SPIRAL MIXER OPERATION MANUAL
AE-1220 / AE-3050 / AE-4065 / AE-5080
WARRANTY REGISTRATION
GO TO: WWW.AMERICANEAGLEMACHINE.COM OR
MAIL THE ENCLOSED WARRANTY REGISTRATION CARD
WARRANTY NOT VALID UNLESS REGISTERED!
REGISTRATION MUST BE COMPLETED WITHIN 30 DAYS OF
PURCHASE AND INCLUDE A COPY OF INVOICE OR RECEIPT
SAVE THIS MANUAL FOR FUTURE REFERENCE
Proud Member of:
Quality • Value • Reliability
Revision 1/2017
Copyright © 2017, American Eagle Food Machinery, All rights reserved
Advertisement
Table of Contents
Related Manuals for American Eagle AE-1220
Summary of Contents for American Eagle AE-1220
- Page 1 REGISTRATION MUST BE COMPLETED WITHIN 30 DAYS OF PURCHASE AND INCLUDE A COPY OF INVOICE OR RECEIPT SAVE THIS MANUAL FOR FUTURE REFERENCE Proud Member of: Quality • Value • Reliability Revision 1/2017 Copyright © 2017, American Eagle Food Machinery, All rights reserved...
-
Page 2: Table Of Contents
AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual Index INTRODUCTION AND NOTICE TO USER..................2 KEY COMPONENTS AND SPECIFICATIONS ................3 IMPORTANT SAFETY RULES INSTALLATION INSTRUCTIONS................5 CLEANING PROCEDURES .6-7 ELECTRICAL CONNECTIONS ....................7 PANEL AND MIXING OPERATION ..........8-9 TROUBLESHOOTING .......................10 LIMITED WARRANTY STATEMENT..................11... -
Page 3: Introduction And Notice To User
Operation Manual Introduction and Notice to User Thank you for choosing to purchase an American Eagle machine! American Eagle Food Machinery, Inc. has been manufacturing and distributing restaurant and bakery equipment for over 30 years. Our machines are designed for heavy duty, commercial use, and are ETL certified to NSF No. -
Page 4: Key Components And Specifications
AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual Key Components and Specifications Safety Guard Control Panel Emergency Stop Switch Agitator Bowl Adjustable Feet Specifications Agitator Ship Voltage Model Capacity Motor Amps Transmission V/HZ/PH Speeds Weight Weight 1.5 HP 40 Quarts... -
Page 5: Important Safety Rules
AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual IMPORTANT SAFETY RULES • ONLY install equipment on a clean, level, non-skid surface and in a well-lit area. • ALWAYS make sure that your outlet meets the electrical specifications of the machine. -
Page 6: Installation Instructions
2. Thoroughly clean the machine before using. Refer to Cleaning Procedures section. 3. Contact American Eagle if you have any questions or problems with the installation or operation of this mixer. Do not return to retailer or dealer! MOVING THE MIXER: 1. -
Page 7: Cleaning Procedures
AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual Cleaning Procedures TO AVOID SERIOUS INJURY AND DAMAGE TO MACHINE: • BEFORE CLEANING, SERVICING, OR REMOVING COMPONENTS, always unplug the machine. • DO NOT attempt to clean while the mixer is in operation. -
Page 8: Electrical Connections
AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual Cleaning Procedures SPIRAL MIXER CLEANING & SANITIZING: 1. Make sure the unit is turned off and disconnected from the power outlet. 2. After each day’s use, wash the mixer bowl and agitator thoroughly with hot water and a mild soap solution and rinse with either a mild soda or vinegar solution. -
Page 9: Panel And Mixing Operation
• Low Speed Timer Example Control Panel is that of High Speed Timer model AE-3050. Models AE-3050, AE-4065, and AE-5080 have dual timers. Model AE-1220 does not. Stop Button Low Speed Button Bowl Rotation High Speed Button Switch Toggle Switch 773.376.0800 (P) •... - Page 10 AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual Panel Operation Function Do This Result Desired Manual control Turn TOGGLE SWITCH MANUAL Starts low speeding mixing. Press LOW SPEED BUTTON Manual (Continuous) Starts high speed mixing. Mixing Press HIGH SPEED BUTTON Mixing pause.
-
Page 11: Troubleshooting
AE-1220 / AE-3050 / AE-4065 / AE-5080 Operation Manual Troubleshooting Issue Possible Cause Check to see that the bowl guard is in lower position. Check electric cord to see if it is plugged into receptacle. Check electrical supply at breaker (fuse) box. -
Page 12: Limited Warranty Statement
Parts: 1 Year • Labor: 1 Year All equipment, which is sold under American Eagle Food Machinery, Inc. (AEFM) trademark and used for commercial purposes, is warranted against defects in materials and workmanship for a period of one year parts and 90 days labor, except as specifically defined below.
