TABLE OF CONTENTS
Revision 1.1
7700 MultiFrame Manual
7780DLY-ASI ASI Delay
INTERFACE - 7780DLY-ASI ........... 8
®
Advertisement
Table of Contents
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7780DLY-ASI ASI Delay TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 3 2.1. ASI CONNECTIONS........................3 2.2. SDI OUTPUT OVER OSD ......................3 2.3. GENERAL PURPOSE INPUTS....................4 SPECIFICATIONS..........................5 3.1. ASI INPUT/OUTPUT........................5 3.1.1. Asynchronous Serial Interface ..................5 3.1.2. - Page 2 7700 MultiFrame Manual 7780DLY-ASI ASI Delay VISTALINK REMOTE MONITORING/CONTROL ................15 ® 8.1. WHAT IS VISTALINK ? ......................15 ® 8.2. VISTALINK MONITORED PARAMETERS ................16 ® 8.3. VISTALINK CONTROLLED PARAMETERS ................. 17 ® 8.4. VISTALINK TRAPS ........................ 17 ®...
- Page 3 Nov 08 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
- Page 4 7700 MultiFrame Manual 7780DLY-ASI ASI Delay This page left intentionally blank Revision 1.1...
-
Page 5: Overview
List of active PIDs • Controlled by VistaLINK PRO or Card Edge ® • Fully integrated with the industry leading Evertz VistaLINK PRO NMS system ® • OSD (On-Screen Display) on SDI output for status and configuration display • 7 programmable preset delays controllable by GPI and VistaLINK ®... -
Page 6: Figure 1-1: 7780Dly-Asi Asi Delay Block Diagram
7700 MultiFrame Manual 7780DLY-ASI ASI Delay DVB ASI Output (Bypass Protected) DVB ASI Input Variabl Cable Equalizer Driver Delay Buffer Cable DVB ASI Output Driver Cable SDI OSD RS232 control Driver VistaLINK CPU Control Interface Card GPI input 1 to 8... -
Page 7: Installation
7700 MultiFrame Manual 7780DLY-ASI ASI Delay INSTALLATION The 7780DLY-ASI module comes with a companion rear plate that has 4 BNC connectors and a 25 pin D connector and occupies two slots in the frame. For information on mounting the rear plate and inserting the module into the frame see section 3 of the 7700FR chapter. -
Page 8: General Purpose Inputs
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 2.3. GENERAL PURPOSE INPUTS A 25 pin D connector labeled GPI contains 8 GPI inputs. The connector pinout is shown in Table 2-1. Pin # Name Description Not used Not used GPI 0 Bypass Relay Enable... -
Page 9: Specifications
7700 MultiFrame Manual 7780DLY-ASI ASI Delay SPECIFICATIONS 3.1. ASI INPUT/OUTPUT 3.1.1. Asynchronous Serial Interface Standard: DVB TR101 891, 270Mb/s Number of Inputs: Number of Outputs: 1 (with relay bypass) Bitrate: 100kb/s to 213Mb/s 3.1.2. Standard Definition Serial Digital Video (OSD) -
Page 10: Status Leds
7700 MultiFrame Manual 7780DLY-ASI ASI Delay STATUS LEDS The 7780DLY-ASI has 2 LED Status indicators on the main circuit board and 1 indicator on the sub- module to show operational status of the card at a glance. Figure 7-1 and Figure 7-2 shows the location of the LEDs and card edge controls. -
Page 11: Card Edge Controls - 7780Dly-Asi
7700 MultiFrame Manual 7780DLY-ASI ASI Delay CARD EDGE CONTROLS - 7780DLY-ASI The 7780DLY-ASI module is equipped with a 4 position DIP switch on the top edge of the card to allow the user to select various functions. All positions are assigned sequentially such that the DIP switch 1 is located farthest from the front of the card. -
Page 12: Selecting Whether The Module Will Be Controlled From The Local Controls Or Through The Vistalink
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 5.2. SELECTING WHETHER THE MODULE WILL BE CONTROLLED FROM THE LOCAL CONTROLS OR THROUGH THE VISTALINK INTERFACE – 7780DLY-ASI ® DIP switch 2, 3, 4 selects whether the module will be controlled from the local user controls or through the VistaLINK interface. -
Page 13: Using The On Screen Menu
7700 MultiFrame Manual 7780DLY-ASI ASI Delay USING THE ON SCREEN MENU An On Screen Display (OSD) is used to configure many of the module’s parameters. The three position, return to center, toggle switch and momentary pushbutton located on the front edge of the module are used to navigate the OSD setup menus and configure the cards various controls. -
Page 14: Top Level Menu Structure
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 6.1. TOP LEVEL MENU STRUCTURE When the module is running, the OSD will show the status of the input. The status window displays the following: SIGNAL ASI input presence status. TOTAL TS BITRATE A measurement of the total Bitrate of the input stream. -
Page 15: 6.1.1. Setting The Asi Delay
7700 MultiFrame Manual 7780DLY-ASI ASI Delay The following is a brief description of the top level of the menu tree that appears when you enter the on screen menu. Selecting one of these items will take you down into the next menu level. -
Page 16: Utility Menu
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 6.3. UTILITY MENU BYPASS RELAY Activates bypass from input to the first output BNC. The module will not OFF/ON detect an input in this condition. RECALL PRESET Recalls one of the 7 delay presets. -
Page 17: Jumpers And User Controls
7700 MultiFrame Manual 7780DLY-ASI ASI Delay JUMPERS AND USER CONTROLS MODULE STATUS EVERTZ (A) 7700SP3 FRAME STATUS SFF POWER +12V Figure 7-1: Location of Jumpers on Main Boards EVERTZ (B) 7700CC LD2 SIGNAL PRESENT Upgrade Figure 7-2: Location of Jumpers on 7700CC Sub-Module 7.1. -
Page 18: Configuring The Module For Firmware Upgrades
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 7.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES UPGRADE: The UPGRADE jumper J15 located near the front of the sub-module is used when firmware upgrades are being done to the module. For normal operation it should be installed in the RUN position. -
Page 19: Vistalink Remote Monitoring/Control
WHAT IS VISTALINK ® VistaLINK is Evertz’s remote monitoring and configuration platform which operates over an Ethernet ® network using Simple Network Management Protocol (SNMP). SNMP is a standard computer network protocol that enables different devices sharing the same network to communicate with each other. -
Page 20: Vistalink Monitored Parameters
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 8.2. VISTALINK MONITORED PARAMETERS ® The following parameters can be remotely monitored through the VistaLINK interface. ® Parameter Description ASI Delay The current ASI delay. Bypass relay status The current relay status. Local remote mode The status of the VistaLINK DIP switch. -
Page 21: Vistalink Controlled Parameters
7700 MultiFrame Manual 7780DLY-ASI ASI Delay 8.3. VISTALINK CONTROLLED PARAMETERS ® Parameter Description ASI Delay Set ASI delay. Set bypass relay mode. Bypass relay Preset recall Recall a preset. Preset store Store current configuration into preset. Force packet length. Packet length OSD video standard Set video standard for the OSD. - Page 22 7700 MultiFrame Manual 7780DLY-ASI ASI Delay This page left intentionally blank 7780DLY-ASI - 18 Revision 1.1...
