Summary of Contents for Crestron ST-BTPN
- Page 1 Crestron ST-BTPN Rechargeable Battery Pack Operations and Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...
-
Page 3: Table Of Contents
Crestron ST-BTPN Contents Rechargeable Battery Pack: ST-BTPN Introduction...1 Functions and Features ...1 Specifications...2 Physical Description ...3 Industry Compliance...4 Handling ...5 Storage ...5 Charging...6 Installation...6 Removal ...8 Further Inquiries ...9 Future Updates...9 Return and Warranty Policies ...10 Merchandise Returns / Repair Service ...10 CRESTRON Limited Warranty ...10... -
Page 5: Rechargeable Battery Pack: St-Btpn
The ST-BTPN offers the touchpanel user the freedom to roam without being confined to a stationary power source (i.e., external battery pack or docking station). The ST-BTPN can be charged when it is mounted on the ST-DSN docking station. The ST-BTPN can also be charged when mounted on the older ST-DS docking station. -
Page 6: Specifications
The latest versions of the guides which includes their respective international versions are available from the Downloads | Product Manuals section of the Crestron website (www.crestron.com). Specifications The following table provides specifications for the ST-BTPN. Specifications for the ST-BTPN SPECIFICATION Output Voltage... -
Page 7: Physical Description
The docking station begins charging the battery once the battery has cooled. Physical Description The ST-BTPN (refer to illustrations below and on the next page) is housed in a black plastic enclosure with its electrical contacts on the top and bottom of the unit. -
Page 8: Industry Compliance
2.280 in (5.791 cm) 1.159 in (2.944 cm) Industry Compliance As of the date of manufacture, the ST-BTPN has been tested and found to comply with specifications for CE and C-Tick markings. • Rechargeable Battery Pack: ST-BTPN BOTTOM VIEW C R E S T R O N Crestron Electronics, Inc. -
Page 9: Handling
Avoid accidental shorting from uninsulated workbenches, tools, bracelets, rings, and coins. Storage The ST-BTPN can be stored in a temperate dry place (removed from the touchpanel and docking station) indefinitely without significant irreversible degradation in its performance. The self-discharge rate is a function of temperature and internal resistance. -
Page 10: Charging
These models have the same shape and battery compartment location. Therefore, as an example, the illustration on the next page shows the ST-BTPN properly seated in the ST-1700C. Complete the steps on the next page to install the battery. - Page 11 1. Place touchpanel screen-side down on a clean and soft surface. 2. Place the designated end of the ST-BTPN into the touchpanel battery compartment. Refer to illustration on next page.
-
Page 12: Removal
Complete the following steps to remove the ST-BTPN from a touchpanel. 1. Place touchpanel screen-side down on a clean and soft surface. 2. Lift latch up so that one edge of ST-BTPN pops out of touchpanel battery compartment. 3. Rotate battery pack out and remove. -
Page 13: Further Inquiries
Crestron's award winning customer service team by calling: • In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400. • In Europe, call Crestron International at +32-15-50-99-50. -
Page 14: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 15 Crestron ST-BTPN Rechargeable Battery Pack This page intentionally left blank. Rechargeable Battery Pack: ST-BTPN • 11 Operations and Installation Guide - DOC. 6088...
- Page 16 Crestron Electronics, Inc. Operations and Installation Guide – DOC. 6088 15 Volvo Drive Rockleigh, NJ 07647 06.02 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
