Other Site Requirements - U-Line Echelon 2075DWRRSS Installation Manual

The drawer unit can be installed with an appliance or
fixture located in front of it, as long as there is adequate
clearance for the drawer to be opened and removed
when servicing (see Figure 4).
Note: U-Line recommends you consider additional
clearance in front of the open drawer for convenience.
Figure 4
www.U-LineService.com
2075DWRR — Drawer Model Refrigerator
24" Min.

Other Site Requirements

Power Supply
The unit requires a grounded and polarized 115 VAC,
60 Hz, 15A circuit (normal household current). See
Electrical Specifications on Page 12.
Environmental Requirements
The surrounding air temperature must be at least 50°F
(10°C) but must not exceed 110°F (40°C). Units may be
installed outdoors in a covered area. The unit must not be
located near heat-generating equipment or in direct
sunlight.
6
™
02/2005
