P5TX–AR User's Manual
4: Reference Information – 4.40
Onboard FDD Controller
Enables or Disables the onboard Floppy Drive controller.
Onboard Serial Port 1/2
Sets the I/O address for serial ports 1 & 2.
3F8/IRQ4
Onboard serial port COM1 default
2F8/IRQ3
Onboard serial port COM2 default
3E8/IRQ4
2E8/IRQ3
Disabled
UART 2 Mode
Sets mode for the second serial port UART. If you select an IR
module type, the second serial port will not be available. The
setting options are:
Standard (default) – (used by COM2 serial port)
ASKIR
HPSIR
The infrared mode you select here should be the same as the
infrared module you are connected to the mainboard. You can
also manually configure the Duplex, RxD and TxD settings if the
defaults are not correct for the installed module. See the screen
illustration on the next page.
