Product Overview

A
Robot (Top View)
A1
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
Power Indicator
• White: Battery level ≥ 20%
• Red: Battery level < 20%
• Breathing: Charging or starting up
• Flashing red: Error
—WiFi Indicator Light
• Flashing blue slowly: Waiting for
connection
• Flashing blue quickly: Connecting
• Steady blue for five seconds: WiFi
connected
Spot Clean/Child Lock
• Press to Spot clean
• Press and hold for 3 seconds to
turn on/off the child lock
Dock
• Press to return to dock/start
emptying
Note: Press any button to stop the robot during cleaning
or docking.
A1-1—Vertical Bumper
A1-2—LiDAR Sensor
A1-3—Wall Sensor
A1-4—Dock Locator
A1-5—Reactive Tech Obstacle Avoidance
Sensor
Robot (Bottom View)
A2
A2-1—Cliff Sensors
A2-2—Omnidirectional Wheel
A2-3—Charging Contacts
A2-4—Side Brush
A2-5—Main Brushes
A2-6—Main Brush Cover
A2-7—Main Wheels
Robot
A3
A3-1—Reset Button
A3-2—Air Vent
A3-3—Mop Cloth Mount
A3-4—Bumper
Dustbin and Water Tank
A4
Combo Unit
A4-1—Latch
A4-2—Stopper
A4-3—Water Filter
A4-4—Washable Filter
Power Cable
A5
Mop Cloth Mount
A6
A6-1—Mop Cloth Attachment Slot
A6-2—Mop Cloth Mount Latches
Mop Cloth
A7
A7-1—Hook and Loop Pads
Dustbin (Disposable Dust
A8
Bag Pre-Installed)
Dustbin Cover
A9
06
Disposable Dust Bag
A10
Base
A11
A11-1—Air Duct Cover Screws (10)
A11-2—Air Duct Cover
A11-3—Screwdriver
A11-4—Base Fastening Screws (6)
Auto-Empty Dock
A12
A12-1—Dustbin Cover
A12-2—Dustbin
A12-3—Base
A12-4—Status Indicator Light
• Steady white: Standby
• Flashing white: Emptying
• Steady red: Malfunction
• Light off: Charging Robot/Not
Powered On
A12-5—Dock Location Beacon
A12-6—Charging Contacts
A12-7—Suction Inlet
A12-8—Electrode Brushes
Auto-Empty Dock (Cover
A13
Removed)
A13-1—Dust Bag Slot
A13-2—Filter
Power Cable Storage
A14
A14-1—Power Cable Storage Slot
A14-2—Cable Outlet
A14-3—Power Port
Note: Power cable can be pulled out at both sides.
