Speed Interface Configuration Screen (6E12X-26 Only)
Chapter 5: Local Management 5.22 HIGH SPEED INTERFACE CONFIGURATION SCREEN (6E12X-26 ONLY) When the HIGH SPEED INTERFACE CONFIGURATION NOTE menu item is selected for the 6E13X-25, the applicable HSIM Setup screen displays. Refer to the HSIM User’s Guide to set operating parameters for the HSIM installed in the 6E13X-25.
Page 121 High Speed Interface Conﬁguration Screen (6E12X-26 Only) Event Message Line Module Type: 6E128-26 Slot Number: X Port Type Link Status Current Oper. Mode Desired Oper. Mode Advertised Ability SAVE Figure 5-28 High Speed Interface Conﬁguration Screen for the 6E12X-26 The following brieﬂy explains each ﬁeld of the High Speed Interface Conﬁguration screen.
Page 122 Chapter 5: Local Management Current Oper. Mode (Read-only) This ﬁeld displays the current operating mode of ports 25 and 26. Depending on the interface installed (100BASE-FX or 100BASE-TX) this ﬁeld displays the following: • With a 100BASE-FX interface: 100Base-FX or 100Base-FXFD (full duplex), or N/A when the port slot is empty.
Page 123: Configuring An Fe-100Fx Or Fe-100F3
High Speed Interface Conﬁguration Screen (6E12X-26 Only) Advertised Ability (Selectable) During auto-negotiation, the FE-100TX “tells” the device at the other end of the segment what its capabilities are. The capabilities of a port (25 or 26) with an FE-100TX installed are 10BASE-T, 10BASE-TFD (full duplex mode), 100BASE-TX and 100BASE-TXFD (full duplex mode).
Page 124: Configuring An Fe-100Tx
Chapter 5: Local Management 5.22.3 Conﬁguring an FE-100TX In normal operation, a port (25 or 26) with an FE-100TX interface automatically establishes a link with the device at the other end of the segment and no user setup is required. provide instructions for manually conﬁguring the port with an FE-100TX installed.
Page 125: Flash Download Screen
ﬁle from a TFTP server. The user may also force the download of a new image by NOTE changing the position of Switch 6 located inside the module. Refer to Section Before downloading a new image to the module, load the image onto the network TFTP server.
Page 126: Using Bootp
Chapter 5: Local Management TFTP DOWNLOAD. WILL COMMIT TO FLASH. REBOOT IN PROGRESS... Module Type: 6E128-26 Slot Number: X EXECUTE Figure 5-29 Flash Download Screen Download Server IP and Download Server Filename are NOTE displayed only when TFTP or RUNTIME are selected in Download Method.
Page 127 Flash Download Screen Reboot After Download (Modiﬁable when RUNTIME is chosen only) This ﬁeld notiﬁes the user that the 6E12X-26 and 6E13X-25 will reboot after the download is complete. If a RUNTIME Download is performed, this ﬁeld toggles between YES and NO. If YES is selected, the module reboots after the download is completed.
Page 128: Image File Download Using Tftp
Chapter 5: Local Management 5.23.1 Image File Download Using TFTP To download a new ﬁrmware image to the FLASH memory of the 6E12X-26 and 6E13X-25 using TFTP proceed as follows: Use the arrow keys to highlight the Download Method field. Use the SPACE bar to select TFTP.
Page 129: Image File Download Using Runtime
5.23.2 Image File Download Using RUNTIME To download a new ﬁrmware image to the FLASH memory of the 6E12X-26 and 6E13X-25 using RUNTIME proceed as follows: Use the arrow keys to highlight the Download Method field. Use the SPACE bar to select RUNTIME. Use the arrow keys to highlight the Reboot After Download field.
Page 130: Image File Download Using Bootp
Chapter 5: Local Management 5.23.3 Image File Download Using BootP To download a new ﬁrmware image to the FLASH memory of the 6E12X-26 and 6E13X-25 using BootP proceed as follows: Use the arrow keys to highlight the Download Method field. Use the SPACE bar to select BOOTP.
