evertz 3067VIP-3G-36x4 User Manual

Next generation quad outputs, compact multi-image display processors
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Next Generation Quad Outputs, Compact Multi-Image
© Copyright 2020
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone:
+1 905-335-3700
Sales:
sales@evertz.com
Tech Support: service@evertz.com
Web Page:
http://www.evertz.com
Version 1.0, February 2020
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of
purchasers of the 3067VIP-3G series product. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the
operation of the 3067VIP-3G series product. Due to on going research and development, features and specifications in this manual are subject to
change without notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.
3067VIP-3G-36x4
Display Processors
User Manual
Fax: +1 905-335-3573
Fax: +1 905-335-7571

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3067VIP-3G-36x4 and is the answer not in the manual?

Questions and answers

Related Manuals for evertz 3067VIP-3G-36x4

Summary of Contents for evertz 3067VIP-3G-36x4

  • Page 1 Version 1.0, February 2020 The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of purchasers of the 3067VIP-3G series product. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of the 3067VIP-3G series product.
  • Page 2 This page left intentionally blank...
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “Dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (Servicing) instructions in the literature accompanying the product.
  • Page 4 WARNING Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables...

  • Page 5: Table Of Contents

    3067VIP-3G-36x4 User Manual TABLE OF CONTENTS OVERVIEW ........................... 1 TECHNICAL SPECIFICATIONS ....................3 2.1. SERIAL VIDEO INPUTS ....................... 3 2.2. DISPLAY VIDEO OUTPUT ....................3 2.3. SERIAL VIDEO OUTPUT ..................... 3 2.4. RISE AND FALL TIME......................3 2.5. GENLOCK INPUT ......................... 3 2.6.
  • Page 6 3067VIP-3G-36x4 User Manual 4.6. UMD CONTROL ......................... 21 4.6.1. UMD Proxy Control ....................22 4.7. SYSTEM NOTIFY ....................... 22 4.7.1. Global Control ......................22 4.7.2. Temperature Notify ....................23 4.8. VIDEO NOTIFY ........................23 4.8.1. Global Control ......................24 4.8.2. Video Notify......................24 4.9.
  • Page 7 5.1. FIRMWARE UPGRADE USING WEBEASY ..............53 ® Figures Figure 1-1: 3067VIP-3G-36x4 Block Diagram ................2 Figure 3-1: 3067VIP-3G-36x4 Rear Panel ..................5 Figure 3-2: COM Port – Serial Port Settings .................. 6 Figure 3-3: Serial Port – Network Setup Menu ................7 Figure 4-1: WebEASY - Login Menu ....................
  • Page 8 Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.

  • Page 9: Overview

    The 3067VIP–3G–36x4 provides the best quality input reproduction; it leverages the same video processing technology as Evertz conversion products. The 3067VIP–3G–36x4 is a hot–swappable device, which can reside in any Evertz EMX series frame available in 1RU, 3RU and 6RU, with optional redundant power supplies. This allows high density I/O count per RU.

  • Page 10: Figure 1-1: 3067Vip-3G-36X4 Block Diagram

    3067VIP-3G-36x4 User Manual Figure 1-1: 3067VIP-3G-36x4 Block Diagram Page - 2 Revision 1.0...

  • Page 11: Technical Specifications

    3067VIP-3G-36x4 User Manual TECHNICAL SPECIFICATIONS 2.1. SERIAL VIDEO INPUTS Standards: 3Gb/s (SMPTE 424M/424M-AB) HD-SDI (SMPTE ST 292-1), and/or SD-SDI (SMPTE ST 259-C) Number of Inputs: Connector: Mini Din 1.0/2.3 connector Equalization: SD-SDI: Automatic to 200m @ 270 Mb/s with Belden 1694A (equiv.) HD-SDI: Automatic to 100m @ 1.5 Gb/s with Belden 1694A (equiv.)

