Crestron TPMC-4XG-BTP

Setup

Removal

NOTE: To prevent damage to multi-pin connector and wiring, use care
when handling the TPMC-4XG-BTP.
Perform the following procedure to remove the existing
TPMC-4XG-BTP from a TPMC-4XG or TPMC-4XG-B touchpanel:
1. Place the touchpanel screen side down on a clean, soft surface.
2. Remove the battery compartment cover on the rear of the
3. Using the flat end of a small slot head screwdriver, gently pry the
4. With the multi-pin connector detached from the touchpanel, lift the

Installation

After completing removal of the old TPS-4XG-BTP from the touchpanel
(refer to "Removal" above), perform the following procedure to install
the TPMC-4XG-BTP in a TPMC-4XG or TPMC-4XG-B touchpanel:
1. Place the TPMC-4XG-BTP in the battery compartment oriented so
2. Carefully connect the multi-pin connector of the TPMC-4XG-BTP
NOTE: When installing the battery in the touchpanel, ensure the
connecting wires are not under the battery. Refer to the photo on the
following page for proper wire routing.
3. Re-attach the battery compartment cover.
Installation Guide – DOC. 6657B
Battery for TPMC-4XG & TPMC-4XG-B
touchpanel.
multi-pin connector off the corresponding connector in the battery
compartment of the touchpanel.
TPMC-4XG-BTP out of the battery compartment.
the multi-pin connector is on the top.
with the corresponding connector inside the battery compartment.
The pin side of the connector should be facing downward (toward
the front of the touchpanel).
Internal Battery Pack: TPMC-4XG-BTP • 3
