Summary of Contents for Trotec BD8A
- Page 1 BD8A INSTRUCTIONS CROSS LINE LASER...
-
Page 2: Table Of Contents
Otherwise do not use the device. out your tasks quickly and safely. • Observe the storage and operating conditions (see Follow the manual Technical data). Information marked with this symbol indicates that the instructions must be observed. cross line laser BD8A... - Page 3 When working with a laser of class 2, observe the atmospheres or in liquids. Never point it at people or animals. national regulations on wearing eye protection. Trotec accepts no liability for damages resulting from improper use. In such a case, any warranty claims will be voided. Warning...
-
Page 4: Information About The Device
360° line • Battery-powered • Integrated ¼ inch tripod connection Device depiction Front Designation Laser Display Operating elements Battery compartment USB-C port Self-levelling switch Accessories Designation Batteries USB cable Tripod mounting plate Platform Mini tripod Wall bracket cross line laser BD8A... -
Page 5: Transport And Storage
• the storage temperature complies with the values specified • 1 x Cross line laser BD8A in the Technical data • 1 x USB cable • 1 x Wall bracket • 1 x Height-adjustable platform • 1 x Tripod mounting plate • 1 x Tripod • 1 x Manual cross line laser BD8A... -
Page 6: Operation
Inclination angle y-axis Self-levelling status on/off Notice The battery can be damaged in case of improper Laser status charging. Laser brightness Never charge the battery at ambient temperatures below 10 °C or above 40 °C. cross line laser BD8A... - Page 7 In self-levelling mode, the device display (22). automatically compensates for an angle of up to 3.5° and aligns the laser lines horizontally or vertically. In the inclination mode, the device can be aligned at any angle. cross line laser BD8A...
- Page 8 1. Open the bar on the side of the mounting plate. 2. Slide the device sideways into the recess on the mounting plate. 3. Close the bar on the side of the mounting plate until it perceptibly clicks into place. cross line laser BD8A...
- Page 9 Adjusting screw 1 Adjusting screw 2 Tripod leg mounting plate Adjusting screw 3 Tripod legs with screw threads ü The tripod mounting plate is attached. 1. Screw the tripod into the tripod thread at the bottom of the mounting plate. cross line laser BD8A...
- Page 10 5. Screw the wall bracket into the tripod thread of the 2. Turn the adjusting screw clockwise to lower the platform. mounting plate at the bottom of the device. Switching the device off 1. Press the Power button (16) for approx. 3 seconds to switch the device off. cross line laser BD8A...
-
Page 11: Maintenance And Repair
Do not use any aggressive cleaning agents (see chapter Cleaning)! If you detect dirt underneath the glass covers or scratches, please contact the customer service. Laser is weak: • Check the battery status and recharge the batteries if required. cross line laser BD8A... - Page 12 Trotec GmbH Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
