Crestron TPMC-10-BTP Replacement Manual

Replacement Battery: TPMC-10-BTP

Description

To replace the TPMC-10 battery, slide the battery compartment latch up to the unlocked
position, and slide the battery out. Slide the replacement battery into the TPMC-10 until it
snaps into position, and slide the latch into the locked position. (Refer to the illustration
below.)
CAUTION: Replace only with a TPMC-10 battery. To obtain an additional replacement
battery, please contact a Crestron customer service representative.
CAUTION: Failure to fully charge the battery for five hours before turning on the
TPMC-10 for the first time may reduce the overall service life of the battery.
NOTE: The TPMC-10's battery "trickle" charges when the external power supply is used to
power the touchpanel.
NOTE: If you are not using the TPMC-10 on a daily basis, store the unit by connecting the
power supply. For extended storage, remove the battery completely.
NOTE: The battery recharge capacity is 500 cycles to 80% of original capacity.
Further Inquiries
If you cannot locate specific information or have questions after reviewing this guide, please
take advantage of Crestron's award winning customer service team by calling the Crestron
corporate headquarters at 1-888-CRESTRON [1-888-273-7876]. For assistance in your local
time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron
worldwide offices.
You can also log onto the online help section of the Crestron website to ask questions about
Crestron products. First-time users will need to establish a user account to fully benefit from
all available features.
