- Page 1 LAN ER300-GLOBAL Industrial LAN-to-LAN router User manual Doc. No. BA001314 Last Update: 06/2023 (Rev. A)
- Page 2 Notes NOTES This document is copyright-protected. The rights derived from this copyright are reserved for Wieland Electric. Reproduction of this document or parts of this document is only permissible within the limits of the statutory provision of the Copyright Act. Any modification or abridgment of the document is prohibited without the express written agreement of Wieland Electric.
-
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS About this manual Function of the manual Other applicable documents Target group Symbols and notations Safety Hazardous locations installation instructions General safety instructions Product Overview Product Introduction Router Versions Delivery Identification Product Label Order numbers Hardware Overview Package Contents Product Dimensions... - Page 4 Table of Contents Type Tests and Environmental Conditions Parameters of I/O Ports System Configuration Troubleshooting Disposal Service and Support Wieland Electric GmbH | BA001314 | 06/2023 (Rev. A)
-
Page 5: About This Manual
About this manual ABOUT THIS MANUAL Please read this chapter carefully before using the user manual or the products. Function of the manual This user manual provides technical staff with information about the device and its functions. This manual contains the necessary information for the intended use and the technical data of the projects described in it. -
Page 6: Symbols And Notations
About this manual Symbols and notations The symbol "DANGER" means an imminent danger. If it is not avoided, it can result in death or serious injury. "DANGER" is used to warn against risks that already apply at the time of the warning (e.g. hot surfaces, sharp edges, pinch points, etc.). -
Page 7: Safety
Safety SAFETY Hazardous locations installation instructions These devices are open-type devices that are to be installed in an enclosure suitable for the environment and can only be accessed with the use of a tool or key. This equipment is suitable for use in Class I, Division 2, Groups A, B, C, and D or nonhazardous locations only. -
Page 8: Product Overview
Product Overview PRODUCT OVERVIEW Product Introduction The wienet LAN ER300 GLOBAL LAN-to-LAN router is designed for wired communication in Ethernet networks. The device is ideal for making a secure connection between two local networks (LANs). The device can also be used as a simple LAN-to-LAN router. Another, equally important possible use is to connect any device via RS232, RS485 or I/O interface to a local network (LAN). -
Page 9: Delivery Identification
Product Overview Delivery Identification Table 3: Delivery Identification wienet Trade name LAN ER300 GLOBAL Type name Router in metal box other Product Label An example of the product label, with all the information printed on it, is in Figure 2. Figure 2: Label Example Order numbers Order codes overview is shown in Table 4. -
Page 10: Hardware Overview
Product Overview Hardware Overview You can find a depiction of the router enclosure in Figure 3 and Figure 4. A brief description of the hardware parts of the router is provided in Table 5 which includes links to the chapters with a detailed description. -
Page 11: Package Contents
Product Overview Package Contents The standard set of router includes items listed in Table 6. Table 6: Package Contents Item# Description Figure Q'ty router 1 pcs DIN rail clip 1 pcs Wall mounting set (pre- 1 pcs mounted) Installation instructions 1 pcs 2-pin screw clamp PWR (pre- 1 pcs... -
Page 12: Product Dimensions
Product Overview Product Dimensions For the dimensions of the product see Figure 4 and Figure 5. Note that all sizes are measured in millimeters. Figure 4: Product Dimensions – Front View Figure 5: Product Dimensions (with wall mounting clip) – Top View Wieland Electric GmbH | BA001314 | 06/2023 (Rev. -
Page 13: Mounting And Removal
Mounting and Removal MOUNTING AND REMOVAL Mounting Recommendations The router can be placed: • on a flat surface, • on a wall (or other surface) via pre-mounted side wings, • on a DIN rail EN 60715 with the metal DIN rail clip. see chapter 4.2 "DIN Rail Mounting", p. 14. For most applications with a built-in router within a switchboard, it is possible to recognize two kinds of environments: •... -
Page 14: Din Rail Mounting
Mounting and Removal DIN Rail Mounting The DIN rail clip is supplied with the router as standard accessories. NOTICE The DIN rail clip is suitable for a DIN rail according to EN 60715 standard only. The default position of the clip is shown in Figure 6. When mounting the wall mounting clip, tighten the screws with max. -
Page 15: Hardware Functionality
Hardware Functionality HARDWARE FUNCTIONALITY See chapter 3.6 "Hardware Overview", p. 10 for the product hardware overview. Table 5 lists a short description of the hardware, including the links to the chapters with a detailed description. Ethernet Interfaces The panel socket of RJ45 is used for Ethernet interface. The pinout of the socket is shown in Figure 8 and described in Table 7. -
Page 16: Power Supply
Hardware Functionality Power Supply The power supply pins are physically connected to the 2-pin terminal on the front of the device. The power supply connection is depicted in Figure 9 and described in Table 8. Figure 9: Connection of Power Supply Table 8: Power Supply Pinout Signal mark Description... - Page 17 Hardware Functionality Low Power Mode Low Power Mode (LPM) is perfectly suited to applications with a low power consumption. It is recommended that you activate LPM before the whole router is shut down. This can be done via a command in the web interface under the Scripts menu element. The command has 2 parameters. The command looks like this: lpm [-b] [-i <interval>] With the parameter –b, you can activate the router via the binary input BIN0;...