Page 131: Port Redirect Function Screen
5.24 PORT REDIRECT FUNCTION SCREEN The Port Redirect Function screen may not be available NOTE depending on the operational mode that has been set for the module. Refer to your Release Notes to see which operational modes support the Port Redirect Function screen. Refer to Section 5.15.9, on conﬁguring the operational mode of the module.
Page 132 Chapter 5: Local Management Event Message Line Module Type: 6E128-26 Slot Number: X Source Port: ============ Source Port [1] SAVE Figure 5-30 Port Redirect Function Screen The following deﬁnitions brieﬂy explain each ﬁeld of the Port Redirect Function screen: Source Port (Read-only) Shows which ports are currently set as source ports.
Page 133: Displaying The Source And Destination Entries
Errors (Toggle) Allows the user to conﬁgure the source ports to either send errored frames to selected destination ports (ON option), or to drop errored frames, and send only valid trafﬁc to the destination ports (OFF option). The default setting of this ﬁeld is ON. Status (Selectable) Allows you to add or delete the source and destination ports selected in the Source Port [n] and Destination Port [n] ﬁelds.
Page 134 Chapter 5: Local Management Use the arrow keys to highlight the Errors field. Use the SPACE bar to select either the ON or OFF option and press ENTER. ON forces the source module and port to forward errored frames to the destination module(s) and port(s). OFF forces the errored frames to be dropped before forwarding traffic.
Page 135: Broadcast Suppression Screen
5.25 BROADCAST SUPPRESSION SCREEN The Broadcast Suppression screen, desired limit of receive broadcast frames that are switched out to the other ports. The Broadcast Suppression screen may not be available if the NOTE operational mode of the module has been set to SECURE FAST VLAN or 802.1Q SWITCHING.
Page 136: Setting The Threshold
Chapter 5: Local Management The following explains each ﬁeld of the Broadcast Statistics screen: PORT # (Read-only) Identiﬁes the number of the port. Total RX (Read-Only) Displays the total number of broadcast frames received. Peak Rate (Read-Only) Displays the number of broadcast frames received per second. Time Since Peak (Read-Only) Displays the time since peak broadcast frames received.
Page 137: Setting The Reset Peak Switch
5.25.2 Setting the Reset Peak Switch To set the Reset Peak Switch ﬁeld to YES or NO, proceed as follows: Use the arrow keys to highlight the Reset Peak field for the selected port. Press the SPACE bar to select YES or NO.
Page 138: Switch Statistics
Figure 5-32 Module Statistics Menu Screen The Module Statistics Menu screen displays the following menu items: SWITCH STATISTICS The Switch Statistics screen lists the number of frames received, transmitted, ﬁltered, and forwarded by each interface. For details, refer to Section 5.27.
Page 139: Switch Statistics Screen
FAST VLAN. This screen may only be used by modules conﬁgured to operate as 802.1D or 802.1Q switches. To access the Switch Statistics screen from the Module Statistics Menu screen, use the arrow keys to highlight the SWITCH STATISTICS menu item and press ENTER.
Page 140: Using The Clear Counters Command
Displays the number of frames forwarded by the interface. [1-12], [13-24], or [25-26] (6E12X-26), [25] (6E13X-25) (Navigation Key) When the Switch Statistics is displayed, the statistics are displayed for the ﬁrst 12 ports. These ﬁelds allow the user to step to a second or third screen for the same type of information for ports 13 through 24 or ports 25 and 26 of the 6E12X-26 and port 25 (HSIM) of the 6E13X-25.
Page 141: The Interface Statistics Screen
5.28 THE INTERFACE STATISTICS SCREEN The Interface Statistics screen is used to gather MIB-II statistics for all of the 6E12X-26 and 6E13X-25 interfaces (ports 1 through 24 and Fast Ethernet Interface Modules and all backplane interfaces) with the exception of an HSIM installed in the 6E13X-25. Cabletron Systems HSIMs gather their own statistics, and may NOTE be viewed via the Local Management screens of the applicable...
Page 142 The InDiscards ﬁeld displays the total number of inbound frames that were discarded, even though the frames contained no errors. This ﬁeld may increment because the switch needed to free up buffer space, or the switch was being overutilized. InErrors (Read-only) This ﬁeld displays the total number of inbound frames that have been...
