P5TX–AR User's Manual
4: Reference Information – 4.6
Onboard Connectors
Name Function
J1 Keyboard & Mouse
J2 ATX Power
J3 USB Port 1 & Port 2
J4 Serial Port Two
COM2
J5 Serial Port One
J6 Parallel Port
J7 External VGA
J8 Floppy Drive Controller 34-pin connector connects to 2-device cable;
J9 Second IDE Channel
J10 First IDE Channel
J11 Audio jacks
J12 Video Feature
J13 SODIMM
J14 CD-In
J15 TV Out
J16 Hard Disk LED
LED
J17 FIR header (optional)
J18 Intel IR header
Description
Stacked PS/2 ports, keyboard lower, mouse upper
Connects to 20-pin ATX power supply lead
Stacked Universal Serial Bus ports
Connector for external 9-pin serial port port bracket is
can be set to COM4
Onboard 9-pin serial port is COM1, can be set to COM3
Standard 25-pin parallel Printer port
External VGA port connector
End device is Drive A:, middle is Drive B:
40-pin connector connects to 2-device cable;
End device is Secondary Master, middle is Slave
40-pin connector connects to 2-device cable;
End device is Primary Master, middle is Slave
Jacks for Line-In, Line-Out & microphone
VGA feature connector & ATi AMC connector
Socket for display memory upgrade
CD-ROM dive audio cable connector
Connector for an optional external TV port module
Connector for case-mounted hard disk activity indicator
Connects to optional Fast IR infrared module cable
Connects to optional IrDA or ASKIR infrared module cable
