7707MB Multi-Signal SDTV Fiber Transciever
Revision 1.5
7700 MultiFrame Manual
Advertisement
Table of Contents
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 4 2.1. AES AUDIO AND AUXILLIARY I/O.................... 5 2.1.1. Connecting the AES Inputs ..................... 5 2.1.2. Connecting the RS232/422 Serial Data Port..............6 2.2. CONNECTING THE GPI INPUTS AND GPO OUTPUTS............6 2.3. - Page 2 7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 4.2.6. Displaying the State of the General Purpose Outputs........... 16 4.2.7. Displaying the State of the General Purpose Inputs ............. 16 4.2.8. Displaying the Firmware Version................... 17 CARD EDGE MENU SYSTEM ......................18 5.1.
- Page 3 7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever Figures Figure 1-1: 7707MB Block Diagram ........................2 Figure 2-1: 7707MB & 7707MB-F2 Rear Panels ....................4 Figure 2-2: Breakout Panel for Wiring Connections....................7 Figure 2-3: Reproduction of Laser Certification and Identification Label ..............9 Figure 7-1: Location of Jumpers –...
- Page 4 7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever This page left intentionally blank Revision 1.5...
- Page 5 Nov 08 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
- Page 6 7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever WARNING Never look directly into an optical fiber. Non-reversible damage to the eye can occur in a matter of milliseconds. Do not hook up the 7707MB DWDM cards directly with a short fiber optic cable.
-
Page 7: Overview
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever OVERVIEW The 7707MB Multi-Signal Fiber Transceiver is a VistaLINK enabled fiber transmitter/receiver for SDI ® Video, AES Audio, RS422 control and GPIO. This single card module transports and receives one bi- directional SDI Video plus two bi-directional AES Audio plus one bi-directional RS422 plus two bi- directional GPI’s and GPO’s. -
Page 8: Figure 1-1: 7707Mb Block Diagram
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever ® CONTROL/ LOCAL LOCAL INDICATION INDICATION CONTROL SDI VIDEO RECLOCKER INPUT OPTICAL AES AUDIO FIBER AES 1 TRANSMITTER OUTPUT INPUTS AES 2 TX/RX RS422/232 OPTICAL FIBER INPUT INTERFACE SPLITTER/ INPUT/ GPI 1... -
Page 9: Table 1-1: Typical Application Configurations
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever The following chart shows some typical applications and power budget calculations: Transmit Side Receive Side Fiber Fiber Optical/Link Description Ordering Ordering Type Links Budget Product Info Power Product Info Sensitivity 1310nm on Tx & Rx Multi-Mode <... -
Page 10: Installation
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever INSTALLATION The 7707MB comes with a companion rear plate that has two BNC connectors, one female DB15 and one SC/PC, SC/PC with cover (shown), ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the module into the frame see the 7700FR chapter section 3. -
Page 11: Aes Audio And Auxilliary I/O
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 2.1. AES AUDIO AND AUXILLIARY I/O A 15-pin High Density D connector labeled AES / SERIAL I/O contains 2 AES Audio inputs, 2 AES Audio outputs and a bi-directional Serial Data port. -
Page 12: Connecting The Rs232/422 Serial Data Port
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 4 Pins on the DB15 connector are used to carry balanced or unbalanced AES audio AES OUTPUT: outputs for channels 6&2 (AES 1) and 1&7 (AES 2) of an audio group. Each output occupies two pins (+, -) on the DB15 with a shared GND pin. -
Page 13: Installing The Bulkhead Breakout Panel
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 2.3. INSTALLING THE BULKHEAD BREAKOUT PANEL The 7707MB-BHP Bulkhead breakout panel is an optional accessory that provides the user with a convenient way of connecting the audio and RS232/422 signals into the HD DB-15 connectors on the rear of the modules. -
Page 14: Connecting The Breakout Panel Aes Inputs
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 2.3.1. Connecting the Breakout Panel AES Inputs For Balanced AES signals connect the + and – signals to the respective BALANCED AES INPUTS: input pins on the AES terminal strips. The AES Term Jumpers J26 and J27 must be set to the 110 positions for proper termination of the balanced AES inputs. -
Page 15: Care And Handling Of Optical Fiber
Triangular band: black Symbol: black 2.4.2. Assembly Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified Evertz technical personnel. 2.4.3. Labeling Certification and Identification labels are combined into one label. As there is inadequate space on the product to place the label, it is reproduced here in the manuals. -
Page 16: Handling And Connecting Fibers
5 cm to avoid fiber-bending loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the frame that does not have a suitable I/O module. -
Page 17: Specifications
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever SPECIFICATIONS 3.1. SERIAL VIDEO INPUT SMPTE 259M-C, 525 or 625 line component, SMPTE 305M. Standards: 1 BNC per IEC 61169-8 Annex A Connector: Equalization: Automatic to 250m @ 270Mb/s with Belden 8281 or equivalent cable >... -
Page 18: Optical Input/Output
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 5V p-p Balanced: Up to 24 bits Resolution: 32, 44.1, 48kHz Sampling Rate: < 20ns Intrinsic Jitter: Unbalanced - 75Ω Impedance: Balanced - 110Ω 3.5. OPTICAL INPUT/OUTPUT 1 (single fiber version) Number:... -
Page 19: System Performance
3.10. ELECTRICAL +12VDC Voltage: 12W (Non-DWDM) Power: 14W (DWDM) 3.11. PHYSICAL 7700 or 7701 frame mounting: 1 (7707MB) Number of slots: 2 (7707MB-F2) 3.12. COMPLIANCE CSA Listed to UL 60065-03, IEC 60065 Electrical Safety: Complies with CE Low voltage Directive... -