Page 143 The OutDiscards ﬁeld displays the total number of outbound frames that were discarded, even though the frames contained no errors. This ﬁeld may increment, because the switch needed to free up buffer space, or the switch was being overutilized. OutErrors (Read-only) This ﬁeld displays the total number of outbound frames discarded...
Page 144: Displaying Interface Statistics
Chapter 5: Local Management Oper Status (Read-only) This ﬁeld displays the current status of the interface. If this ﬁeld displays “Testing”, no frames may be passed on this interface. MTU (Read-only) The MTU ﬁeld displays the maximum frame size (in octets) that a frame may contain to be received or transmitted from this interface.
Page 145: Rmon Statistics Screen
5.29 RMON STATISTICS SCREEN RMON statistics for each interface, on a interface-by-interface basis, are viewed through the RMON Statistics screen shown in To access the RMON Statistics screen, use the arrow keys to highlight the RMON STATISTICS menu item on the Module Statistics Menu screen and press ENTER.
Page 146 Drop Events (Read-only) This ﬁeld displays the total number of times that the RMON agent was forced to discard frames due to the lack of available switch resources. The Drop Events ﬁeld does not display the number of frames NOTE dropped, it only displays the number of times that the RMON agent was forced to discard frames.
Page 147 Undersized Pkts (Read-only) The Undersized Pkts ﬁeld displays the number of frames received whose size was less than the minimum Ethernet frame size of 64 bytes, not including preamble, but have a valid CRC. Oversized Pkts (Read-only) The Oversized Pkts ﬁeld displays the number of frames received whose size exceeded 1518 data bytes, not including preamble, but have a valid CRC.
Page 148 Chapter 5: Local Management 65 - 127 Octets (Read-only) Displays the total number of frames, including bad frames, received that were between 65 and 127 bytes in length (excluding framing bits, but including FCS bytes). 128 - 255 Octets (Read-only) Displays the total number of frames, including bad frames, received that were between 128 and 255 bytes in length (excluding framing bits, but including FCS bytes).
Page 149: Displaying Rmon Statistics
5.29.1 Displaying RMON Statistics To display the statistics for any index, proceed as follows: Use the arrow keys to highlight the Index [nn] field at the bottom of the screen. Press the SPACE bar to increment (or press the DEL [delete] key to decrement) the index number.
Page 150: Network Tools
Chapter 5: Local Management 5.30 NETWORK TOOLS The Network Tools function resides on both the 6E12X-26 and 6E13X-25 and allows the user to access and manage network devices. To Access the Network Tools screen, use the arrow keys to highlight the NETWORK TOOLS menu item in the Module or Chassis Menu screen and press ENTER.
Page 151: Built-In Commands
• Special Commands – Allow the user to exit from Network Tools. The commands are done, exit, and quit. The conventions used in describing the commands in Network NOTE Tools are as follows: Arguments enclosed by [ ] are required. Arguments enclosed by <...
Page 152: Mac Address
Chapter 5: Local Management You must specify the arp command with one of the following options: Options: Example: -> arp -a # Interface # (SonicInt) # (SonicInt) # (SonicInt) # (SonicInt) -> arp -d 1 122.144.52.68 -> arp -s 1 22.44.2.3 00:00:0e:03:1d:3c ->...
Page 153 bridge: Syntax: Description: Options: Example: -> bridge disable all -> bridge enable 1 -> bridge disable 1 defroute: Syntax: Description: Options: Example: -> defroute 2 147.152.42.32 # Default route is 147.152.42.32 on interface 2 -> defroute # Default route is 147.152.42.32 on interface 2 ->...
Page 154 Chapter 5: Local Management netstat: Syntax: Description: Options: Example: -> netstat -i Interface + Description # 1 (ethernet -csmacd) 1514 # 2 (ethernet - csmacd) 1514 # 3 (ethernet - csmacd) 1514 # 4 (ethernet - csmacd) 1514 -> netstat -r Destination Next-hop # Default Route...
