System Installation

General Information
Tools and Equipment
Required
General Notes
Important: Notify the appropriate personnel (building occupants, fire
department, monitoring facility, etc.) of the installation.
The following paragraphs contain material which is applicable to all 4009 IDNet
systems. Be sure that you are thoroughly familiar with this material before
installing your 4009 IDNet.
To help you with installation of this and other Simplex Fire Alarm equipment,
the following publication is available for general reference: How to Wire a
Building for a Fire Alarm System (FA2-91-001 or 575-892).
The following tools and equipment are required to install the 4009 IDNet:
•
1/4-inch flat-tip screwdriver, 8-inches long
•
1/8-inch flat-tip screwdriver, 4-inches long
•
Volt-Ohmmeter
•
Diagonal cutting pliers
•
Wire strippers
•
Listed end-of-line resistors (ordered seperately)
10K resistor (733-804)
•
Field Wiring Diagram 842-068.
1. All wiring must be installed in accordance with local codes.
2. A minimum of 6 inches of free conductor is required at each electrical box
to facilitate terminations.
3. A 12-inch service loop of cable is required for all continuous pulls through
an electrical box.
4. All system wiring subject to physical damage must be mechanically
protected based on the environment to which the cable is subjected.
5. A neatly wired system helps assure an accurate inspection of all connections
and simplify troubleshooting.
11
Continued on next page
