4.1.3.11. AirDirectionUD_command (Multi-state Output Object Type)

It sets the indoor unit's vertical air direction (up-down).
Property Identifier Property Datatype
Object_Identifier BACnetObjectIdentifier
Object_Name CharacterString
Object_Type BACnetObjectType
Present_Value Unsigned
Description CharacterString
Device_Type CharacterString
Status_Flags BACnetStatusFlags
Event_State BACnetEventState
Reliability BACnetReliability
Out_Of_Service BOOLEAN
Number_Of_States Unsigned
State_Text BACnetArray[N] of CharacterString
Priority_Array BACnetPriorityArray
Relinquish_Default Unsigned
Time_Delay Unsigned
Notification_Class Unsigned
Feedback_Value Unsigned
Event_Enable BACnetEventTransitionBits
Acked_Transitions BACnetEventTransitionBits
Notify_Type BACnetNotifyType
Event_Time_Stamps BACnetArray[N] of BACnetTimeStamp
Profile_Name CharacterString
Table 7. Air direction up-down command
Present_Value
1
2
3
4
5
6
7
8
USER MANUAL Version 2.0.4
Value
(Multi-state Output, 2)
AirDirectionUD_command
MULTISTATE_OUTPUT (14)
1 .. 8
-
-
{FALSE, FALSE, FALSE, FALSE}
STATE_NORMAL (0)
NO_FAULT_DETECTED (0)
FALSE
8
Check the Air direction command table below
-
-
-
-
-
-
-
-
-
-
State_Text
POS1
POS2
POS3
POS4
POS5
POS6
POS7
SWING
BACnet MS/TP and Modbus RTU Server Gateway for Hitachi
ASHRAE Gateway
R R
R R
R R
R W
O -
O -
R R
R R
O R
R R
R R
O R
R R
R R
O -
O -
O -
O -
O -
O -
O -
O -
Page 21 of 65
