Savant HST-STUDIO46-2CH Deployment Manual

Ip audio studio with integrated host
Hide thumbs Also See for HST-STUDIO46-2CH:

Advertisement

Quick Links

Savant® IP Audio Studio with Integrated Host
HST-STUDIO46-2CH | HST-STUDIO55-2CH
Deployment Guide
Document Number:
009-1839-01
Document Date:
August 2019
Document Supports:
da Vinci 9.1
Copyright © 2019 Savant System, LLC
45 Perseverance Way, Hyannis, MA 02601
Savant.com
| 508.683.2500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HST-STUDIO46-2CH and is the answer not in the manual?

Questions and answers

Summary of Contents for Savant HST-STUDIO46-2CH

  • Page 1 Savant® IP Audio Studio with Integrated Host HST-STUDIO46-2CH | HST-STUDIO55-2CH Deployment Guide Document Number: 009-1839-01 Document Date: August 2019 Document Supports: da Vinci 9.1 45 Perseverance Way, Hyannis, MA 02601 Copyright © 2019 Savant System, LLC Savant.com | 508.683.2500...
  • Page 2: Table Of Contents

    7.1. Accessing the Web UI ..............................15 7.2. Status Tab ...................................16 7.3. Network Tab ..................................16 7.4. Inputs & Outputs Tab ..............................17 Appendix: Network Requirements ......................18 Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1839-01 | 190801...
  • Page 3 Important Safety Information - Read First Safety Statements Before installing, configuring, or operating any equipment, Savant recommends All safety instructions below should be read, understood, and applied under all that each dealer, integrator, installer, etc. access and read all relevant technical relevant circumstances when working with this equipment.
  • Page 4: Introduction

    Appendix: Network Requirements Deployment Steps Follow these steps to successfully deploy Savant IP Audio Studio with Integrated Host. This page can be used as a checklist to record which steps have been completed. Review product specifications and connection details ....................
  • Page 5: Equipment Overview

    The IP Audio Soundbar complements the Savant family of IP Audio and IP Video solutions for distributing audio over IP networks and is expertly designed to provide a rich, detailed and immersive sound from your favorite sources. It is also part of the Savant from source to speaker audio...
  • Page 6 Hold Reset Button for 5 seconds while powered On to clear static IP Address settings. Status LED will rapidly blink red when reset is complete. Digital Audio Digital optical audio inputs (TOSLINK). Supports up to 192kHz/24-bit digital audio in; PCM stereo format only. Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1839-01 | 190801...
  • Page 7: Wiring And Connections

    3. Wiring and Connections The Savant IP Audio Soundbar control connections send data to control a device and receive data to display current status on the user interfaces or trigger a system action. Each port type may support multiple protocols that are determined by the logical connection within Blueprint.
  • Page 8: Network Connection

    4. Savant Music The IP Audio Studio with Integrated Host has a single stream of Savant Music. This allows the use of popular music streaming services such as Pandora or Spotify (streaming music service fee may apply). For a full list of supported services, see Savant Media Server/Savant Music Supported Streaming Services on the Savant Customer Community.
  • Page 9: Installation

    4. Choose the desired Mounting Bracket (use the Bracket Selection table on the previous page). Find the screws that fit the TV’s VESA mounting points. Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1839-01 | 190801...
  • Page 10 Mounting Bracket UMB Stabilizer Reattach to the TV mount/stand. Break off the any additional thread of the stabilizer with a pair of pliers. Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1839-01 | 190801...
  • Page 11: Blueprint

    DIGITAL AUDIO OUT (Digital Optical) Control Ports IR(Serial PWM) Output 1 RS-232 1 Assigned Inputs Audio Input 1 Digtial Audio In 1 (Digital Optical) Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1839-01 | 190801...
  • Page 12: Replacing A Host In A Configuration

    Layout Window. Enter a unique Device Name and the Savant UID for the host. The Savant UID is used to identify the host on the network so that a configuration may be uploaded. A. Select the Host in the Layout Window and open the Inspector by navigating to: View >...
  • Page 13: Adding A Host To The Layout Window

    Dresden45 Host Savant UID: Notes: Enter a unique Device Name and the Savant UID for the host. The Savant UID is used to identify the host on the network so that a configuration may be uploaded. Show: Data I/Os D. Select the host in the Layout Window and open the...
  • Page 14: Ip Audio Soundbar

    LEARN MORE For more information on using the IP Audio Studio with Integrated Host in a system with other AVB devices see the Savant IP Audio Speaker and Soundbar Deployment Guide or the Savant IP Audio Deployment Guide on the Savant Customer Community.
  • Page 15: Web User Interface (Web Ui)

    Go To Audio Controller Page Go To Lighting Page NOTE: For information on the Lighting Page, see the System Monitor Reference Guide section on WiFi Lighting on the Savant Customer Community. Savant IP Audio Studio with Integrated Host Deployment Guide Copyright ©...
  • Page 16: Status Tab

    NOTE: Setting the IP address to a static address from the WebUI will automatically set the DNS for the Host to 8.8.8.8 and 8.8.4.4 (Google). Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC...
  • Page 17: Inputs & Outputs Tab

    IP Audio devices these changes are made in 1dB increments. Subwoofer Configuration Toggle on or off. If on it enables a fixed high pass filter at 80Hz. Savant IP Audio Studio with Integrated Host Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1839-01 | 190801...
  • Page 18: Appendix: Network Requirements

    Device Network Connections Connect all Savant devices to the same local area network (LAN) or subnet as the host. Savant recommends not implementing any type of traffic or packet shaping in your network topology for the Savant devices as this may interfere with performance.
  • Page 19 Savant Systems, LLC. shall not be liable for any technical or editorial errors or omissions contained herein or for incidental or consequential damages resulting from the performance, furnishing, reliance on, or use of this material.
