4. Using two of the screws (C) supplied, fasten the screws
through the bracket and into the counter, cabinet or wall.
IMPORTANT
Certain cabinets or countertops may require special
fasteners or additional wood blocking to anchor properly.
CAUTION
Make sure the screws are back far enough so they do not
damage any exposed front surface of the cabinet.

Installation Troubleshooting

Q:
Problem
The drawer remains open unless it is pushed closed.
A:
Solution
The drawer should be self-closing when it is open
approximately 8". If it is not, re-check leveling from front
to back of the unit and readjust if necessary.
www.U-LineService.com
2075DWRR — Drawer Model Refrigerator
9 Start-Up for the First Time

Initial Start-Up

Once installation and leveling is complete, the unit is
ready for initial start-up and operation. The ON/OFF
switch is located in the front grille (see Figure 27).
Put the ON/OFF switch in the ON position.
Figure 27
Temperature Controller
The temperature controller (Figure 28) is located in the
top drawer. It consists of an LED display, two LED status
indicator lights and three touchpad buttons. The LED
display shows the temperature set point and is calibrated
in degrees Fahrenheit. The controller is factory
programmed for a set point of 38°F which will show when
the unit is first powered up.
Figure 28
To display actual temperature, press the "WARMER"
button momentarily. A solid status indicator light
(1, Figure 28) will show the air temperature reading in
the cabinet for approximately 10 seconds.
To adjust the temperature set point, press the "SET TEMP"
button momentarily; the display will flash. Press the
"WARMER" or "COOLER" button as desired to change the
set point. When the desired set point shows on the
display, wait 10 seconds and the new set point will be
saved. Wait 24 hours for the temperature to stabilize
before checking the actual temperature again. The
refrigerator set point range is 34°F to 45°F.
14
™
ON/OFF
Switch
1 2