  • Page 12: Electrical

    3067VIP-3G-36x4 User Manual ELectrical Voltage: +12VDC Power: 130W EMI/RFI: Complies with FCC Part 15, Class A EU EMC Directive Physical (number of slots): 2.7. MONITORING OPTIONS • Standard AVM monitoring audio: low/high/loss Video: black/frozen/loss • Dolby audio monitoring, Loudness monitoring,...

  • Page 13: Getting Started

    3067VIP-3G-36x4 User Manual GETTING STARTED 3.1. REAR PLATE DESCRIPTION Figure 3-1: 3067VIP-3G-36x4 Rear Panel Page - 5 Revision 1.0...

  • Page 14: Hardware Installation

    The 3067VIP-3G-36x4 module requires a first time initialization to set up proper network parameters. Procedure 1. Connect the Evertz serial upgrade cable (ribbon cable) to the 2x3 header at the front edge of the 3067VIP-3G-36x4 card. 2. Start a terminal program and configure the port settings.

  • Page 15: Figure 3-3: Serial Port - Network Setup Menu

    3067VIP-3G-36x4 User Manual 3. Boot up module, a login prompt will appear, enter: • “customer” for user name <Enter> • “customer” for password <Enter> 4. Once logged in, we will be configuring the network settings. • Select <1> for the Network Setup menu.
  • Page 16 3067VIP-3G-36x4 User Manual This page left intentionally blank Page - 8 Revision 1.0...

  • Page 17: Web Interface

    After the card has been installed and configured with the required network addresses for the control ports, it can be completely configured using the web interface. To do this, simply type in the IP address of the Control Port on the 3067VIP-3G-36x4 module in the web browser. ...

  • Page 18: System Tab

    3067VIP-3G-36x4 User Manual 4.1. SYSTEM TAB Figure 4-2: WebEASY - System Tab - Part 1 ® 4.1.1. Control Port Control *must reboot in order for new settings to take effect IP Address: This control allows the user to set the IP address on the Control Port. This control will also display the currently set IP address.

  • Page 19: Reference Monitoring

    3067VIP-3G-36x4 User Manual 4.1.2. Reference Monitoring Reference Status: This monitor displays whether the module is locked or unlocked to reference Reference Present: This monitor displays whether a genlock signal is present. Reference Standard: This monitor displays the standard detected for the gunlock reference.

  • Page 20: Product Features

    3067VIP-3G-36x4 User Manual 4.1.5. Product Features This monitor will display the different features enabled on module. These features can be purchased either separately or with the initial purchase of the 3067VIP card. Figure 4-3: WebEASY - System Tab - Part 2 ®...

  • Page 21: Global Time Control

    3067VIP-3G-36x4 User Manual 4.1.8. Global Time Control Global Timer IP Address: This field allows the user to add the IP address of the global timer masterclock. System Reboot: This button control is used to reboot the system. When making changes to system configurations, a reboot will be necessary 4.2.

  • Page 22: Input Properties Control

    3067VIP-3G-36x4 User Manual NTP Server IP Address: This control is used to configure the IP address of the NTP server, use the control to select main or backup, and set the IP for the corresponding device. Current Time Zone: This monitor displays the current time zone; the user can select the appropriate time zone from the list.

  • Page 23: Global Control

    3067VIP-3G-36x4 User Manual 4.3.1. Global Control Default Settings set alarm settings to factory default for all inputs. Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration 4.3.2. Input Settings Control...

  • Page 24: Input Audio Properties

    3067VIP-3G-36x4 User Manual HD Caption Decode: This parameter will set HD caption decode with CC1, CC2, CC3, CC4 and services 1 through 16. WST Decode: This parameter allows the user to enable or disable WST decode. Blur Video: This parameter allows user to enable or disable caption.

  • Page 25: Input Monitor

    3067VIP-3G-36x4 User Manual 4.4. INPUT MONITOR Figure 4-7: WebEASY - Input Monitor - Part 1 ® 4.4.1. Input Monitor For 36 input streams Source Name: This parameter displays the input name. Video Refresh Rate (Hz): This monitor is used to display the detected refresh rate on the input stream.

