7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter
TABLE OF CONTENTS
Revision 1.1
7700 Multi-Frame Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter TABLE OF CONTENTS OVERVIEW ..........................1 1.1. SETTING UP THE DDC VALUE ....................3 INSTALLATION ........................4 2.1. OPTICAL CONNECTIONS......................6 2.2. SIGNAL CONNECTIONS ......................6 2.3. INTERFACING WITH 3G OPTICAL ROUTER................7 2.4. - Page 2 7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.2. Selecting the Output Laser Enable Mode..............15 4.2.3. Selecting Link Rate ....................... 15 4.2.4. Setting Input RGB Gain (7708RGBT models only) ............16 4.2.5. Setting the RGB Output Video Sharpness (7708RGBT models only)......16 4.2.6.
- Page 3 7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter Tables Table 1-1: Sample Typical Fiber Application Configurations ................2 Table 4-1: LEDs Functionality ..........................12 Table 6-1: VistaLINK Monitored Parameters.....................22 ® Table 6-2: VistaLINK Controlled Parameters ....................23 ®...
- Page 4 Oct 09 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
- Page 5 7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter WARNING Never look directly into an optical fiber. Irreversible eye damage can occur in a matter of milliseconds. Revision 1.1...
- Page 6 7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter This page left intentionally blank Revision 1.1...
-
Page 7: Overview
Monitoring and control of the card status and parameters are provided locally at the card-edge, or remotely via VistaLINK capability. ® The 7708RGBT uses Evertz SFP modules to interface to and from the fiber optic domain. transmitters and transceivers are available in 1310nm, 1550nm, and CWDM wavelengths. Features: •... -
Page 8: Figure 1-1: 7708Rgbt Block Diagram
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter Transmit Side Receive Side Fiber Optical/Link Description Type Budget Ordering Product Info Ordering Product Info Power Sensitivity Multi-Mode < 500m 7708RGBT13-A2 -1dBm 7708RGBR-A2 -20dBm 1310nm on Tx and Rx fibers... -
Page 9: Setting Up The Ddc Value
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 1.1. SETTING UP THE DDC VALUE DDC (Display Data Channel) is a series of protocols that enables plug and play communication between a graphics adapter and a computer monitor. It allows the display to communicate its supported display modes and display parameters to the graphics adapter. -
Page 10: Installation
DB9 serial connector, and a type-B USB connector. In addition, there is a dual channel LC/PC SFP slot to house an Evertz SFP transmitter or an Evertz SFP transceiver. The DVI-I connector supports combined analog and digital video through a single interface. An industry-standard DB-15 connector adapter may be used for RGB. -
Page 11: Figure 2-1: 7708Rgbt & 7708 Dvit Rear Plates
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter Figure 2-1: 7708RGBT & 7708 DVIT Rear Plates Page - 5 Revision 1.1... -
Page 12: Optical Connections
DB-15 to DVI-I adapter such as the Belkin F2E4162, or appropriately terminated cable assembly such as the Amp 16539332-1. When making digital DVI connections, Evertz recommends using only high quality DVI cables, no longer than 6 feet (1.8m). AUDIO INPUTS (A2 & A2KM Versions):... -
Page 13: Interfacing With 3G Optical Router
2.4.1. Safety CLASS 1 LASER PRODUCT Background colour: yellow Triangular band: black Symbol: black 2.4.2. Assembly Assembly or repair of the laser sub-module is performed only at the Evertz facility by qualified Evertz technical personnel. Page - 7 Revision 1.1... -
Page 14: Labeling
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore care must be taken to prevent fiber damage caused by heavy objects or abrupt fiber bending. Evertz recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. -
Page 15: Specifications
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter SPECIFICATIONS Video and audio performance specifications are measured at the output of a companion 7708RGBR/DVIR Receiver. 3.1. ANALOG VIDEO INPUTS Number of Signals: Signal Type: Sync Type:... -
Page 16: Keyboard/Mouse Input/Output (A2Km Versions)
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 3.5. KEYBOARD/MOUSE INPUT/OUTPUT (A2KM VERSIONS) Number: Connector: 1 PS2 each for keyboard and mouse 3.6. SERIAL PORT (A2KM VERSIONS) Standard: RS232 or RS422 (user selectable) Number:... -