Page 155 reset: Syntax: Description: The Network Tools connection to the module will be terminated upon execution of this command. CAUTION Options: Example: -> reset RESET : Are you *SURE* ? Y 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide reset The reset command initiates a hardware reset of the module.
Page 156 Chapter 5: Local Management show: Syntax: Description: Options: Example: -> show Appletalk interfaces # Interface AdminStatus enabled disabled -> show IP ARP MediaType # Interface 3 (dynamic) 3 (dynamic) 5-110 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide show [PROTOCOL] [TABLE] The show command displays information concerning various components of the device.
Page 157 traceroute: Syntax: Description: Options: Example: -> traceroute 122.144.11.52 # next-hop[0] : 122.144.60.45 # next-hop[1] : 122.144.8.113 # next-hop[2] : 122.144.61.45 # 122.144.11.52 is alive : 3 hops away. soft_reset: Syntax: Description: The Network Tools connection to the module will be terminated upon execution of this command.
Page 158 Chapter 5: Local Management telnet: Syntax: Description: Options: Example: link_trap: Syntax: Description: Options: 5-112 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide telnet [IP address] <Port #> The telnet command allows the user to communicate with another host (that supports Telnet connections) using the Telnet protocol. The user must specify the remote host using its IP address.
Page 159 Example: -> link_trap status LINK TRAP STATUS: Port 1 is ENABLED Port 3 is ENABLED -> link_trap disable 2 Link traps have been DISABLED on port 2 -> link_trap disable all Link traps have been DISABLED on all ports (1-24) ->...
Page 160: Special Commands
Chapter 5: Local Management 5.30.2 Special Commands done, quit, exit: Syntax: Description: Options: Example: -> done Connection closed 5-114 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide done The done command enables the user to exit from Network Tools and return to the Main Menu screen.
Page 161: Appendix Aspecifications
This appendix provides operating speciﬁcations for the Cabletron Systems 6E138-25, 6E128-26, 6E139-25 and 6E129-26 Interface Modules. Cabletron Systems reserves the right to change these speciﬁcations at any time without notice. DEVICE SPECIFICATIONS Processor: Dynamic Random Access Memory (DRAM): FLASH Memory: PHYSICAL PROPERTIES Dimensions: Weight (Unit):...
Page 162: Input/Output Ports
Appendix A: Speciﬁcations INPUT/OUTPUT PORTS 6E128-26 Ports 1 through 24 Slots for optional Fast Ethernet Interface Modules (ports 25 and 26) 6E138-25 Ports 1 through 24 Slot for optional HSIM 6E129-26 Ports 1 through 24 Slots for optional Fast Ethernet Interface Modules (ports 25 and 26) 6E139-25...
Page 163: Com Port Pinout Assignments
COM PORT PINOUT ASSIGNMENTS The COM port is a serial communications port that supports Local Management or connection to a UPS. The COM port has the following pin assignments: Table A-1 COM Port Pin Assignments Signal Name Transmit Data (XMT) Data Carrier Detect (DCD) Data Set Ready (DSR) Receive Data (RCV)
Page 164 Appendix A: Speciﬁcations 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide...
Page 165: Appendix B
Unshielded Twisted Pair (UTP) cabling with an impedance between 85 and 111 ohms. The slide switch on the FE-100TX determines the crossover status of the cable pairs. If the switch is on the over. If the switch is on the over.
Page 166: Fe-100Fx
Appendix B: FE-100TX, FE-100FX and FE-100F3 Speciﬁcations FE-100FX The FE-100FX shown in supports multimode ﬁber optic cabling. Speciﬁcations for the FE-100FX are listed below. Cable Type 50/125 µm ﬁber 62.5/125 µm ﬁber 100/140 µm ﬁber The transmitter power levels and receive sensitivity levels listed NOTE are peak power levels after optical overshoot.
Page 167: Fe-100F3
FE-100F3 The FE-100F3 shown in supports single mode ﬁber optic cabling. Speciﬁcations for the FE-100F3 are listed in Table B-2 Cable Type 8/125 µm ﬁber 12/125 µm ﬁber The transmitter power levels and receive sensitivity levels listed NOTE are peak power levels after optical overshoot. A peak power meter must be used to correctly compare the values given above to those measured on any particular port.