  • Page 26: Input Video Monitor

    3067VIP-3G-36x4 User Manual 4.4.2. Input Video Monitor For 36 input streams Video Standard: This parameter will return the current video standard for an input. Aspect Ratio Decode: This parameter will return the current decoded aspect ratio string from one of the selected aspect control modes.

  • Page 27: Output Control

    3067VIP-3G-36x4 User Manual 4.5. OUTPUT CONTROL Figure 4-9: WebEASY - Output Control ® Page - 19 Revision 1.0...

  • Page 28: Output Control

    3067VIP-3G-36x4 User Manual 4.5.1. Output Control For Outputs 1-4 Output Resolution: This control allows the user to select the output resolution. Options are: • 720p, • 1080p • 1080i • 480p (720x480) • 576p (720x576) • XGA (1024x768) • WXGA (1280x768) •...

  • Page 29: Output Control

    3067VIP-3G-36x4 User Manual Layout: Selects different basic screen layouts for the output display in a standalone mode. (This is currently used for debugging purposes.) Options are: • Full Screen • • • • Advanced Output Rotation: Allow user to set display in landscape or portrait mode. Options are: •...

  • Page 30: Umd Proxy Control

    3067VIP-3G-36x4 User Manual 4.6.1. UMD Proxy Control For Readers 1 and 2 Protocol: This control is used to select the UMD protocol to use. Options are: • Image Video • TSL 3.1 • TSL 4.0 • TSL 5.0 • Harris Image Video Port (0 to 10000): This control is used to configure the port for the UMD protocol.

  • Page 31: Temperature Notify

    3067VIP-3G-36x4 User Manual Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration 4.7.2. Temperature Notify Temperature Send Trap: This control is used to turn temperature traps on and off. When set to true, the system will notify when an error is present.

  • Page 32: Global Control

    3067VIP-3G-36x4 User Manual 4.8.1. Global Control Default Settings set alarm settings to factory default for all inputs. Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration Video configuration thresholds on the 32 input streams are used for setting traps and fault monitoring in the Video Notify section below.

  • Page 33: Audio Notify

    3067VIP-3G-36x4 User Manual 4.9. AUDIO NOTIFY Figure 4-13: WebEASY - Audio Notify - Part 1 ® 4.9.1. Global Control Default Settings: This control will reset all audio notify settings to default. Copy Input 1 Settings to Others: This control will copy all audio notify settings on input 1 to the remaining inputs.

  • Page 34: Audio Monitoring Control (1)

    3067VIP-3G-36x4 User Manual 4.9.2. Audio Monitoring Control (1) For 36 input streams and 16 channels of audio per input stream Audio Over Level (-30 to 0 dBFS): The control sets the dBFS threshold for the audio over fault. Audio Over Duration (1 to 3600 seconds): This control sets the duration time audio must stay above the dBFS threshold before a fault is triggered.

  • Page 35: Audio Monitoring Control (2)

    3067VIP-3G-36x4 User Manual 4.9.3. Audio Monitoring Control (2) For the 36 input streams and 8 groups of audio per input stream Mono Detection Level (20 to 50): This control is used to adjust the mono phase detection on the audio pair.

  • Page 36: Figure 4-6: Webeasy

    3067VIP-3G-36x4 User Manual Figure 4-15 : WebEASY - Audio Notify - Part 3 ® Page - 28 Revision 1.0...

  • Page 37: Audio Notify

    3067VIP-3G-36x4 User Manual 4.9.4. Audio Notify Audio Notify allows for SNMP traps to be sent for audio faults previously configured in the sections above on the 36 input streams. Audio Traps: When enabled, a fault condition will send out a trap message to the trap addresses configured in the Trap Control section of the System tab.

