- Page 1 2023 Farley Alloy 5, 7 and 9 SERVICE MANUAL...
- Page 2 Notice: Measurements of actual tires may vary. Always verify there is sufficient clearance between the tire and the frame. Improper tire size could damage the bicycle frame. Trek recommends 6mm clearance above and on both sides of the tire. Water bottle fit Small frame: one water bottle, down tube only.
- Page 3 2023 Farley 5, 7 and 9 Front and rear dropouts 25 Nm Switch lever — W573860 Front dropout (Farley 5 and 9) Thru axle, 12 x 223 — W5279557 Dérailleur hanger Washer — W5271425 Bolt (left-hand thread) Carbon fork — 5311796 Front thru axle, 15 x 198.5 mm —...
- Page 4 2023 Farley 5, 7 and 9 Routing 2 Nm External cable guide — W5287833 Dropper post housing Socket head screws, steel, M5 x 16 — W5252789 Rear brake hose Zip ties Rear derailleur housing...
-
Page 5: Frame Guards
2023 Farley 5, 7 and 9 Frame guards 1.5 Nm 2 Nm Farley 5 and 9 only. Align holes in the guard with the holes in the frame. Chainstay guard Match the original part number found on the inside Fork dropout bumper, driveside of the guard, with the correct replacement part (shown below). - Page 6 2023 Farley 5, 7 and 9 Frame mounts — Farley 5 and Farley 9 Mounts for: 4 or 6 . Mounts for: 3 , 4 , or 5 . page 10 for bag and mudguard informa- tion. 5 Nm 3 kg (max load per side 5 Nm...
- Page 7 2023 Farley 5, 7 and 9 Frame mounts — Farley 7 Mounts for 1 , 2 , or 3 . page 10 for bag and mudguard information. Mounts for: 1 , 2 , or 3 . Mounts for: 2 or 3 . Thumb screws —...
- Page 8 2023 Farley 5, 7 and 9 Rear rack — parts 3 Nm 5.2 Nm 5.2 Nm 1.5 Nm M5x10 M5x16 M5x25 Rear rack — 44355 Search trekbikes.com to find the colour-matched part for your bike. Strut nuts — 423544 Struts, one set. Matte black. Includes strut caps —...
- Page 9 2023 Farley 5, 7 and 9 Rear rack — installation Large or extra-large frames only: If adding or replacing a Loosely attach the rack to the seat stay bridge. rack, use a hacksaw to cut two lengths from each strut to create clearance for the tyre.
-
Page 10: Front Rack
2023 Farley 5, 7 and 9 Front rack 6 Nm Farley front rack — 44354 Search trekbikes.com to find the colour-matched part for your bike. Bolts, stainless steel, M6 x 16 mm, with washers — W582658... - Page 11 2023 Farley 5, 7 and 9 Frame bag, rack bag and mudguard Frame bag S — 5288902 M — 5288903 L — 5288904 XL — 5288905 Thumb screw — 5281893 Universal mudguard kit — W5289946 Socket head screws, steel, M5 x 16 mm — W5252789 Rear rack bag —...
-
Page 12: Specifications
Notice: Measurements of actual tyres may vary. Always verify that there is sufficient clearance between the tyre and the frame. Improper tyre size could damage the bicycle frame. Trek recommends 6mm clearance above and on both sides of the tyre. Front Hub: 150 mm... - Page 13 2023 Farley 5, 7 and 9 Fork WARNING Exceeding the recommended maximum fork length could damage the bicycle and result in injury to the rider. Farley 5 and 9 Farley 7 Refer to the suspension set-up card included with your bike or the suspension calculator at Trekbikes.com/suspension-calculator.
