- Page 1 Tursdale Technical Services Ltd Unit N12B Tursdale Business Park Co. Durham DH6 5PG United Kingdom Phone: +44 ( 0 ) 191 377 3398 Fax: +44 ( 0 ) 191 377 3357 info@tursdaletechnicalservices.co.uk http://www.industrial-needs.com/ Manual PCE-880 pyrometer...
- Page 2 info@tursdaletechnicalservices.co.uk SAFETY ........................... 2 GENERAL SPECIFICATIONS ..................2 FRONT PANEL DESCIPTION ..................3 INDICATOR ........................3 MEASURMENT OPERATION..................3 BATTERY REPLACEMENT .................... 5 Notes: ..........................5 Features: Precise non-contact measurements Built-in laser pointer ºC / ºF switchable button Automatic Data Hold & Auto power off The meter at 8 inches away measure 1 inch target Backlit LCD display Wide range application:...
- Page 3 info@tursdaletechnicalservices.co.uk OPERATING TEMP. 0ºC to 50ºC (32ºF to 122ºF) OPERATING RH% Max. 80% RH POWER SUPPLY 9V battery WEIGHT 180g. SIZE 159 x 79 x 57.2mm 1ºC / ºF Resolution Ranges -20ºC to 270ºC / -4ºF to 518ºF Accuracy ±2% of reading or ±2ºC / ±4ºF Note Accuracy is given at 18 oC to 28 oC (64 oF to 82 oF), less than 80 % RH Accuracy specified is for emissivity of 0.95...
- Page 4 info@tursdaletechnicalservices.co.uk B. SELECTING UNITS(℃/℉) Select temperature units (degrees or ) by first pressing the ON/HOLD key and then pressing the key. The units will be seen on the LCD. (Fig. B) Presses the key again to switch the unit (scale) again. See Fig. C. Fig.B Fig.C C.
- Page 5 info@tursdaletechnicalservices.co.uk Holding the meter by its handle, point the IR Sensor toward the object whose temperature is to be measured. The meter automatically compensates for temperature deviations from ambient temperature. Keep in mind that it will take up to 30 minutes to adjust to wide ambient temperatures are to be measured followed by high temperature measurements, some time (several minutes) is required after the low (and before the high) temperature measurements are made.
- Page 6 info@tursdaletechnicalservices.co.uk In this direction will find a vision of the measurement technique: http://www.industrial-needs.com/measuring-instruments.htm NOTE: "This instrument doesn’t have ATEX protection, so it should not be used in potentially explosive atmospheres (powder, flammable gases)."...
