Contents
Exterior Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cut-Out Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clearances Information . . . . . . . . . . . . . . . . . . . . . . . . .
Other Site Requirements . . . . . . . . . . . . . . . . . . . . . . . .
No Custom Drawer Panels . . . . . . . . . . . . . . . . . . . . . . .
Custom 1/4" Drawer Panel Inserts . . . . . . . . . . . . . . . .
Full Overlay Drawer Panels . . . . . . . . . . . . . . . . . . . . . .
Checking Drawer Alignment . . . . . . . . . . . . . . . . . . . .
Adjusting Drawer Alignment . . . . . . . . . . . . . . . . . . . . 10
Water Supply Connection . . . . . . . . . . . . . . . . . . . . . . . 12
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 13
Leveling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation Tip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Installation of the C2275DWR . . . . . . . . . . . . . . . . . . . 14
Anti-Tip Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installation Troubleshooting . . . . . . . . . . . . . . . . . . . . . 15
Initial Start-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Start-Up Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 16
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
www.U-LineService.com
C2275DWR - Ice Maker/Refrigerator
4
4
5
5
6
7
7
8
9
1 Follow Safety Precautions
IMPORTANT
PLEASE READ all instructions completely before
attempting to install or operate the unit.
• This unit requires connection to the water supply.
Improper hook-up can result in substantial property
damage! If you are unsure of your ability to safely
connect the water supply to the unit, consult a licensed
plumber for assistance.
• This unit requires connection to a grounded (three-
prong), polarized receptacle that has been placed by a
qualified electrician in accordance with applicable
electrical codes.
Safety Alert Definitions
Safety items throughout this guide are labeled with a
Danger, Warning or Caution based on the risk type:
Danger means that failure to follow this safety
statement will result in severe personal injury or
death.
Warning means that failure to follow this safety
statement could result in serious personal injury,
or death.
Caution means that failure to follow this safety statement
may result in minor or moderate personal injury, property
or equipment damage.
2
DANGER
WARNING
CAUTION
