Taiwan Commate Computer Inc. 370PMA Series Quick Installation page 13

When you enter the CMOS Setup Utility, the Main Menu will be displayed (Figure 3-1). You can use arrow
keys to select your function, press <Enter> key to accept the selection and enter the sub-menu.
Sub-Menu
Note that a right pointer symbol appears to the left of certain fields. This pointer indicates that a sub-menu
can be launched from this field. A sub-menu contains additional options for a field parameter. To call up a
sub-menu, simple move the highlight to the field and press <Enter>. The sub-menu will then immediately
appear. Use the legend keys to enter values and move from field within a sub-menu just as you would within
a menu. Use the <Esc> key to return to the main menu.
3.2 Standard CMOS Features
With the sub-menu (Figure 3-2), you can setup the; system date, system time, hard and floppy drive type,
and display adapter type. Please refer to your equipment specification when changing the setup. Use arrow
keys to highlight items, and use <PageUp>, <PageDown>, <+>, or <-> keys to scroll through the available
options.
Date ( mm : dd : yy )
Time ( hh : mm: ss )
>IDE Primary Master
>IDE Primary Slave
>IDE Secondary Master
>IDE Secondary Slave
Drive A
Drive B
Floppy 3 Mode Support
Video
Halt On
Base Memory
Extended Memory
Total Memory
¯ ® ¬: Move
3.2.1 Date
To assign the system date, the format is "mm.dd.yy". The input range for the Month is 1-12. Range for
Date is 1-31. Range for Year is 1994-2079. System BIOS will calculate the day of the week automatically.
3.2.2 Time
To assign the system time, the format is "hh:mm:ss". The setting is in military time. When entering 2:34pm enter
"14:34:00".
3.2.3 Hard Disks Setting
Figure 3-1. CMOS Setup Utility Main Screen
CMOS Setup Utility - Copyright ( C ) 1984 - 2000 Award Software
>Standard CMOS Features
>Advanced BIOS Features
>Advanced Chipset Features
>Integrated Peripherals
>Power Management Setup
>PnP / PCI Configurations
>PC Health Status
Esc : Quit
F10 : Save & Exit Setup
Time, Date,
Figure 3-2. Standard CMOS Features Screen
CMOS Setup Utility - Copyright ( C ) 1984 - 2000 Award Software
Enter : Select +/-/PU/PD : Value F10 : Save ESC : Exit F1 : General Help
F5 : Previous Value F6 : Fail-Safe Defaults
>Frequency Control
Load Fail-Safe Defaults
Load Optimized Defaults
Set Supervisor Password
Set User Password
Save & Exit Setup
Exit Without Saving
¯ ® ¬ : Select Item
Hard Disk Type...
Standard CMOS Features
Fri, Jan 1 1999
1 : 28 : 42
Menu Level >
Press Enter 4403 MB
Press Enter None Change the day, month,
Press Enter None Year and century
Press Enter None
1.44M, 3.5 in.
None
Disabled
EGA/VGA
All Errors
640K
14336K
15360K
F7 : Optimized Defaults
Item Help