-
Page 18: Serial And I/O Port Interfaces
Hardware Functionality Serial and I/O port interfaces The pins of the serial interfaces RS232 and RS485 are connected, together with the I/O interface, physically to the 10-pin terminal on the left side of the device. None of the 3 interfaces are isolated from the router. -
Page 19: Led Status Indication
Hardware Functionality The I/O user interface is intended for processing binary inputs and controlling binary outputs. By default, the binary output is open, i.e., not grounded. The maximum binary output load is 36 V at 500 mA. The constant current supplied by the binary input is 3 mA. The functional connection scheme of the binary input and output is shown in the following figure. -
Page 20: Reset Functions
Hardware Functionality Reset Functions The RST button on the front panel can be used in three different situations: • Reboot the router: Hold the RST button for less than 4 seconds, the router will be restarted. • Factory reset – restore the default configuration: Hold the RST button for more than 4 seconds. The PWR LED turns off and on again. -
Page 21: First Use
First use FIRST USE Before starting up the router, all components required to execute your applications must be connected. Powering up the Router The router starts as soon as it is connected to the mains. The DHCP server assigns an address to the devices that are connected via the Ethernet port ETH0. - Page 22 First use Figure 14: Router's Web Interface A detailed description of the router settings in the web interface can be found in the configuration NOTICE manual of the router. Wieland Electric GmbH | BA001314 | 06/2023 (Rev. A)
-
Page 23: Technical Specifications
Technical Specifications TECHNICAL SPECIFICATIONS Basic Parameters Table 14: Basic Parameters Router parameters Temperature range Operating -40 °C … +75 °C Storage -40 °C … +85 °C Humidity Operating 0 … 95 % relative humidity, non condensing Storage 0 … 95 % relative humidity, non condensing Altitude Operating 2000 m / 70 kPa... -
Page 24: Type Tests And Environmental Conditions
Technical Specifications Type Tests and Environmental Conditions Table 16: Type Tests and Environmental Conditions Phenomena Testing Description Test levels EN 61000-4-2 Contact discharge ± 6 kV (crit. A) Air discharge ± 8 kV (crit. A) RF field AM EN 61000-4-3 Housing 20 V/m (crit. -
Page 25: System Configuration
Technical Specifications System Configuration The main parameters of the system are listed in Table 18. Table 18: System Configuration Other technical parameters CPU architecture Cortex A8 CPU frequency 1 GHz CPU power 2 DMIPS/MHz Flash Memory Available memory • 2× 256 MB - FW •... -
Page 26: Troubleshooting
Troubleshooting TROUBLESHOOTING If you cannot connect to the router from your PC, your network card may be configured in such a way that it is not possible to connect to the router. Take one or more of the following steps in order to solve the problem: CAUTION •... - Page 27 Troubleshooting Is the router Cisco compatible? Can I use the Cisco configuration? No, the Firmware in the router (Conel OS) is based on Linux with BusyBox. Thus, the Cisco configuration cannot be used. But network connections are defined by standards so connecting the router to the Cisco or other networking devices is possible and will be compatible.
-
Page 28: Disposal
Disposal DISPOSAL The WEEE (Waste Electrical and Electronic Equipment: 2012/19/EU) directive was introduced to ensure that electrical/electronic products are recycled using the best available recovery techniques in order to minimize impact on the environment. This product contains high quality materials and components which can be recycled. -
Page 29: Service And Support
Service and Support SERVICE AND SUPPORT Service-Hotline: +49 951 9324-991 E-Mail: industry@wieland-electric.com Web: http://eshop.wieland-electric.com Wieland Electric GmbH Brennerstraße 10 – 14 DE-96052 Bamberg UKCA – for UK: Wieland Electric Ltd | Ash House, Tanshire Park | Shackleford Road | Elstead, Godalming GU8 6LB Wieland Electric GmbH | BA001314 | 06/2023 (Rev. - Page 30 Wieland Electric GmbH Brennerstraße 10 – 14 DE-96052 Bamberg Tel +49 951 9324-0 Fax +49 951 9324-198 info@wieland-electric.com www.wieland-electric.com...
