Taiwan Commate Computer Inc. 370PMA Series Quick Installation page 17

AGP Aperture Size
AGP-4X Mode
AGP Driving Control
X AGP Driving Value
OnChip USB
USB Keyboard Support
OnChip Sound
OnChip Modem
CPU to PCI Write Buffer
PCI Dynamic Bursting
PCI Master 0 WS Write
PCI Delay Transaction
PCI#2 Access #1 Retry
AGP Master 1 WS Write
AGP Master 1 WS Read
¯ ® ¬: Move
F5 : Previous Value
( Scroll down to see more items , as shown here )
3.4.1 DRAM Timing By SPD
If your DIMM memory have SPD ( Serial Presence Detect ) 8-pin IC on module, you can set this option
to Enabled. System will set your DRAM clock and timing from the SPD IC. If the option set as Disabled,
you must set the DRAM clock and timing from items below.
3.4.2 DRAM Clock
This item allows you to set the DRAM Clock. Options are Host CLK, HCLK+33M or HCLK-33M.
Please set the item according to the Host (CPU) Clock and DRAM Clock
3.4.3 SDRAM Cycle Length
This item allows you to set the SDRAM Latency Timer. Options are 2, 3.
3.4.4 Memory Hole
Enabling this feature reserves 15MB to 16MB memory address space to ISA expansion cards that
specifically require this setting. This makes the memory from 15MB and up unavailable to the system.
Expansion cards can only access memory up to 16MB.
3.4.5 P2C/C2P Concurrency
When Disabled, CPU bus will be occupied during the entire PCI operation period.
3.4.6 Fast R-W Turn Around
DRAM optimization feature: If a memory read is addressed to a location whose latest write is being held
in a buffer before being written to memory, the read is satisfied through the buffer contents, and the
read is not sent to the DRAM.
3.4.7 System BIOS Cacheable
Allows the system BIOS to be cached for faster system performance.
3.4.8 Video BIOS Cacheable
Allows the video BIOS to be cached for faster video performance.
3.4.9 Video RAM Cacheable
Enabled allows caching of the video RAM, resulting in better system performance. However, if any
program writes to this memory area, a system error may result.
3.4.10 Frame Buffer Size
64M
Enabled
Auto
DA
Enabled
Disabled
Auto
Auto
Enabled
Enabled
Enabled
Enabled
Enabled
Disabled
Disabled
Enter : Select +/-/PU/PD : Value F10 : Save ESC : Exit F1 : General Help
F6 : Fail-Safe Defaults F7 : Optimized Defaults
