When set to On, any event occurring to the DMA controller will awaken a system which has been
powered down.
3.6.18 Wake up on LAN/Modem
(1) This allows you to remotely power up your system through your network by sending a wake-up
frame or signal. With this feature, you can remotely upload/download data to/from systems during off-
peak hours. Set to Enabled to set this feature. Please refer to session 2.4.6 for more information.
(2) An incoming call on the external Modem power on the system. The function of power on through
modem when system is off. When set to "Enabled" : To let the system to enter the environment of DOS
or Windows 95/98 OS before system is power off. As long as there are any message through the Modem
to enter the System during system is power off. The system will enable power on function.
3.6.19 RTC Alarm Resume
Set this option to enable or disable the RTC Alarm to Wake Up the system which is set at soft Off.
3.6.20 Date (of Month), Resume Time (hh:mm:ss)
Set these options to specify the RTC Alarm time on Date / Hour / Minute /Second.
3.6.21 Primary INTR
When set to On (default), any interrupt request is set to Enabled (see below) will awaken the system
which has been powered down.
Following this option is a list of IRQs (Interrupt ReQuests). You can set each IRQ to be Enabled or
Disabled.
3.6.22 IRQs Activity Monitoring
IRQ3
IRQ4
IRQ5
IRQ6
IRQ7
IRQ8
IRQ9
IRQ10 (Reserved)
IRQ11 (Reserved)
IRQ12 (PS/2 Mouse)
IRQ13 (Coprocessor)
IRQ14 (Hard Disk)
IRQ15 (Reserved)
¯ ® ¬: Move

3.7 PNP/PCI Configuration Setup

PNP OS Installed
Reset Configuration Data
Resources Controlled By
X IRQ Resources
X DMA Resources
PCI/VGA Palette Snoop
Assign IRQ For VGA
Assign IRQ For USB
CMOS Setup Utility - Copyright ( C ) 1984 - 2000 Award Software
IRQs Activity Monitoring
(COM2)
(COM1)
(LPT2)
(Floppy Disk)
(LPT1)
(RTC Alarm)
(IRQ2 Redir)
Enter : Select +/-/PU/PD : Value F10 : Save ESC : Exit F1 : General Help
F5 : Previous Value F6 : Fail-Safe Defaults
Figure 3.7 PNP/PCI CONFIGURATION SETUP
CMOS Setup Utility - Copyright ( C ) 1984 - 2000 Award Software
PnP/PCI Configurations
No
Disabled
Auto (ESCD)
Press Enter
Press Enter
Disabled
Enabled
Enabled
Enabled
Enabled Menu Level >
Enabled
Enabled
Enabled
Disabled
Disabled
Disabled
Disabled
Enabled
Enabled
Enabled
Disabled
F7 : Optimized Defaults
Item
Menu
Item Help
Help
Level >
