evertz 7700 Manual

Sd-sdi 4 aes audio embedder
Hide thumbs Also See for 7700:

Advertisement

Quick Links

1.
OVERVIEW.......................................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 3
3.
SPECIFICATIONS............................................................................................................................... 5
3.1. SERIAL VIDEO INPUT ............................................................................................................... 5
3.2. SERIAL VIDEO OUTPUTS WITH EMBEDDED AUDIO ............................................................. 5
3.3. AES AUDIO INPUTS .................................................................................................................. 5
3.4. SYSTEM PERFORMANCE ........................................................................................................ 5
3.5. ELECTRICAL ............................................................................................................................. 5
3.6. PHYSICAL .................................................................................................................................. 6
4.
STATUS LEDS .................................................................................................................................... 7
4.1. MODULE STATUS LEDS ........................................................................................................... 7
4.2. AUDIO GROUP AND MODE STATUS LEDS............................................................................. 7
5.
CARD EDGE CONTROLS .................................................................................................................. 9
5.1. SELECTING THE AUDIO GROUPS THAT WILL BE EMBEDDED............................................ 9
5.2. SELECTING THE AUDIO DELAY ............................................................................................ 11
AND WHERE THE EMBEDDED AUDIO WILL BE PLACED ................................................... 11
5.4. SELECTING AES LOCKED GROUP MODE............................................................................ 12
5.5. SELECTING SAMPLE RATE CONVERSION FOR AES INPUTS............................................ 12
5.6. SELECTING FUNCTION OF THE MODULE OK STATUS LED............................................... 13
5.7. SELECTING OPERATION WHEN THERE IS NO VIDEO INPUT............................................. 13
6.
JUMPERS.......................................................................................................................................... 14
BY THE GLOBAL FRAME STATUS ........................................................................................ 14
6.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES .............................................. 14

TABLE OF CONTENTS

Revision 1.2
7700 MultiFrame Manual
7720AE4 SD-SDI 4 AES Audio Embedder

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700 and is the answer not in the manual?

Questions and answers

Summary of Contents for evertz 7700

  • Page 1: Table Of Contents

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 3 SPECIFICATIONS..........................5 3.1. SERIAL VIDEO INPUT ....................... 5 3.2. SERIAL VIDEO OUTPUTS WITH EMBEDDED AUDIO ............. 5 3.3. AES AUDIO INPUTS ........................5 3.4. SYSTEM PERFORMANCE ......................5 3.5.
  • Page 2 7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder Figures Figure 1-1: 7720AE4 Block Diagram........................2 Figure 2-1: 7720AE4 Rear Panels ........................3 Figure 6-1: Location of Jumpers ......................... 14 Tables Table 4-1: Audio Group and Mode Status LEDs....................8 Table 5-1: Toggle Switch Function Overview .......................
  • Page 3 May 09 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
  • Page 4 7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder This page left intentionally blank Revision 1.2...
  • Page 5: Overview

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder OVERVIEW The 7720AE4 Audio Embedder inserts AES audio signals into a 270 Mb/s SDI video signal as specified in SMPTE 272M. The companion 7720AD4 Audio Deembedder facilitates audio demultiplexing at the destination.
  • Page 6: Figure 1-1: 7720Ae4 Block Diagram

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder By Pass Relay Audio Present Serial Output Serial Input 270 Mb/s 270 Mb/s with SMPTE 272 (SMPTE 259M) embedded Audio Cable Equalizer Embedder S / P P / S Driver AES Inputs...
  • Page 7: Installation

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder INSTALLATION The 7720AE4 modules each come with a companion rear plate that has 7 BNC connectors. information on mounting the rear plate and inserting the module into the frame see section 3 of the 7700FR chapter.
  • Page 8 7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder AES INPUT 2: AES audio input for channel 3 and 4 of the audio group selected for embedding by embedder 1. AES INPUT 3: AES audio input for channel 1 and 2 of the audio group selected for embedding by embedder 2.
  • Page 9: Specifications

