System Installation,
Mounting and Wiring
Peripheral Devices
System Wiring Configurations
Continued
Refer to the 842-068 Field Wiring Diagram for detailed information, and the
procedure listed below when installing the 4009 IDNet peripheral devices.
1. Determine the mounting locations of the peripheral devices and install
system wires from the mounting location of each peripheral device to the
4009 system board. All wiring to be minimum 18 AWG, supervised, and
Power-Limited.
2. Install all peripheral devices and connect them to appropriate wires. (Refer
to the installation instructions packed with the devices.)
3. For 2-wire Class B/Style Y and 4-wire Class A/Style Z devices, a 10K, 1/2
W (Brown/Black/Orange) End-of-Line Resistor (EOLR) is provided. Refer
to Field Wiring Diagram 842-068.
The base 4009 IDNet NAC Extender has the following system wiring
configurations:
•
2-wire Class B/Style Y NAC (reverse polarity)
•
4-wire Class A/Style Z NAC (reverse polarity)
•
Hardwired NAC Control Inputs from host FACP (Class A/Style Z &
Class B/Style Y)
•
Addressable IDNet Slave Interface (Class B/Style 4 and Class A/Style 6)
•
Addressable IDNet Repeater Interface (Class B/Style 4 and Class A/Style 6)
•
Addressable IDNet Fiber Receiver/Transmitter Interface (Class B/Style 4
and Class A/Style 6)
