Summary of Contents for PCE Instruments PCE-EM 890
- Page 1 User Manual PCE-EM 890 Environmental Tester User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 12 January 2021 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Safety notes ................... 1 Specifications ..................2 Delivery scope ..................3 System description ................4 Measurement functions ................ 5 Operation ....................5 Preparation ........................5 Functions ......................... 5 Measurement ........................7 Contact ....................10 Disposal ....................10 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
-5.4 ... 49 °C 0.1 °C temperature Heat stress index 0 ... 100 °C 0.1 °C ±2 °C Wind chill -9.4 ... 44.2 °C 0.1 °C ±2 °C Altitude above sea level -2000 ... 9000 m ±15 m © PCE Instruments... -
Page 5: Delivery Scope
0 ... 50 °C / max. 80 % RH Dimensions 120 x 45 x 20 mm Weight approx. 160 g Delivery scope 1 x environmental tester PCE-EM 890 1 x CR2032 battery 1 x protective bag 1 x user manual © PCE Instruments... -
Page 6: System Description
③ ⑨ Hold key (freeze display) Pt1000 connection for external sensor ④ ⑩ UV light sensor Brief description of key function ⑤ ⑪ Temperature / humidity sensor Pressure sensor barometer ⑥ ⑫ Power key (On) Battery compartment © PCE Instruments... -
Page 7: Measurement Functions
• Press and hold the "Hold" key when the meter is switched on. • The display shows the measuring functions one after the other. • Release the key as soon as the desired measuring function is displayed. © PCE Instruments... - Page 8 To exit the Rec function and delete the saved values, press and hold the "REC" key for more than 2 seconds. 6.2.7 Automatic power off The tester powers off after approx. 10 minutes of inactivity to save battery power. Automatic power off is not active in "REC" mode. © PCE Instruments...
-
Page 9: Measurement
Switch on the meter and select the dew point measurement function as described above. • Select the desired unit of measurement as described above. • Do not cover or enclose the openings of the temperature / humidity sensor. This will lead to incorrect measurement results. © PCE Instruments... - Page 10 When the hold indicator is displayed, press and hold the "REC" key until "m" or "F" appears at the bottom of the display. • With the "Hold" and "Power" keys, you can increase or decrease the site altitude above sea level. • Press the "REC" key to confirm the entry. © PCE Instruments...
- Page 11 Power on the meter and select the measuring function external temperature via Pt1000, as described above. • Select the desired unit of measurement as described above. The Pt1000 connection is designed as a 2-pin 3.5 mm jack socket. © PCE Instruments...
-
Page 12: Contact
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 13 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