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder SPECIFICATIONS 3.1. SERIAL VIDEO INPUT Standard: SMPTE 259M C (270 Mb/s) 525 or 625 line component Connector: 1 BNC per IEC 61169-8 Annex A Equalization: Automatic 210m @ 270 Mb/s with Belden 8281 or equivalent cable Return Loss: >...
  • Page 10: Physical

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder 3.6. PHYSICAL 350FR: 7700FR-C: 7800FR: Stand Alone Enclosure: Dimensions: 14 “ L x 4.5 “ W x 1.9 “ H (355 mm L x 114 mm W x 48 mm H) Weight: approx.
  • Page 11: Status Leds

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder STATUS LEDS The location of the status LEDs is shown in Figure 6-1. 4.1. MODULE STATUS LEDS MODULE OK: This Green LED will be On when the module is operating properly. Depending on the Status LED mode chosen, the LED will be on solid when input video, or audio or both video and audio is present (see section 5.6)
  • Page 12: Table 4-1: Audio Group And Mode Status Leds

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder DIP Switch Control Value Description Description Audio Present AES1 Present AES2 Present AES3 Present AES4 Present Audio Delay Minimum ½ frame 1 frame 1 ½ frames 2 frames 2 ½ frames 3 frames 3 ½...
  • Page 13: Card Edge Controls

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder CARD EDGE CONTROLS The 7720AE4 is equipped with an 8 position DIP switch to allow the user to select various functions. All positions are assigned sequentially such that the first position is located at the left side of the DIP switch (farthest from to the card ejector).
  • Page 14: Table 5-2: Embedder 1 Enable Switch Settings

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder When set to Disable embedder 1 will be disabled. When it is set to Enable the embedder destination can be set when the DIP switches are set as shown in Table 5-3. Channels 1 and 2 from AES input 1 will be embedded into channels 1 and 2 of the selected group.
  • Page 15: Selecting The Audio Delay

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder 5.2. SELECTING THE AUDIO DELAY When the DIP switches are as shown in Table 5-6, the toggle switch is used to select one of fifteen delays which can be added to the audio before it is embedded. This delay allows the user to resynchronize the audio back to the video to accommodate video processing delays.
  • Page 16: Selecting Aes Locked Group Mode

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder 5.4. SELECTING AES LOCKED GROUP MODE For audio that is synchronous to video there is exactly 8008 audio samples (48kHz sampling rate) in 5 frames of NTSC, 525 line video. Most audio embedders will spread these samples as evenly as possible throughout the 5 frames of video.
  • Page 17: Selecting Function Of The Module Ok Status Led

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder 5.6. SELECTING FUNCTION OF THE MODULE OK STATUS LED When the DIP switches are as shown in Table 5-10, the toggle switch is used to select the function of the Module OK LED status indicator. (See section 4.1)
  • Page 18: Jumpers

    7700 MultiFrame Manual 7720AE4 SD-SDI 4 AES Audio Embedder JUMPERS EVERTZ (C) 7700PB3 MODULE STATUS A7700AES4-2 SIGNAL PRESENT ERROR AUDIO Upgrade FRAME STATUS SFF POWER +12V Figure 6-1: Location of Jumpers 6.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME STATUS...
  • Page 19: Resetting The Module To Its Factory Default Condition

    Special Serial Upgrade cable supplied with the 7700FR-C frame. This cable is normally in the vinyl pouch at the front of this manual. (Evertz part #WA-76). A “Straight-thru” serial extension cable (DB9 female to DB9 male) may be required if you need to extend the length of the WA-S76 serial upgrade...
  • Page 20 Improper port settings in the terminal program. (Refer to step 5 for settings). 9. Press the <CTRL> and <X> keys. This will bring you to the boot prompt "7700 Boot> 10. Type the word “reset”, without quotes, and hit the <ENTER> key once. The boot code will ask Are you sure? Type "y", without quotes.

This manual is also suitable for:

7720ae4
