MONTAGE DER WANGE
FITTING SIDE COVER
A
HÖHENVERSTELLUNG
HEIGHT ADJUSTMENT
6
B
Achtung: Vor Inbetrieb-
nahme unbedingt die bei-
liegende Bedienungsanlei-
tung lesen!
Caution: The enclosed
operating instructions must
be read before initial
operation!
unterer Höhenausgleich max. 10 mm
height levelling adjustment 10 mm
2x
M10 x 35
SW 8
