Integrated Rigging
WPM
WPM USER GUIDE V2
Copyright © 2023 Martin Audio Ltd.
FRONT RIGGING POINTS
RIGGING PIN
HANDLE
REAR DROP LINK
WPM's three-point rigging system consists of two rigging points at
the front and a single rigging point at the rear of the cabinet.
The rear drop down link is equipped with a single hole at the top for
linking to cabinets above it.
Five rigging holes labeled for 0.5°, 2°, 4°, 6.5° and 10° inter-
cabinet angles, as well as a rigging hole for use when assembling
ground stacked arrays.
23
WPM USER GUIDE
REAR RIGGING POINT
HANDLE