Page 17: Physical
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 3.11. PHYSICAL 7700, 7800, or 7701 Frame Mounting: Number of Slots Model 7708RGBT/DVIT 7708RGBT/DVIT-A2 7708RGBT/DVIT-A2KM 7708RGBT/DVIT-A2KM-USB Page - 11 Revision 1.1... -
Page 18: Card-Edge Monitoring And Control
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter CARD-EDGE MONITORING AND CONTROL The 7708RGBT/DVIT has ten LED status indicators and a four-digit dot-matrix display on the front card- edge to show the card’s operational status at a glance. The card-edge pushbutton and toggle switch are used to select various control and status indicators on the dot-matrix display. -
Page 19: Status Indicator Leds
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.1. STATUS INDICATOR LEDS LOCAL FAULT: This red LED indicates poor module health. Several conditions could cause this fault indication to be active: o Laser fault... -
Page 20: Figure 4-2: 7708Rgbt/Dvit Card Edge Menu Flow Cart
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter Pushbutton Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Indications LASR...ERR (Laser Error) Supersedes LINK...LOSS (No optical Link) Supersedes VID...LOSS (No Video Input) -
Page 21: Card-Edge Display Warning Indications
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.1. Card-Edge Display Warning Indications There are flashing warning indicators that may appear on the display of the 7708RGBT/DVIT. These warning indicators can overwrite other displayed text. Pressing the pushbutton will clear a warning indicator from the display and will allow access to other menu items. -
Page 22: Setting Input Rgb Gain (7708Rgbt Models Only)
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.4. Setting Input RGB Gain (7708RGBT models only) When RGB video is applied, the Input ADC Gain level can be adjusted to affect the brightness of the RGB video seen out of the 7708RGBR. -
Page 23: Setting The Analog Audio Detection Duration (A2 & A2Km Versions Only)
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.7. Setting the Analog Audio Detection Duration (A2 & A2KM Versions Only) The DUR control sets the amount of time (in seconds) the audio is below the level set by the DET control before the audio is considered missing. -
Page 24: Selecting Iden
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.10. Selecting IDEN The IDEN card edge menu item works in conjunction with the module ID card edge menu item for the purpose of audio soft switching on the 7708RGBR/DVIR modules. For audio soft switching, select ON under the IDEN card edge menu item. -
Page 25: Setting The Orientation Of The Text On The Card Edge Display
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.13. Setting the Orientation of the Text on the Card Edge Display The DISP option allows the user to set a horizontal or vertical orientation for the card edge display. -
Page 26: Displaying The Selected Display Data Channel Mode
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 4.2.17. Displaying the Selected Display Data Channel Mode The 7708RGBT can display the Selected Display Data Channel Mode. To indicate the Selected Display Data Channel Mode, select the STAT menu item in menu level 1. Use the toggle switch to select the DDC menu item and press the pushbutton. -
Page 27: Jumper Controls
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter JUMPER CONTROLS Several jumpers (located at the front of the module) are used to preset various operating modes. Figure 4-1 shows the locations of the jumpers. -
Page 28: Vistalink ® Remote Monitoring/Control
1. An SNMP manager, also known as a Network Management System (NMS), is a computer running special software that communicates with the devices in the network. Evertz VL-Fiber demo Manager graphical user interface (GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled fiber optic products. -
Page 29: Table 6-2: Vistalink ® Controlled Parameters
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 6.3. LINK CONTROLLED PARAMETERS ISTA ® The following parameters can be remotely controlled through the VistaLINK interface. ® Parameter Name Notes Description 7708RGBT only when RGB... -
Page 30: Vista Link ® Traps
7700 Multi-Frame Manual 7708RGBT/DVIT DVI and RGB Video + Audio SFP Based Fiber Transmitter 6.4. LINK TRAPS ISTA ® The following traps can be VistaLINK enabled and monitored. ® Trap Description Triggers when valid DVI input is lost DVI Input...