  • Page 38: Advanced Notify Control

    3067VIP-3G-36x4 User Manual 4.10. ADVANCED NOTIFY CONTROL Figure 4-16: WebEASY - Advanced Notify Control - Part 1 ® 4.10.1. Global Control Default Settings set alarm settings to factory default for all inputs. Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration 4.10.2.
  • Page 39 3067VIP-3G-36x4 User Manual Active Picture Level Max Duration (0 to 900 frames): This control sets the number of frames for which maximum luma level is exceeded before reporting a fault alert. Active Picture Level Max Reset Duration (0 to 60 seconds): This control allows the user to set the amount of seconds the trigger will remain active after the luma has not exceeded the threshold.

  • Page 40: Cc Control

    3067VIP-3G-36x4 User Manual Figure 4-17: WebEASY - Advanced Notify Control - Part 2 ® 4.10.3. CC Control For the 36 input streams on CC 1 to CC 4 CC Loss Duration (0 to 3600 seconds): This parameter sets the number of seconds to pass with CC data missing before a fault is triggered.

  • Page 41: Nielsen Control

    3067VIP-3G-36x4 User Manual Figure 4-18: WebEASY - Advanced Notify Control - Part 3 ® 4.10.5. Nielsen Control For the 36 input streams NAES Source Loss Reset Duration: This control is used to set the amount of time after the return of the NAES Source Loss for the fault to clear.
  • Page 42 3067VIP-3G-36x4 User Manual AMOL Data Loss Duration: This control is used to set the amount of time for the loss of the AMOL Data before triggering a fault condition. AMOL Data Loss Reset Duration: This control is used to set the amount of time after the return of the AMOL Data for the fault to clear.

  • Page 43: Eia 708 Control

    3067VIP-3G-36x4 User Manual Figure 4-19: WebEASY - Advanced Notify Control - Part 4 ® 4.10.6. EIA 708 Control For the 36 input streams and EIA 708 Service 1 to EIA 708 Service 16 EIA 708 Error Duration (0 to 3600 seconds): This control sets the duration of missing EIA-708 captions which is considered a fault.

  • Page 44: Anc Control

    3067VIP-3G-36x4 User Manual Figure 4-20: WebEASY - Advanced Notify Control - Part 5 ® 4.10.7. ANC Control For the 36 input streams Teletext Duration (0 to 3600 seconds): This parameter sets the number of seconds to pass with teletext data missing before a fault is triggered.
  • Page 45 3067VIP-3G-36x4 User Manual SMPTE AFD Loss Reset Duration (0 to 60 seconds): This parameter sets the number of seconds to pass with the SMPTE AFD signal corrected before a fault is cleared. SMPTE AFD Change Reset Duration (0 to 60 seconds): This parameter sets the number of seconds to pass with SMPTE AFD Change before a fault is cleared.

  • Page 46: Video Control

    3067VIP-3G-36x4 User Manual Figure 4-21: WebEASY - Advanced Notify Control - Part 6 ® 4.10.8. Video Control For the 36 input streams Video Standard Change Duration (0 to 900) frames: This control is used to set the number of consecutive frames that must elapse before video standard fault condition is triggered.

  • Page 47: Gpi Control

    3067VIP-3G-36x4 User Manual Macro Block Detect Error Reset Duration (0 to 120) seconds: This control is used to set the amount of time after the Macro Block is not detecting errors for the fault to clear. Macro Block Detect Thresh (0 to 14): This control is used to set the threshold (sensitivity) for the Macro Block detection.

  • Page 48: Advanced Notify

    3067VIP-3G-36x4 User Manual 4.11. ADVANCED NOTIFY Page - 40 Revision 1.0...

  • Page 49: Global Control

    3067VIP-3G-36x4 User Manual Figure 4-22: WebEASY - Advanced Notify ® 4.11.1. Global Control Default Settings set alarm settings to factory default for all inputs. Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration 4.11.2.

