System Installation,
Mounting the 4009 IDNet,
continued
Wiring the 4009 IDNet
Continued
5. Mount back box to wall. Back box must be level and plumb. For surface
mounting use the teardrop and clearance holes located in the rear of the box
and screw to wall.
6. Wire Non-Power-Limited wiring in the shaded areas only (see Figure 6),
this includes AC input and battery connections. All other wiring is Power-
Limited. Maintain at least ¼-inch spacing between all Power-Limited and
Non-Power-Limited wiring.
7. Connect the AC wiring harness and install the electronic card cage assembly
to the 4009 IDNet cabinet.
When wiring the 4009 IDNet, refer to the 842-068 Field Wiring Diagram, the
4009 IDNet NAC Extender Connection Diagram (Figure 7), and the following
system wiring requirements.
•
All wiring, except incoming power and ground connecting wires, must be
free from grounds or shorts and have a resistance of one megohm, or higher,
to EARTH.
•
All wires are to be copper conductors only, except fiber cables. All
equipment must be installed in accordance with the manufacturer's
recommendations and the specifications and standards of the Authority
Having Jurisdiction (AHJ). The installation of all wiring, cable, and
equipment must be in accordance with NFPA 70.
•
If shielded wire is used, the metallic continuity of the shield must be
maintained and insulated throughout the entire length of the cable. The
entire length of the cable must have a resistance of one megohm to earth.
•
Splicing is permitted in accordance with NFPA 70. All wiring must be
terminated with UL listed devices (e.g., wire nuts, pressure connectors).
Wiring terminated with only electrical tape is not permitted. All splicing
(free ends of conductors) must be covered with an insulation equivalent to
that of the conductors.
•
An appropriate system ground must be provided for earth detection and
lighting protection devices. This connection shall be made to an approved
dedicated earth connection per NFPA 70.
•
When running wires to the 4009 IDNet, identify the wires appropriately:
Only system wiring can be run in the same conduit which includes dedicated
NAC wiring, IDNet wiring, 24V AUX wiring, and the four NAC circuits (an
additional four NAC circuits are available as a field-installed option).
Input power and external battery power are Non-Power-limited and
cannot be run with Power-Limited system wiring.
13
Continued on next page
