- Page 1 Instructions for Installation and Use Gas Hob Model S830G Model S840G...
-
Page 2: Table Of Contents
Introduction For Your Safety Know your Hob How to use your Hob Practical Advice Care and Cleaning Troubleshooting Installation Electrical Connection Characteristics of Burners and Nozzels Key Contacts Retention of this Instruction Book This Instruction Book must be kept handy for reference as it contains important details on the safe and proper use of the appliance. -
Page 3: Introduction
Your new hob is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully. The hob is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 4: For Your Safety
When used properly your appliance is completely safe but as with any electrical product there are certain PLEASE READ THE BELOW PRECAUTIONS BEFORE USING YOUR APPLIANCE. To maintain the efficiency and safety of this appliance, we recommend you do the following: - only call the Service Centres authorised by the manufacturer. -
Page 5: Know Your Hob
A. Gas Burners B. Support Grid for Cookware C. Control Knobs for Gas Burners D. Ignitor for Gas Burners (only on certain models) The position of the corresponding gas burner is indicated on each control knob. The burners differ in size and power. Choose the most appropriate one for the diameter of the cookware being used. -
Page 6: Practical Advice
Practical Advise on Using the Burners For best performance, follow these general guidelines: • Use the appropriate cookware for each burner (see table) in order to prevent the flame from reaching the sides of the pot or pan; • Alwasy use cookware with a flat bottom and keep the lid on;... -
Page 7: Care And Cleaning
Before cleaning or performing maintenance on your hob, disconnect it from the power supply. To extend the life of the hob, it should be cleaned carefully and thoroughly on a frequent basis, keeping in mind the following: • The enamelled parts must be washed with warm water without using abrasive powders or corrosive substances which could ruin them. -
Page 8: Installation
The following instructions are intended for the installer so that the installation and maintenance procedures may be followed in the most professional and expert manner possible. Important: Disconnect the appliance from the electrical supply before performing any maintenance or repair. Positioning the Hob Important: this unit may be installed and used only in permanently ventilated rooms in accordance with British... - Page 9 Fastening Clamps - Assembly Diagram Clamp Position for Clamp Position for H=20mm top H=30mm top Clamp Position for H=40mm top N.B: Use the clamps contained in the "accessory kit." f) In the event the hob is not installed above a built-in oven, a wood panel must be inserted as insulation.
- Page 10 • Remove the pan supports and slide the burners out of the cooktop. • Unscrew the nozzles using a 7mm socket wrench and replace them with those for the new type of gas. (See table 1, “Burner and Nozzle Specifications”).
-
Page 11: Electrical Connection
Electrical connection WARNING: THIS APPLIANCE MUST BE EARTHED. The hob is designed to work with alternating current, the supply voltage and frequency indicated on the rating plate (situated under the hob). Make sure that the local supply voltage corresponds to the voltage indicated on the rating plate. -
Page 12: Characteristic Of The Burners And Nozzles
Characteristic of the burners and nozzles Table 1 Burner Diameter Thermal power (mm) Nomin. Fast (R) 3,00 Semi Fast (S) 1,90 Auxiliary (A) 1,00 Triple Crown (TC) 2,50 Nominal (mbar) Supply Minimum (mbar) Pressures Maximum (mbar) At 15°C and 1013 mbar-dry gas Propane P.C.S. - Page 13 Notes...
- Page 14 Notes...
- Page 15 Notes...
-
Page 16: After Sales Service
Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in both the appliances and services we offer. Repair Service and Information Desk (Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays) Note: Our operators will require the following information: (Open 8-30 to 5-30 Mon - Fri &...
