4009 IDNet NAC Extender,
System Switches and
Indicators, continued
Continued
Table 3. Control Mapping Switch Settings
DIP Switch SW2
Position
1 2 3
OFF OFF OFF
OFF OFF OFF
ON OFF OFF
ON OFF OFF
OFF ON OFF
OFF ON OFF
NAC Status Indicators (LED(s) 1-4)
Each output NAC has a yellow LED (see Figure 4 for location of LEDs) to
indicate a trouble condition or the active state of that NAC. The condition/state
for the NACs are as follows:
• IN ALARM = NAC (1-4) LED "ON"
• IN SUPERVISORY = LED "OFF" (OK)
• SLOW FLASH (1 flash per second) = SHORT
• FAST FLASH (2 flashes per second) = OPEN
System Trouble Indicators (LED(s) 5-8)
The system trouble indicators consist of a bank of four yellow LEDs (see Figure
4 for location of LEDs) that are used to signify various trouble conditions within
the 4009 IDNet system. Only one trouble at a time is indicated, highest trouble
state indicated first. When that trouble clears, additional troubles, if present, will
be indicated. Table 4 lists system troubles from highest trouble state (invalid
configuration) to lowest trouble state (Normal).
Table 4. System Trouble Indicators
LED 5 LED 6 LED 7
OFF OFF OFF
ON ON ON
OFF ON ON
OFF ON OFF
ON OFF OFF
ON OFF ON
ON OFF OFF
OFF OFF ON
OFF OFF OFF
8
Host NAC Power Distribution to
Input
1
2
1
2
1
2
LED 8 TROUBLE DESCRIPTION
ON Invalid Configuration
OFF Diagnostic Test Fail
OFF Software Failure
OFF Running on Depleted Battery
OFF Low/Missing Battery
OFF Earth Ground Fault
ON NAC Trouble
OFF AC Power Loss
OFF Normal
Continued on next page
NAC Circuits
1,2 (5 & 6)
3, 4 (7 & 8)
1 – 4
5 – 8
1 – 8
None
