- Page 1 SC250 Operator manual – English www.crescentindustrial.co.uk...
-
Page 2: Table Of Contents
INSTRUCTIONS FOR USE ENGLISH TABLE OF CONTENTS INTRODUCTION ................................2 MANUAL PURPOSE AND CONTENTS ............................2 TARGET ......................................2 HOW TO KEEP THIS MANUAL ............................... 2 DECLARATION OF CONFORMITY ..............................2 IDENTIFICATION DATA ................................... 2 OTHER REFERENCE MANUALS ..............................2 SPARE PARTS AND MAINTENANCE ............................. -
Page 3: Introduction
ENGLISH INSTRUCTIONS FOR USE INTRODUCTION NOTE The numbers in brackets refer to the components shown in Machine Description chapter. MANUAL PURPOSE AND CONTENTS The purpose of this Manual is to provide the operator with all necessary information to use the machine properly, in a safe and autonomous way. -
Page 4: Conventions
INSTRUCTIONS FOR USE ENGLISH CONVENTIONS Forward, backward, front, rear, left or right are intended with reference to the operator’s position when in use. UNPACKING/DELIVERY When the machine is delivered, check that the packing and the machine were not damaged during transportation. In case of visible damages, keep the packing and have it checked by the carrier that delivered it. -
Page 5: General Instructions
ENGLISH INSTRUCTIONS FOR USE GENERAL INSTRUCTIONS Specific warnings and cautions to inform about potential damages to people and machine are shown below. DANGER! – Before performing any maintenance, repair, cleaning or replacement procedure disconnect the battery. – This machine must be used by properly trained operators only. –... - Page 6 INSTRUCTIONS FOR USE ENGLISH WARNING! – This machine is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the machine by a person responsible for they safety. Children should be supervised to ensure that they do not play with the machine.
-
Page 7: Technical Data
ENGLISH INSTRUCTIONS FOR USE TECHNICAL DATA Model SC250, Scrubtec 334 Solution and recovery water tank capacity 6 litres / 6 litres Machine size (length x width x height) 630 x 425 x 400 mm Cleaning width 340 mm Squeegee width 360 mm Rear rotating wheel diameter 75 mm... - Page 8 INSTRUCTIONS FOR USE ENGLISH MACHINE STRUCTURE (Continues) P100930 9100001614 - SC250, Scrubtec 334 07/2016...
-
Page 9: Accessories/Options
ENGLISH INSTRUCTIONS FOR USE ACCESSORIES/OPTIONS In addition to the standard components, the machine can be equipped with the following accessories/options, according to the machine specific use: – Cylindrical brush SOFT NYLON BLACK – Cylindrical brush MEDIUM NYLON WHITE – Cylindrical brush HARD GRIT 120 GREY –... -
Page 10: Park Pedal
INSTRUCTIONS FOR USE ENGLISH PARK PEDAL NOTE In order to facilitate the use of the park pedal (10), slightly lift the front section of the machine by gaining leverage with your hands on the handlebar (A, Fig. For parking/handling: Putting your hands on the handlebar (A), slightly lift the front section of the machine, then press the pedal (B, Fig. -
Page 11: Starting Up The Machine (Scrubbing/Drying)
ENGLISH INSTRUCTIONS FOR USE STARTING UP THE MACHINE (SCRUBBING/DRYING) Press the lever (8) and turn the handlebar (1), adjusting its position and inclination as preferred. Ensure that the park pedal (10) is lowered, then push the machine over to the area to be cleaned. Lift the park pedal (10) to bring the brush/squeegee unit in contact with the floor. -
Page 12: Battery Charge Level
INSTRUCTIONS FOR USE ENGLISH BATTERY CHARGE LEVEL 80% 100% The battery charge level can be viewed on the battery icon LEDs (5). The battery charge percentage depends on the number of LEDs lit, as shown in the figure 5. When the first left LED flashes (15 %), the machine will only run for a few more minutes (this will depend on the characteristics of the work to perform). -
Page 13: After Using The Machine
ENGLISH INSTRUCTIONS FOR USE AFTER USING THE MACHINE After working, before leaving the machine: Stop and turn off the machine, then lift the brush/squeegee unit using the pedal (10). Empty the tanks (13). Park the machine as shown in the figure 7; for lowering the handlebar (1) press the lever (8). -
Page 14: Battery Charging
INSTRUCTIONS FOR USE ENGLISH BATTERY CHARGING CAUTION! Charge the battery when only one LED of the battery symbol is lit (5). When the battery is discharged, charge is as soon as possible, as that condition makes its life shorter. Check for battery charge at least once a week. -
Page 15: Squeegee Bar Cleaning
ENGLISH INSTRUCTIONS FOR USE SQUEEGEE BAR CLEANING CAUTION! It is advisable to wear protective gloves when cleaning the squeegee bars because there can be sharp debris. NOTE The squeegee bars must be clean and the blades must be in good conditions in order to get a good drying. -
Page 16: Recovery Tank And Cover Cleaning
INSTRUCTIONS FOR USE ENGLISH RECOVERY TANK AND COVER CLEANING Lift the tanks container (13) from the machine body using the handle (15). Remove the cover (A, Fig. 11) and clean it with hot water. Remove the suction grid (B) along with the float and clean them thoroughly. -
Page 17: Troubleshooting
ENGLISH INSTRUCTIONS FOR USE TROUBLESHOOTING Trouble Possible Cause Remedy The motors do not turn on; no LED The battery is completely discharged. Charge the battery. turns on. Change the battery. Switch panel broken. Replace the switch panel. (*) Broken grip handle sensors. Replace the grip handle sensors. - Page 18 We supply a full range of cleaning equipment for rental or purchase. For more information, or a cleaning solution to suit your business, please get in touch – For a more comprehensive product range, please visit our website. Address Contact Berrington House, t: 0845 33 77 695 Berrington Road,...