  • Page 50: Global Control

    3067VIP-3G-36x4 User Manual 4.12.1. Global Control Default Settings set alarm settings to factory default for all inputs. Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration 4.12.2. Advanced Audio Notify Control...

  • Page 51: Audio Loudness Monitoring Control

    3067VIP-3G-36x4 User Manual Advanced Audio Traps: When enabled, a fault condition will send out a trap message to the trap addresses configured in the Trap Control section of the System tab. Advanced Audio Faults: This monitor will display green when there is no fault on the audio and red for a fault indication.

  • Page 52: Audio Loudness Monitoring

    3067VIP-3G-36x4 User Manual Group 1 and 2 Audio Type: This parameter selects the audio program loudness types for group 1 and 2 audio. Group 3 and 4 Audio Type: This control selects the audio program loudness types for group 3 and 4 audio.

  • Page 53: Figure 4-14: Webeasy

    3067VIP-3G-36x4 User Manual Figure 4-26: WebEASY - Advanced Audio Notify - Part 4 ® Page - 45 Revision 1.0...

  • Page 54: Audio Loudness Notify

    3067VIP-3G-36x4 User Manual 4.12.5. Audio Loudness Notify Audio Loudness Notify allows for fault monitoring and traps be sent for audio faults, configured in the sections above, on the 36 input streams. Audio Loudness Traps: When enabled, a fault condition will send out a trap message to the trap addresses configured in the Trap Control section of the System tab.

  • Page 55: Thumbnail Control

    3067VIP-3G-36x4 User Manual 4.13.2. Thumbnail Control Thumbnail Server User Name: This parameter displays the thumbnail server username if required for authentication. Thumbnail Server Password: This parameter displays the thumbnail server password if required for authentication. Thumbnail Interval: This parameter displays the number of seconds to pass between thumbnailed image data intervals.

  • Page 56: Advanced Input Notify

    3067VIP-3G-36x4 User Manual 4.14. ADVANCED INPUT NOTIFY Figure 4-28 : WebEASY - Advanced Input Notify - Part 1 ® Page - 48 Revision 1.0...

  • Page 57: Advanced Input Notify (1)

    3067VIP-3G-36x4 User Manual 4.14.1. Advanced Input Notify (1) Default Settings set alarm settings to factory default for all inputs. Copy Input 1 Settings to Others copies input 1 settings to all other inputs on card for faster configuration. 4.14.2. Advanced Input Notify (2) Advanced Audio Notify allows for fault monitoring and traps to be sent on audio faults, configured in the sections above, on the 36 input streams.

  • Page 58: Figure 4-16: Webeasy

    3067VIP-3G-36x4 User Manual Figure 4-29 : WebEASY - Advanced Input Notify - Part 2 ® Page - 50 Revision 1.0...

  • Page 59: Timecode Gpi Control

    3067VIP-3G-36x4 User Manual 4.14.3. Timecode GPI Control For the 36 input streams and Timecode GPI 1 to Timecode GPI 6 Timecode GPI Duration Reset: This control allows the user to set the amount of time the trigger will remain active.
  • Page 60 3067VIP-3G-36x4 User Manual This page left intentionally blank Page - 52 Revision 1.0...

  • Page 61: Firmware Upgrade

    When first visiting the 3067VIP-3G-36x4 web interface, the user will be asked to enter a login and password. Enter customer in both fields. On the top of the web page for the 3067VIP-3G-36x4, there is a tab labeled Upgrade. The Upgrade tab is used to check current firmware version and upload the latest firmware.

  • Page 62: Figure 5-2: Webeasy - Firmware Upgrade Menu

    3067VIP-3G-36x4 User Manual Figure 5-2: WebEASY - Firmware Upgrade Menu ® Click Browse to locate image file. Once selected, click Open (Step 1) to advance to the next step. Click Upgrade (Step 2). The progress bar will display the status of the upgrade. Once completed, the device will automatically restart.

Table of Contents
