YUYAO VISTAR ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD
No.206 BEIXING ROAD OF WEST CITY INDUSTRIAL
DEVELOPMENT ZONE,
YUYAO CITY, ZHEJIANG, CHINA 315450
TEL: +86-574-62803099
FAX: +86-574-62803111
EMAIL: info@vistarfoto.com
WEB:www.visico.com
FT-650RX Full Color Pixel LED light Panel
FT-650R Full Color LED light Panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT-650RX and is the answer not in the manual?

Questions and answers

Related Manuals for VISICO FT-650RX

Summary of Contents for VISICO FT-650RX

  • Page 1 YUYAO VISTAR ELECTRONIC SCIENCE & TECHNOLOGY CO., LTD No.206 BEIXING ROAD OF WEST CITY INDUSTRIAL FT-650RX Full Color Pixel LED light Panel DEVELOPMENT ZONE, FT-650R Full Color LED light Panel YUYAO CITY, ZHEJIANG, CHINA 315450 TEL: +86-574-62803099 FAX: +86-574-62803111 EMAIL: info@vistarfoto.com...

  • Page 2: Table Of Contents

    Set Special Effect Mode ......12 Pixel Effect Mode ......14 Specification ......15 VISICO LIGHT APP Thank you very much for your selection of full color Panel Light. Please read instruction carefully and keep them handy for your reference. 01/02...

  • Page 3: Name Of Parts

    NameofParts 1.Power switch 8.Locking screw for tilt angle 2.AC adapter port 9.Ø16 hole for light stand 3.DMX port 10.Fixing screw for light stand (Only with FT-650RX) 11.Barndoors 4.Function buttons 12.LEDs 5.Battery compartment 13.Magnetic holders for diffuser panel 6.Battery release button 14.

  • Page 4: Operation Button

    Repeatedly press to select CCT MODE mode, HSI mode, effect mode and Pixel Fx mode. (Pixel Fx mode only with FT-650RX) Press UP or down button, to change function options. Rotate Regulator to select language, select effects or change parameter.

  • Page 5: Set Id

    ID. Rotate regulator to select ID value 001-200. DMX address range: 001-512 DMX Control(Only with FT-650RX) DMX PIXEL value : 1 or 4. 1. Use DMX adapter cable (not include) to establish the connection between light fixtures and DMX console.

  • Page 6: Set Cct Mode

    Set HSI Mode Press MODE button to select HSI Mode. Press button to select If you select DMX mode RGBWY, each pixel will use 5 DMX addresses. from DIM, HUE, SAT. Rotate regulator to adjust the value of DIM, If you select DMX mode RGB, each pixel will use 3 DMX addresses. HUE, SAT.

  • Page 7: Set Special Effect Mode

    Press button to change function options. Rotate knob to change the value of every function option. Pixel Effect Mode(Only with FT-650RX) There are 12 pixel effect modes, including HUE LOOP, CCT LOOP, INT LOOP, MULTICOLOR, FADE, PROCESS、SCROLL,FIRE, RAINBOW,DRIVING, POLICE CAR, AMBULANCE.

  • Page 8: Specification

    Specification Model FT-650RX FT-650R 144PCS 2700K, 144PCS 6500K, LED quantity 288PCS RGB Power Output 60W CCT, 30W RGB 2240 lux/m @5500K, Illumination 8050 lux/0.5m @5500K Color Temperature 2700-10000K 000-360 CRI @5500K >96% >97% TLCI @5500K DIM range 0-100% CCT, HSI, 15 kinds...

  • Page 9: Visico Light App

    VISICOLIGHTAPP Download the “VISICO LIGHT”app directly from the App Store or the Google Play Store. (iOS 9.0 or superior, Android 5.0 or superior) 15/16...