Page 20: Status Indicators And Displays
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever STATUS INDICATORS AND DISPLAYS The 7707MB has 6 LED Status indicators and a 4 digit alphanumeric display on the front card edge to show operational status of the card at a glance. The card edge pushbutton is used to select various displays on the alphanumeric display. -
Page 21: Displaying The Video Standard
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever Parameters monitored by MIB Input Video standard in use. AES1 clock rate received. AES2 clock rate received. Output Video standard in use. AES1 clock rate in use. AES2 clock rate in use. -
Page 22: Displaying The Serial Data Activity
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 4.2.3. Displaying the Serial Data Activity The 7707MB detects activity on the RS232/422 serial data channel on the input signal and displays this on the four-digit card edge display. The following list describes possible displays and their meaning. -
Page 23: Displaying The Firmware Version
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 4.2.8. Displaying the Firmware Version The S/W display shows the firmware version and build number of the 7707MB firmware. The message will scroll across the display. For example: VER 1.0 BLD 067 7707MB Revision 1.5... -
Page 24: Card Edge Menu System
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever CARD EDGE MENU SYSTEM 5.1. NAVIGATING THE MENU SYSTEM While in control mode, the toggle switch and pushbutton are used to navigate through a menu system to set various parameters for the module. To enter the menu system, press the pushbutton one or more times to exit the current display mode and return to the mode select menu item. -
Page 25: Setting Edh Detection
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 5.2.1. Setting EDH Detection The 7707MB will monitor both incoming EDH and outgoing EDH errors and report them to the four-digit card edge display. Incoming EDH errors are displayed in the IVS window. Outgoing EDH errors are displayed in the OVS window: Reports Incoming EDH errors to the four-digit card edge display. -
Page 26: Card Edge Controls
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever CARD EDGE CONTROLS The 7707MB is equipped with a three position, return to center toggle switch that is used to select the various card edge displays and is also used in conjunction with a momentary pushbutton to select some sub-items of the displays. -
Page 27: Jumpers
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever JUMPERS GPO1 GPO2 Figure 7-1: Location of Jumpers – I/O Module TOGGLE SWITCH LOCAL FAULT MODULE OK AES 1 PRESENT AES 2 PRESENT DATA ACTIVITY DATA ACTIVITY DISPLAY PUSH BUTTON SELECT AES1... -
Page 28: Selecting Whether Local Faults Will Be Monitored By The Global Frame Status
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 7.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME STATUS The FRAME STATUS jumper J4 determines whether local faults (as shown by the Local Fault indicator) will be connected to the 7700FR frame's global status bus. -
Page 29: Configuring Rs422 Device Communication Between A Controller And Tributary
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 7.3.1. Configuring RS422 Device Communication between a Controller and Tributary SMPTE Standard 207M defines the electrical and mechanical characteristics of the device interface used in transferring data and control signals between production and post-production equipment. -
Page 30: Configuring The Module For Firmware Upgrades
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 7.5. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES The UPGRADE jumper J5 is used when firmware upgrades are being done to the module. UPGRADE: For normal operation it should be installed in the RUN position. -
Page 31: Setting The Aes Output Level
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 7.9. SETTING THE AES OUTPUT LEVEL The AES LEVEL jumpers J28 and J29 control the peak to peak voltage level of the outputs. AES LEVEL: When the AES TERM jumpers are set to the 110 position the AES LEVEL jumpers must be set to the HI position to give a 5 volt balanced signal level. -
Page 32: Selecting Normally Open Or Closed Gpos
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 7.11. SELECTING NORMALLY OPEN OR CLOSED GPOS The GPO1 and GPO2 jumpers J13 and J14, located on the I/O assembly select whether the General Purpose output relay contacts will be open or closed when they are active. The GPO1 and GPO2 displays indicate the state of the GPOs. -
Page 33: Vistalink ® Remote Monitoring/Control
1. An SNMP manager, also known as a Network Management System (NMS), is a computer running special software that communicates with the devices in the network. Evertz VL-Fiber demo Manager graphical user interface (GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled fiber optic products. -
Page 34: Table 8-1: Vistalink Monitored Parameters
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 8.2. LINK MONITORED PARAMETERS ISTA ® The following parameters can be remotely monitored through the VistaLINK interface: ® Parameter Description Indicates presence of a valid optical link with a companion 7707MB Link OK module. -
Page 35: Vista Link ® Controlled Parameters
7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever 8.3. LINK CONTROLLED PARAMETERS ISTA ® Parameter Description Force AES Sampling Rate Manually set the audio sampling rate Module Output Video Signal On Loss of Video, set blue or black screen output... - Page 36 7700 MultiFrame Manual 7707MB Multi-Signal SDTV Fiber Transciever This page left intentionally blank 7707MB Revision 1.5...
