FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 1
INSTRUCTIONS for INSTALLATION
and USE
Gas Hob
W810
This appliance must be installed in accordance with
regulations in force and only in a well ventilated place.
Ensure that the hob unit is securely fixed to the worktop
before use.
To the Installer
Before installation fill in the product details on the back cover of this
booklet. The information can be found on the rating plate.
To the User
You must read the instructions prior to using the appliance and then
retain them for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Creda W810
Summary of Contents for Creda W810
-
Page 1: Instructions For Installation
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 1 INSTRUCTIONS for INSTALLATION and USE Gas Hob W810 This appliance must be installed in accordance with regulations in force and only in a well ventilated place. Ensure that the hob unit is securely fixed to the worktop before use. -
Page 2: Table Of Contents
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 2 CONTENTS Introduction For Your Safety – Always For Your Safety – Never Using The Hob Care & Cleaning Something Wrong? Installation Key contacts Retention of this Instruction Book This Instruction Book must be kept handy for reference as it contains important details on the safe and proper use of the appliance. -
Page 3: Introduction
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 3 INTRODUCTION Your new hob is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. -
Page 4: Safety Advice
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 4 FOR YOUR SAFETY When used properly, your appliance is completely safe but as with any product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. -
Page 5: For Your Safety - Never
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 5 FOR YOUR SAFETY NEVER Never leave children unsupervised where a cooking appliance is installed as all cooking surfaces will be hot during and after use. Never allow anyone to sit or stand on any part of the appliance. -
Page 6: Using The Hob
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 6 USING THE GAS HOB - FEATURES In order to obtain maximum performance from the burners, use pans with the following diameters: Rapid burner 22 - 28 cm Standard burner 14 - 22 cm Auxillary burner 10 - 14 cm All pans should be positioned centrally over the burners. -
Page 7: Care & Cleaning
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 7 CARE AND CLEANING Clean the hob regularly and wipe up spills soon after they occur to prevent them from becoming burnt on. CLEANING MATERIALS TO AVOID 1. Household abrasive powders, e.g. Vim. -
Page 8: Something Wrong
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 8 SOMETHING WRONG ? IF THE IGNITION DOES NOT WORK Is the electricity switched on? If the electricity supply has failed, the burners can be lit with a match. If only a hotplate burner is failing to ignite, check that the burner body and cap are seated correctly and that the slots in the burner body are not blocked (see care and cleaning). -
Page 9: Installation - Electrical Requirements
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 9 INSTALLATION - electrical requirements WARNING – THIS APPLIANCE MUST BE EARTHED. CONNECT TO A 230-240V A.C. SUPPLY ONLY. Connection to the electricity supply should be made via a properly earthed, readily accessible wall socket which is adjacent to but not directly above, and not more than 1.25m away from the... -
Page 10: Installation Instructions
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 10 INSTALLATION INSTRUCTIONS Gas Category II (GB,IE) 2H3+ Model Numbers W810, BG05 These models are set to burn NATURAL GAS (G20) at 20mbar. They can also be converted to burn BUTANE GAS (G30) at 28mbar or PROPANE GAS (G31) at 37mbar using the conversion kit included. -
Page 11: Provision For Ventilation
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 11 INSTALLATION INSTRUCTIONS Prior to installation, ensure that the local distributions (nature of the gas and gas pressure) and the adjustment conditions are compatible. The adjustment conditions for this appliance are stated on the rating plate which is fitted on the underside of the base panel. -
Page 12: Fitting The Hob
FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 12 INSTALLATION SITING THE HOB The hob is designed to fit into worktop and base unit(s) with a cutout as shown in Fig.1. Any obstruction such as supports or side panels must be removed to allow 30mm minimum depth below the worktop cutout. - Page 13 FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 13 INSTALLATION Fig. 1 Front edge of worktop Fig. 2 FIXING CLAMP Note: Do not over tighten the hob clamps as distortion of the hob may occur. IMPORTANT Minimum unobstructed depth...
- Page 14 FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 14 INSTALLATION INSTRUCTIONS LPG Conversion Instructions for Model W810, BG05 Read the Gas Hob instructions before conversion, installation and using the Gas Hob. Contents of kit: Rapid burner injector marked 92 - 1 off...
- Page 15 FP089-01 Creda Gas Hob (W810) 12/09/2001 5:02 pm Page 15...
-
Page 16: Extended Warranty
Genuine Parts & Accessories Republic of Ireland: (01) 842 6836 For further product information All Creda Services are offered as an extra benefit and do not affect your statutory rights. General Domestic Appliances Limited, Morley Way, Peterborough, PE2 9JB FP089 - 01 Service confidence.
