Chapter 2. Hardware Setup

2.1 Installation Procedure

1. Jumper settings (BIOS and CPU)
2.
Installation of CPU
3.
Installation of Memory
4.
I/O Connections & Panel Connections

2.1.1 Jumper Settings

In this manual , (1-2) represents the first and second pins of the jumper. (2-3) represents the
second and third pins of the jumper. On the motherboard, you will see two sets of jumpers
with different color jumper caps:
Yellow Jumper Caps : Sets the Function of Flash CMOS
Green Jumper Caps : Sets the type and speed of CPU
TM
PM133 VT8605 & VT82C686A chipset.
TM
PL133 VT8604 & VT82C686A chipset and doesn't support AGP slot.
TM
PM133 VT8605 & VT82C686B chipset.
TM
PL133 VT8604 & VT82C686B chipset and doesn't support AGP slot.
JRTC
JF0, JF1, JF2, JF3
