Summary of Contents for Trek Farley Carbon 9.6 2023

  • Page 1 2023 Farley Carbon 9.6 SERVICE MANUAL...
  • Page 2 Notice: Measurements of actual tires may vary. Always verify there is sufficient clearance between the tire and the frame. Improper tire size could damage the bicycle frame. Trek recommends 6mm clearance above and on both sides of the tire. Maximum insertion S...
  • Page 3 2023 Carbon Farley 9.6 Front and rear dropouts Sliding rear dropout For information about adjusting the sliding drop out, watch the video How To: Adjust Horizontal Sliding Dropouts on Trek’s YouTube channel. 10Nm 23Nm 23Nm Front dropout Switch lever —...
  • Page 4 2023 Carbon Farley 9.6 Routing — 1x 0.7Nm No housing         0.7Nm Fasteners, M3 x 12mm — W318529 Dropper post housing Note: Apply anti-sieze or waterproof grease. Rear brake hose Frame plug — W329840 Rear derailleur housing Cable entry guide —...
  • Page 5 2023 Carbon Farley 9.6 Routing — Optional 2x 0.7Nm 0.7Nm No housing       0.7Nm   Front derailleur housing Cable exit guides — W439610 Dropper post housing Guide tubes — W333080 Fasteners, M3 x 12mm — W318529 Rear brake hose Note: Apply anti-sieze or waterproof grease.
  • Page 6: Frame Guards

    2023 Carbon Farley 9.6 Frame guards Low, direct-mount front derailleur plate cover — W516639 Down tube adhesive guard — W519509 Use isopropyl alcohol to clean the frame surface where the guard attaches. Wait for the alcohol to dry before applying the guard.
  • Page 7 2023 Carbon Farley 9.6 Fork and frame mounts Mounts for: 3 and 4 . Carbon fork — 5311796 Screws, stainless steel, M5 x 16mm — W5252789 Water bottle bolts, stainless steel, M5 x 8mm — W598484 Water bottle nutsert plugs — W308963 Mounts for M6 x 16mm bolts.
  • Page 8 2023 Carbon Farley 9.6 Front rack (available separately) Farley front rack — 44354 Search trekbikes.com to find the color-matched part for your bike. Bolts, M6 x 16mm, with washers — W582658...
  • Page 9: Specifications

    Notice: Measurements of actual tires may vary. Always verify there is sufficient clearance between the tire and the frame. Improper tire size could damage the bicycle frame. Trek recommends 6mm clearance above and on both sides of the tire. Maximum insertion S...
