Roborock Q8 Max+ User Manual page 10

Side Brush
C2
* Clean monthly and replace every 3-6 months.
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the screw.
Omnidirectional Wheel
C3
* Clean as required.
C3-1— Use a tool, such as a small screwdriver,
to pry out the axle and take out the
wheel.
Note: The omnidirectional wheel bracket cannot be removed.
C3-2— Rinse the wheel and the axle with
water to remove any hair and dirt.
Dry and reattach the wheel, pressing
it firmly in place.
Main Wheels
C4
* Clean monthly.
Clean the main wheels with a soft, dry cloth.
Dustbin and Water Tank
C5
Combo Unit
* Clean weekly and replace the filter every 6-12 months
C5-1—Press the latch to remove the unit.
Remove the washable filter then
empty the dustbin.
C5-2—Empty the water tank of unused water.
C5-3—Fill the dustbin with clean water and
gently shake it. Then pour out the
dirty water.
Note: To prevent blockage, only use clean water without any
cleaning liquid.
C5-4—Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
Note: Do not touch the surface of the filter with your hands,
brush, or hard objects to avoid potential damage.
C5-5—Allow 24 hours for the filter to dry
thoroughly and reinstall it.
Note: Purchase an additional filter and alternate if
necessary.
Mop Cloth
C6
* Clean after each use and replace every 3-6 months
Remove the mop cloth from mop cloth
mount. Clean the mop cloth and air-dry it.
Note: A dirty mop will affect the mopping performance. Clean
it before use.
Robot Sensors
C7
* Clean monthly.
Use a soft, dry cloth to wipe and clean all
sensors, including:
C7-1—Dock Locator
C7-2—Reactive Tech Obstacle Avoidance
Sensor
C7-3—Wall Sensor
C7-4—Cliff Sensors
Dust Bag Replacement
C8
* Replace as required.
C8-1— Remove the dustbin cover vertically
as shown.
C8-2— Lift the dust bag out of the dustbin
and discard it.
Note: The dust bag handle seals the bag on removal to
prevent dust leakage.
C8-3— Clean the filter with a dry cloth.
C8-4— Install a new dust bag in place
along the slot and put the dustbin
cover back.
10
Air Duct
C9
* Clean as required.
C9-1—Unscrew the screws (10) and
remove the cover.
C9-2—
Wipe the air duct and cover with a
dry cloth.
C9-3— Reinstall the cover and screw it
back in place.
Charging Contact Areas
C10
* Clean as required.
Use a soft dry cloth to wipe the charging
contacts on the robot. Clean the dock
location beacon, charging contacts, and
electrode brushes on the dock.
Battery
The robot is equipped with a built-in
high-performance lithium-ion rechargeable
battery pack. To maintain battery
performance, keep the robot charged
during normal use.
Note: If the robot will be left unused for a long period, turn it
off and charge it at least every three months to avoid battery
damage caused by over-discharge.
