COMPONENTS REQUIRED TOOLS Supplied Not supplied Spanner (washer) Box cutter Spanner (plinth) Phillips screwdriver Allen key Level PARTS Supplied Supplied (not required*) 1x Cold water hose 1x Communication cable 1x Hot water hose 2x Dryer front brackets 1x Blanking cap 2x Dryer rear brackets 7x Plugs 2x Dryer rear mounting screws...
Page 3
ACCESSING YOUR PRODUCT SPECIFICATIONS For full product, cabinetry and service specifications, refer to the Planning Guide. To access the Planning Guide, scan the QR code or visit fisherpaykel.com/specify. Search by appliance type, product name or model code. 1042...
PRIOR TO INSTALLATION 1. Ensure cabinetry and servicing specifications have been met and clearances have been considered. Refer to the Planning Guide for details. fisherpaykel.com/specify 2. Ensure floor is level and clear and a finished return has been created. 3. Ensure power will remain accessible following install to allow access for any future product maintenance.
Page 5
UNPACK 1. Cut the straps and the line printed on the top of the washer carton. Lift to remove. Discard braces and corner posts. Remove any packaging and accessories from the drum and base packer. Dispose of packaging responsibly. 2. Cut the straps and tape to open the plinth carton from the top.
Page 6
LEVEL PLINTH 1. Push the front of the plinth to open. Remove the divider before closing the drawer. 2. Place the plinth in its final install location. Adjust the feet using the supplied spanner until the plinth is level front to back and corner to corner.
Page 7
FIT WASHER TO PLINTH 1. Tilt the washer back onto a protected surface such as the plinth carton. Ensure cords and hoses are not crushed. For new products, we recommend keeping the transit bolts fitted during this step. 2. Unwind feet using the supplied spanner to remove.
Page 8
FIT WASHER TO PLINTH 4. Using the spanner provided as a spacer, ensure a 4mm gap is left between the bolt head and the chassis. 5. Align all four brackets to the M10 bolts on the washer and slot into place. 6.
Page 9
FIT WASHER TO PLINTH 7. Lift the washer upright, avoiding lifting from the lid. Take care as storage drawer may open. 8. Tighten the rear bolts.
Page 10
REMOVE WASHER TRANSIT BOLTS 1. Using the supplied spanner, remove all four transit bolts from the back of the washer. 2. Pull the rubber grommets and spacers outwards to remove. 3. Using a Phillips screwdriver, remove the two side brackets.
Page 11
REMOVE WASHER TRANSIT BOLTS 4. Remove and discard the braces. 5. Pull the two transit rods outwards to remove. Set aside for future use. 6. Cover the transit bolt holes using the supplied plugs.
Page 12
RAISE PRODUCT SET 1. Partially roll stacked products into alcove and check alignment. To do this, use the supplied 6mm hex key, rotate clockwise to lower both sets of wheels via the adjustment screws. 2. Ensure all feet are raised off the floor before rolling the plinth to the final install location.
Page 13
CONNECT CABLES AND HOSES 1. Refer to the Planning Guide for full service information. Supply: 220 - 240V, 50Hz Service: 10A Outlet: 3-prong grounding-type Supply: Hoses provided Pressure: 50KPa (7psi) - 1MPa (150psi). Min 6 litres/min. fisherpaykel.com/specify 2. Connect the angled end of cold hose to the cold water inlet on the washer.
Page 14
CONNECT CABLES AND HOSES 4. Partially roll products into the alcove. Take care not to crush the cables and hoses. 5. Route the power cables and hoses through service holes. Ensure power will remain accessible following install to allow access for any future product maintenance.
Page 15
CONNECT CABLES AND HOSES 7A. Standpipe Installations: Route the drain hose through the guide and place into the 20mm standpipe. Ensure a maximum of 20mm of the hose rests in the standpipe. 7B. Spigot Installations: Drill out blanking insert from the spigot.
Page 16
CONNECT CABLES AND HOSES 9. Connect the power cable and check washer is powered on and connected.
Page 17
INSTALL WASHER 1. Roll washer into the alcove. Take care not to damage hoses or power cord. 2. Turn the adjustment screw counter-clockwise to retract Floor the wheels. Ensure the wheels are fully raised off the floor. 3. Check alignment and ensure required clearances are maintained.
Page 18
INSTALL WASHER 4. Once adjustment is complete, fit the plinth bolt hole covers.
