Savant HST-STUDIO46BG-2CH-00 Quick Reference Manual

Savant® IP Audio Studio with Integrated Host and Grille - Black
Quick Reference Guide
Product Specific Contents
IP Audio Studio SoundBar 46 [HST-STUDIO46BG-2CH]
(1) Soundbar (093-3100-xx)
(1) Standard Grille (093-3225-xx)
IP Audio Studio SoundBar 55 [HST-STUDIO55BG-2CH]
(1) Soundbar (093-3102-xx)
(1) Standard Grille (093-3226-xx)
Universal Box Contents
(1) Power Cord (064-0480-xx)
(2) 6-pin Control Connector [pre-installed] (028-9352-xx)
(1) Install Kit (075-0256-xx)
(1) Pair of White Gloves (099-0348-xx)
(2) Wall Mounting Bracket (071-1130-xx)
(1) 3mm Allen Wrench (015-0222-xx)
(8) M5x10mm hex screw (039-0440-xx)
(4) 25mm Washer 5mm ID (039-0437-xx)
(2) 50x90 Bracket Extension (071-1112-xx)
(2) 70x90 Bracket Extension (071-1113-xx)
(2) Plastic Feet (074-1030-xx)
(2) Rubber Pads for Feet (073-0014-xx)
(1) Product Regulatory Insert (009-1950-xx)
Optional Accessories (sold separately)
–
Soundbar TV Mount Hardware (MNT-STUDIO-TV-xx)
– Custom Grilles matched to Flat Panel TV
Front Panel
A B
HST-STUDIO55BG-2CH-xx
HST-STUDIO46BG-2CH-xx
STUDIO46:
(2) 25 mm Vifa DX Super Audio Tweeters
A
Front Tweeters
STUDIO55:
(2) 25 mm Vifa XT Super Audio Tweeters
Midrange/ (4 or 6) 89 mm Long Throw Carbon Fiber
B
Woofers Midrange/Woofers
IP Audio Studio with Integrated Host QRG | 009-1835-05
Copyright © 2022 Savant Systems, Inc. | 220829
Specifications
Environmental
Temperature
Humidity
Dimensions and Weight
STUDIO46 Dimensions
(with included grille)
STUDIO55 Dimensions
(with included grille)
STUDIO46 Shipping
STUDIO55 Shipping
Power
Input Power
Maximum Power Draw
Networking
Supported Standard
Operating Parameters
Frequency Response
Sensitivity
Regulatory
Safety and
Emissions
RoHS
Minimum Supported Release
Software Release
1 of 2
32° to 104° F (0° to 40° C)
10% to 90% Relative Humidity (non-condensing)
Height Width Depth
4.78 in 45.4 in 2.76 in
(12.14 cm) (115.32 cm) (7.03 cm)
4.67 in 54.1 in 2.76 in
(11.87 cm) (137.41 cm) (7.03 cm)
9.25 in 54.5 in 6.1 in
(23.49 cm) (138.43 cm) (15.94 cm)
9.6 in 63.2 in 6.5 in
(24.38 cm) (160.52 cm) (16.51 cm)
100/240V AC (50/60 Hz)
250W
IEEE 802.1 AVB/TSN switches
80 Hz - 40 kHz +/- 3 dB
89 dB @ 2.83V/1 meter
FCC Part 15B CE Mark
Compliant
da Vinci 9.1
45 Perseverance Way, Hyannis, MA 02601
Savant.com
Weight
13.5 lbs
(6.12 kg)
20.0 lbs
(9.07 kg)
20.0 lbs
(9.07 kg)
26.5 lbs
(12.02 kg)
C-Tick UKCA
| 508.683.2500
