Technical Datasheet
Options
®
JobControl Vision
Travelling exhaust
Digital table exhaust
Chiller
TM
Sonar Technology
TroCAM Basic / Advanced
TroCare
Dimensions (W x D x H) & Weight
Machine
Chiller
Operating console
Travelling exhaust
Safety
Laser class
Laser safety
Mechanical safety
Interlock
Ambient conditions
Certificates
Electrical & Exhaust
Exhaust working point
Voltage & power consumption
(Machine without chiller
Camera compensation system for print&cut applications
Exhaust mounted to working head
Digitally controlled sectioning of table exhaust; 4 exhaust sections
For all power levels
Ultrasonic-based autofocus system
CAD / CAM software for perfect cutting results; nesting-function, lead-
in/lead-out, tool paths, etc. included
Comprehensive package of technical services
3.076 x 3.914 x 1.230 mm (121 x 154 x 49 in)
1.600 kg (3.530 lbs)
720 x 835 x 930 mm (117 x 33 x 37 in) (400 watts model)
130 kg (287 lbs) (400 watts model)
800 x 600 x 1.126 mm (32 x 24 x 45 in)
40 kg (88 lbs)
2.082 x 714 x 2.852 mm (82 x 29 x 113 in)
165 kg (363 lbs)
Fully enclosed beam path CDRH laser safety class 4 laser; can be op-
erated like laser class 2 in standard operation mode
Fully enclosed beam path as well as active laser deflector shield at
working head
Light barriers and safety bumpers for beam path and gantry
Encoded duplicate interlock safety system
Mandatory ambient temperature +15° to +25° C or 59° to 77° F
Humidity 40% to max. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
CE compliant
Min. 2.500 m³/h at 800 Pa (Min. 1.200 cfm at 8.900 in H
(Table exhaust)
Min. 100 m³/h at 4.450 Pa (Min. 60 cfm at 17.865 in H
(Travelling exhaust)
Minimum requirement for acrylic cutting; Depending on application
3x400V (3xL+N+PE) 50/60Hz, max. 1,6 kW (60 watts)
3x400V (3xL+N+PE) 50/60Hz, max. 3,1 kW (100 watts)
3x400V (3xL+N+PE) 50/60Hz, max. 4,5 kW (200 watts)
3x400V (3xL+N+PE) 50/60Hz, max. 8,4 kW (400 watts)
O)
2
O)
2