Page 168 Appendix B: FE-100TX, FE-100FX and FE-100F3 Speciﬁcations 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide...
Page 169: Mode Switch Bank Settings And Optional Installations
MODE SWITCH BANK SETTINGS AND OPTIONAL INSTALLATIONS This appendix covers the following items: • Required tools (Section • Locations, functions, and settings for the mode switches • Installing Optional Fast Ethernet Interface Modules REQUIRED TOOLS You need the following tools to perform the procedures provided in this appendix: •...
Page 170 COM port to 9600 baud for Local Management sessions. • Switch 6 – Forced BootP. Changing the position of this switch (i.e., moving the switch from one position to the other) clears download information from NVRAM and forces the 6E12X-26 and 6E13X-25 to download a new image ﬁle from a BootP server after power to the...
Page 171 6E13X-25 are reset, the passwords can either be reentered or the default passwords (Public and ENTER) may be used. Do not change the position of switch 8 unless it is necessary to NOTE reset the module super-user conﬁgured passwords to their factory default settings.
Page 172: Installing Optional Fast Ethernet Interface Modules
Appendix C: Mode Switch Bank Settings and Optional Installations INSTALLING OPTIONAL FAST ETHERNET INTERFACE MODULES Figure C-2 shows the location of the Fast Ethernet Interface Module connectors on the 6E12X-26 board for port slots 25 and 26. For instructions on installing a High Speed Interface Module...
Page 173 Installing Optional Fast Ethernet Interface Modules To install a Fast Ethernet Interface Module in port slot 25 or 26 of the 6E12X-26, proceed as follows: The Fast Ethernet Interface Module and the host module are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure.
Page 174 Appendix C: Mode Switch Bank Settings and Optional Installations Coverplate Figure C-3 Coverplate Removal Remove the screw from the rear standoff. Save the screw. When installing an FE-100FX or FE-100F3 module into the host module, remove the rubber plug on the SC connector CAUTION before proceeding.
Page 175 Installing Optional Fast Ethernet Interface Modules Figure C-4 Installing the Fast Ethernet Interface Module Press down firmly on the Fast Ethernet Interface Module until the pins slide all the way into the motherboard connector. Ensure that the Fast Ethernet Interface Module seats flush on the standoffs. Secure the Fast Ethernet Interface Module with the screws saved in steps 1 and 2.
Page 176 Appendix C: Mode Switch Bank Settings and Optional Installations 6E128-26, 6E138-25, 6E129-26 and 6E139-25 User’s Guide...
Page 177 Clear NVRAM 5-45 Clearing NVRAM 5-56 COM port pin assignments A-3 Connecting to the network 3-5 Crossover switch B-1 Current switch utilization 5-73 Default gateway 5-42, 5-47 Displaying statistics 5-98, 5-103 Environmental requirements A-1 Ethernet Full Duplex Configuration screen 5-66...
Page 178 Configuration 5-70 System Resources 5-70 Module Statistics 5-37 Module Statistics Menu screen 5-91 Interface statistics 5-92 RMON statistics 5-92 Switch statistics 5-92 Module time 5-42 Module Uptime 5-43 Navigating Local Management 5-8 Exiting Local Management 5-10 Selecting items 5-10 Network connection...
Page 179 SNMP Traps screen 5-27, 5-60 Switch Configuration screen 5-62 Switch Statistics screen 5-93 System Resources screen 5-71 Setting communtiy names 5-25 Setting the reset peak switch 5-91 Setting the threshold 5-90 SNMP Community Names screen 5-24, 5-57 access policy 5-25, 5-58...
Page 180 System Resources screen 5-71 current switch utilization 5-73 DRAM installed 5-72 Flash memory installed 5-72 NVRAM installed 5-72 peak switch utilization 5-73 reset peak switch utilization 5-73 TFTP Gateway IP Addr 5-48, 5-81 Trap table configuration 5-28, 5-61 Traps enable 5-28 Troubleshooting 4-1...
