USB-7204 User's Guide
OEM connector
The OEM connector operates in parallel with the USB connector — do not connect to both the USB connector
and the OEM connector.
The OEM connector is a 0.1" box header. Pins 2, 4, 6, 8, and 10 provide a USB connection, as listed in the
connector pinout below:
Pin
Signal Name
1
N/C
3
N/C
5
N/C (do not connect anything to this pin)
7
N/C (do not connect anything to this pin)
9
N/C (do not connect anything to this pin)
Modifications are required in order to use the OEM connector
We recommend that you return the device to the factory for this modification.
Should you have the capabilities to perform the modifications, the following change is required: in order to
create a USB connection via the OEM connector, locations R48 and R49 must be populated. We recommend
that you populate with 0603 size 0 Ω resistors or provide solder bridges to close the gaps.
Trigger/Sync connector
The Trigger/Sync connector provides two signals —
the screw terminal (see page 15 for details about these signals).
Use a 0.1" box header when making connections to the Trigger/Sync connector.
The Trigger/Sync connector internally connects its SYNC and TRIG_IN pins to the screw terminal via jumpers
and
.
P6
P7
Sync jumper (P6)
The Sync jumper internally connects the SYNC pin on the Trigger/Sync connector to the SYNC pin on the
screw terminal. Remove this jumper on boards that will not send/receive the SYNC signal through the
SYNC/TRIG connector. Refer to Figure 2 on page 10 for the location of this jumper.
OEM connector pinout
Pin
2
4
6
8
10
SYNC
Trigger/Sync connector pinout
Pin Signal Name
Pin Signal Name
1
TRIG_IN
2
3
N/C
4
5
SYNC
6
7
N/C
8
9
N/C
10
Figure 3. Jumper P6 and P7 schematic
11
Signal Name
VBUS
D–
D+
GND
SHIELD
and
TRIG_IN
. These signals are also available on
GND
GND
GND
GND
N/CD
